Connect the speakers to the amplifier
Connecting the speaker cables
q Peel off about 10 mm of
sheathing from the tip of the
speaker cable, then either
twist the core wire tightly or
apply solder to it.
w Turn the speaker terminal
counterclockwise to loosen it.
e Insert the speaker cable’s
core wire to all the way into
the speaker terminal.
r Turn the speaker terminal
clockwise to tighten it.
w q
w q
AC IN
AUDIO IN POWER AMP IN
AUDIO IN
CD LINE-1
PHONOSIGNAL
GND
LINE-2 RECORDER- 1 RECORDER- 2 RECORDER- 1 RECORDER- 2 IN
ID
STEREO
BI-AMP
F.C.B.S.
REMOTE CONTROL AMP MODE
OUTIN
OUT
AUDIO OUT
SPEAKERS
(L) (R)

Marantz PM-KI RUBY Specifications

General

Type	Integrated Amplifier
Signal to Noise Ratio MC	75 dB
Damping Factor	100
Dimensions	440 x 127 x 453 mm
Frequency Response	5Hz - 50kHz
Total Harmonic Distortion	0.005%
Input Sensitivity MM	2.5 mV / 47 kohm
Input Sensitivity	200 mV / 22 kohm
