MAIN
MAIN PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied. Part indicated b
y
"
@
" mark is not illustrated in the ex
p
loded vie
w
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D100 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D300 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D301 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D302 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D303 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D304 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D305 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D308 90M-HD201820R DIODE, SCHOTTKEY BARRIER HVDRB160L60TE25 1
Q100 00D9430058908 T.R , CHIP , SOT-23
HVTKTA1504SYRTK
1
Q101 00D2730464901 T.R , CHIP , SOT-23
HVTKTC3875SYRTK
1
Q300 00D2690184907 T.R , CHIP , SOT-23 HVTKRA102S 1
Q301 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1
Q302 00D2730464901 T.R , CHIP , SOT-23
HVTKTC3875SYRTK
1
IC100 943245006980S I.C , CD DSP(DSP,LQFP-80P)
CVITC94A92FG_CU 1
IC101 943239101880S I.C,MOTOR DRIVE (HSOP-M28,28PIN) CVIBA5810FM 1
IC103 943231102390S I.C, REGULATOR(1.0A, 1.5V, SOT-223) CVILM1117S15 1
IC108 00MHC012405KY I.C , INVERTER (SON5-P-0.50) CVITC7SGU04FE 1
IC300 943246101070M EOL item I.C , EEPROM (16KBIT,SOP-8P) CVIK24C16SIRXA 1
IC301 943234009290S I.C , RESET 2.4V (200ms,C-MOS,SOT23-5P)
CVIS80124CLMCJIJT2
1
IC302 943243103490S
I.C,U-COM HDCD1 (MB9AF344NAPMC, FUJITSU)
See PROCEDURE AFTER REPLACING THE U-COM, ETC.
VVIANAM2338C 1 *
RESISTOR GROUP
R100 nsp RES, CHIP(1608/5%/91ohm) CRJ10DJ910T 1
R101 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R102 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R103 nsp RES, CHIP(1608/5%/18Kohm) CRJ10DJ183T 1
R104 nsp RES, CHIP(1608/5%/18Kohm) CRJ10DJ183T 1
R105 nsp RES, CHIP(1608/5%/18Kohm) CRJ10DJ183T 1
R106 nsp RES, CHIP(1608/5%/39ohm) CRJ10DJ390T 1
R107 nsp RES, CHIP(1608/5%/39ohm) CRJ10DJ390T 1
R108 nsp RES, CHIP(1608/5%/39ohm) CRJ10DJ390T 1
R109 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R110 nsp RES, CHIP(1608/5%/39ohm) CRJ10DJ390T 1
R111 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R112 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R113 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R114 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R115 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R116 nsp RES, CHIP(1608/5%/330Kohm) CRJ10DJ334T 1
R118 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R119 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R120 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R121 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R122 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R123 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R124 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R125 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R126 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R127 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R128 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R130 nsp RES, CHIP(1608/5%/1.8Kohm) CRJ10DJ182T 1
R131 nsp RES, CHIP(1608/5%/27Kohm) CRJ10DJ273T 1
R132 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R134 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R135 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R136 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R137 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R138 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R139 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R140 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R141 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R142 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R147 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R149 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R150 nsp RES, CHIP(1608/5%/12Kohm) CRJ10DJ123T 1
R151 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R152 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R154 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R155 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R157 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R158 nsp RES, CHIP(1608/5%/1.8Kohm) CRJ10DJ182T 1
R159 nsp RES, CHIP(1608/5%/27Kohm) CRJ10DJ273T 1
R160 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R162 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R163 nsp RES, CHIP(1608/5%/47ohm) CRJ10DJ470T 1
R164 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R166 nsp RES, CHIP(1608/5%/22ohm) CRJ10DJ220T 1
R167 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R168 nsp RES, CHIP(1608/5%/0ohm)
CRJ10DJ0R0T 1
R169 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R170 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R171 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R172 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R173 nsp RES, CHIP(1608/5%/1.8Kohm) CRJ10DJ182T 1
R174 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R180 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R181 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R182 nsp RES, CHIP(1608/5%/68ohm) CRJ10DJ680T 1
R183 nsp RES, CHIP(1608/5%/10ohm) CRJ10DJ100T 1
R184 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R185 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R187 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R209 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R214 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R215 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R219 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R235 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R236 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R237 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R238 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R239 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R240 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R241 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R242 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R243 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
3
