Marantz DV4500 - Parts List

POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PARTS NAME DISCRIPTION
EXPLODED VIEW PARTS
A1X /N1B 12BW248510 00M12BW248510 PANEL FRONT ASSEMBLY BLACK 1VM220042
A1X /N1S 12BW248530 00M12BW248530 PANEL FRONT ASSEMBLY SILVER 1VM220044
A2 /N1B 44AW063010 00M44AW063010 ESCUTCHEON TRAY PANEL BLACK 0VM204372
A2 /N1S 44AW063210 00M44AW063210 ESCUTCHEON TRAY PANEL SILVER 0VM416014
A13 44AW057020 00M44AW057020 LEG FOOT(REAR) DV4500 0VM415007
A14 /N1B 44AW057010 00M44AW057010 LEG LEG ASSY BLACK GOLD 0VM415913
A14 /N1S 44AW057210 00M44AW057210 LEG LEG ASSY SILVER 0VM416056
A15 nsp nsp CHASSIS MAIN CHASSIS DV4500 0VM101362
A17 nsp nsp PANEL REAR PANEL DV4500 FOR N 1VM220059
00M12BW304010 00M12BW304010
MECHA LOADER /
MECHA
TRAVERSE
DVD MECHA(FG LESS) 0838 VCZL0500 N79F0HVM
90M-ZZ002500R 90M-ZZ002500R PCB ASSY DVD MAIN CBA UNIT N79B0HEP
90M-ZZ002510R 90M-ZZ002510R PCB ASSY AV CBA ASSY / FUNCTION CBA ASSY
/ LED CBA ASSY
1VSA10352
AC1001 90M-YC000820R 90M-YC000820R MAINS CORD ! MAINS CORD PE8B2CG980A-057 WAE0172LW006
PACKING
X1 00MZK12BW0010 00MZK12BW0010 UNIT KIT REMOTE CONTROLLER RC6500DV NA819ED
X10 00M12BW851310 00M12BW851310 USER GUIDE USER GUIDE DV4500 FOR N 1VMN20116
NOT STANDARD SPARE PARTS
A16 /N1B nsp 00M44AW257010 LID TOP COVER BLACK 0VM101038B
A16 /N1S nsp 00M44AW257210 LID TOP COVER SILVER 0VM305312C
S1 nsp 00M12BW801010 CARTON BOX GIFT BOX CARTON DV4500 1VM320178
S2 nsp 00M44AW809010 CUSHION CUSHION DV4500 0VM101316
ELECTRICAL PARTS LIST
AV CBA
C1001 90M-DF100360R 90M-DF100360R FILM CAP. ! 0.047UF/250V K OR M CT2E473DC011
C1006 90M-DK100850R 90M-DK100850R CERAMIC CAP. ! SAFETY CAP. 2200PF/250V CCN2EMP0E222
CN1001 nsp 90M-YU001620R FPC 23P FFC AV PCB TO MAIN WX1E59M2-003
CN1601 nsp 90M-YU001630R FPC 20P FFC AV PCB TO MAIN WX1E5982-004
CN2082 nsp 90M-YU001640R FPC 7P FFC AV PCB TO IND PCB WX1E59M2-001
F1001 90M-FS001120R 90M-FS001120R FUSE ! FUSE T1.6AL/250V PAGC20BW3162
OR 1790994
IC1204 90M-YJ002710R 90M-YJ002710R OPT. CONNECTOR OPTIC TRANS.MODULE GP1FA513TZ JWHHA00SH005
JK1202 90M-YT003370R 90M-YT003370R TERMINAL CINCH (BLACK) MSP-251V-01 NI JXRL010LY070
JK1401 90M-YT003380R 90M-YT003380R TERMINAL S TYPE JACK MDC-050V-2.4 JXEL040LY001
JK1404 90M-YT003850R 90M-YT003850R TERMINAL CINCH MSP-246V34-65NI-FELF
OR MSD-246V-65NI/PBSN
JXRL060LY082
OR JXRL060LY069
JK1405 90M-YT003390R 90M-YT003390R TERMINAL
SCART CONNECTOR 21P RGB AJ-2050*04
0
JXGL210JD002
JK2081 90M-YT003860R 90M-YT003860R TERMINAL CINCH 2PIN (ORANGE) MSD-242V-24 NI JXRL020LY105
L1001 90M-FN000190R 90M-FN000190R FILTER ! 50MH LF-4Z-E503
OR LF-4D-E503
OR TLF14CB5630R2
LLBG00ZKQ008
OR LLBG00ZKQ009
OR LLBG00ZTU022
SA1001 90M-HV000050R 90M-HV000050R VARISTOR ! PVR-10D471KB
OR CNR-10D471K
NVQZ10D471KB
OR
SW2081 90M-SS000760R 90M-SS000760R SWITCH SLIDE SWITCH SK12D07VG5-L A SSS0102LY003
T1001 90M-TP000080R 90M-TP000080R TRANSF. ! PULSE TRANS CGS-SW0005A
OR 04715
LTT00CPSA155
OR LTT00CPKT128
FUNCTION CBA
CN2101 nsp 90M-YU001650R FPC 9P FFC AV PCB TO FNT PCB WX1E59M2-002
OR CT2E473MS037
OR CA2E222MR049
1B1
A18
A19
NOTE ON SAFETY :
Symbol Fire or electrical shock hazard. Only original
parts should be used to replaced any part marked with
symbol . Any other component substitution (other
than original type), may increase risk of fire or electrical
shock hazard.
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PARTS LIST
1-15-1
