Dimensions (Unit : in. (mm))
.
17 3/8 (440)
2 1/4
(55)
3 1/2
(87)
5/8
(14)
13 1/2 (340)
2 1/4
(55)
2 (50) 2 (50)
3/4
(16)
1 3/8
(34)
8 3/8 (210)
13 (328) 15 (378)
3 5/8 (91)
4 1/4 (105)
7 (175)
o
Weight : 18 lbs 1 oz (8.2 kg)
