Marantz PMD570 Service Manual

56
No. portname I/O USE Sig.Name ACT INI RST PUP Description
61 P61 I/O I TCK E10A（UDI1)
62 P62 I/O I TDI E10A（UDI6)
63 P63 I/O O TDO E10A（UDI3)
64 P27 I/O
65 P26 I/O
66 P25 I/O
67 P24 I/O
68 P23 I/O O PLAYLED LED
69 P22 I/O O DBCK Audio
70 P21 I/O O DBSTB Audio
71 P20 I/O O DBDATA Audio
72 ￣ WDTOVF
73 ￣ RES I I - I PullUp
74 NMI I I - I PullUp
75 ￣ STBY I I - I PullUp
76 Vcc - - +3.3V -
77 XTAL O O 24.576MHz O
78 EXTAL I I 24.576MHz I
79 VSS I - - - Ground
80 PF7 I I CARDEJECT L H Z PullUp
81 Vcc - - +3.3V' -
82 PF6 I/O I PLAY L H Z PullUp
83 PF5 I/O I STOP L H Z PullUp
84 PF4 I/O I RECP L H Z PullUp
85 PF3 I/O I MODE L H Z PullUp
86 PF2 I/O I FF L H Z PullUp
87 PF1 I/O I RWD L H Z PullUp
88 PF0 I/O I JOGENTER L H Z KEY&SW
89 P50 I/O O LINE-MUTE H L Z Audio
90 P51 I/O O HP-MUTE H L Z Audio
91 P52 I/O
92 P53 I/O
93 ACVV I - +5V -
94 Vref
95 P40 I ADC
96 P41 I ADC
97 P42 I I
98 P43 I I HRDY - - Z forDSP
99 P44 I I CARDIN L H Z PullUp
100 P45 I I USBIN H L Z CD1&CD2&USB1
101 P46 I I
102 P47 I I
103 AVSS I - Ground - - - Ground
104 VSS I - - - Ground
105 P17 I/O O DSPPW forDSP
106 P16 I/O O HCNTL1 H H Z forDSP
107 P15 I/O O HCNTL0 H H Z forDSP
108 P14 I/O I Reserve
109 P13/TIOCD0 I/O I ENCORDERB
110 P12/TIOCC0 I/O I ENCORDERA
111 P11/TIOCB0 I/O O RECLED H L Z REDLED
112 P10/TIOCA0 I/O O HRESET# L H Z forDSP
113 MD0 I I Mode7 I PullUp
114 MD1 I I Mode7 I PullUp
115 MD2 I I Mode7 I PullUp
116 PG0 I/O O HBIL H L Z forDSP
117 PG1 I/O O HDS# L H Z forDSP
118 PG2 I/O O HRW# L H Z forDSP
119 PG3 I/O O HCS# L H Z forDSP
120 PG4 I/O O DSPINT forDSP
QU01 : H8S/2328 (FRONT uP)
