Video connectors (VIDEO)
Used to connect devices equipped with video connectors.
0
“Connection 3 : TV equipped without an HDMI
connector” (v p. 54)
0
“Connecting a set-top box (Satellite tuner/cable TV)” (v p. 56)
0
“Connecting a video camcorder or game console” (v p. 59)
M
Component video connectors (COMPONENT VIDEO)
Used to connect devices equipped with component video connectors.
0
“Connection 3 : TV equipped without an HDMI
connector” (v p. 54)
0
“Connecting a DVD player or Blu-ray Disc player” (v p. 57)
N
Speaker terminals (SPEAKERS)
Used to connect speakers. (v p. 36)
O
AC inlet (AC IN)
Used to connect the power cord. (v p. 68)
NOTE
0
Do not touch the inner pins of the connectors on the rear panel. Electrostatic
discharge may cause permanent damage to the unit.
