no port name I/O USE Sig. Name act. Description
41 PA6 I/O O _RST SURR L
42 PA7/SCOUT I/O O _REQ SURR L I/F to SURR. µP
43 ALE O - - - Pull Up
44 VCC I - - - to VCC
45 P00 I/O O TU_CE(TUNER) H
46 P01 I/O O CLK(TUNER) -
47 P02 I/O O DO(TUNER) -
48 P03 I/O I DI(TUNER) -
49 P04 I/O I SD(TUNER) L
50 P05 I/O I DI(RDS) -
51 P06 I/O O _KILL CON L
52 P07 I/O O - -
53 P10 I/O O -CLKFL -
54 P11 I/O O -DATAFL -
55 P12 I/O O -
56 P13 I/O O - -
57 P14 I/O O - -
58 P15 I/O O - -
59 P16 I/O O - -
60 P17 I/O O - -
61 WDTOUT O - - - N.C
62 VSS I - - - to VSS
63 VCC I - - - to VCC
64 P20 I/O I FUNC. ENC. A -
65 P21 I/O I FUNC. ENC. B -
66 P22 I/O I VOL. ENC. A -
67 P23 I/O I VOL. ENC. B -
68 P24 I/O I GYRO A -
69 P25 I/O I GYRO B -
70 P26 I/O I - - to VSS
71 P27 I/O I - - to VSS
72 P30 I/O O CE0(AUDIO) H
73 P31 I/O O _CE7(VIDEO) L
74 P32 I/O O CE3(Multi Vol.) H
75 P33 I/O O _CE6(MUTE) L
76 P34 I/O O _CE5(LED) L
77 P35 I/O O _CE4(FL) L
78 P36 I/O O _CE1(OSD C) L
79 P37 I/O O _CE2(OSD S) L
80 P40 I/O O (RESERVED) -
no port name I/O USE Sig. Name act. Description
81 P41 I/O O (RESERVED) -
82 P42 I/O O (RESERVED) -
83 P60/ I/O I (RESERVED) - to VSS
84 P61/ I/O I (RESERVED) - to VSS
85 P62/ I/O I (RESERVED) - to VSS
86 P63/ I/O I SWITCH0 -
87 P64/ I/O I SWITCH1 -
88 P65/ I/O I SWITCH2 -
89 P66/ I/O I SWITCH3 -
90 P67/ I/O I SWITCH4 -
91 VSS I - - - to VSS
92 P50/AN0 I AN - - pull down
93 P51/AN1 I AN POWER DET. - see below
94 P52/AN2 I AN ABNORMAL - see below
95 P53/AN3 I AN KEY IN0 -
96 P54/AN4 I AN KEY IN1 -
97 P55/AN5 I AN KEY IN2 -
98 P56/AN6 I AN KEY IN3 -
99 P57/AN7 I AN KEY IN4 -
100
VREFH I - - - A/D VREFH
no port name I/O USE Sig. Name act. Description
1 VREFL I - - - A/D VREFL.
2 AVSS I - - - A/D VSS
3 AVCC I - - - A/D VCC
4 NMI I NMI - - Pull Up
5 P70/TI0 I/O O _POWER OFF L
6 P71/TO1 I/O O KILL IR H
7 P72/TO2 I/O O RC-5 OUT H
8 P73/TO3 I/O O SPEAKER OFF H SPK RELAY
9 P80/INT4/ I/O I
RC-5 IN
H Both Edge
10 P81/INT5/ I/O I SYNC0 H Rising Edge
11 P82/TO4 I/O I _HEAD PHONE L
12 P83/TO5 I/O I - -
13 P84/INT6/ I/O I _SURR. ACK L Both Edge
14 P85/INT7/ I/O I
SYNC1
H Rising Edge
15 P86/TO6 I/O I MULTI RC-5 IN L
16 P87/INT0 I/O I _POWER DOWN L
17 P90/TXD0 I/O TXD DO0 - I/F to SURR. µP
18 P91/RXD0 I/O RXD DI0 - I/F to SURR. µP
19 P92/SCLK0 I/O CLK CLK0 - I/F to SURR. µP
20 P93/TXD1 I/O O DO1 - I/F to ICs
21 P94/RXD1 I/O -
22 P95/SCLK1 I/O O CLK1 - I/F to ICs
23 AM8/_16 I - - - Pull Up
24 CLK O - - - Pull Up
25 VCC I - - - Pull Up
26 VSS I - - - to VSS
27 X1 I - - - 20MHz
28 X2 O - - - 20MHz
29 EA I - - - Pull Up
30 RESET I - - -
31 P96/XT1 I/O I - - to VSS
32 P97/XT2 I/O I - - to VSS
33 TEST1 I - - - to TEST2
34 TEST2 I - - - to TEST1
35 PA0 I/O O OSD ON0 H
36 PA1 I/O O OSD ON1 H
37 PA2 I/O O _CLR LED L NJU3718 CLR
38 PA3 I/O O MULTI RC-5 OUT H
39 PA4 I/O O _CE8 (Volume 8ch) L
40 PA5 I/O O SMUTE H
Pull Up
QY01:TMP93PW40DF
