Marantz SR-19EX - Page 53

79
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
LR02 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
L601 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
L602 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
L651 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
L691
4822 157 10884 EMI FILTER BLM11A221S FN31000010
L697
X601 4822 242 10851 CRYSTAL 12.288MHz AT-49 JX12013260
X691 9965 000 01346 SERAMIC VIB. CST20 00MXW FQ02005030
P704-3CH POWER-AMP.
CIRCUIT BOARD
P704-CAPACIORS
CT01 4822 124 22275 ELECT 47
F M 10V RA-2 OA47601020
CT03 9965 000 05891 FILM 470pF J 100V OF15471540
CT05 9965 000 05891 FILM 470pF J 100V OF15471540
CT07 9965 000 01040 ELECT 470
F M 6.3V RA-2 OA47700620
CT11 9965 000 02644 ELECT 220
F M 100V RA-2 OA22710020
CT13 9965 000 02644 ELECT 220
F M 100V RA-2 OA22710020
CT15 4822 124 11533 ELECT 1
F M 100V RA-2 OA10510020
CT17 9965 000 01561 MICA 10pF D 250WV DF31100520
CT19 9965 000 05892 ELECT 4.7
F 100V EA47510010
CT27 9965 000 00438 FILM 120pF J 100V OF15121540
CT29 9965 000 00438 FILM 120pF J 100V OF15121540
C701 4822 124 22275 ELECT 47
F M 10V RA-2 OA47601020
C702 4822 124 22275 ELECT 47
F M 10V RA-2 OA47601020
C703
9965 000 05891 FILM 470pF J 100V OF15471540
C706
C707 9965 000 01040 ELECT 470
F M 6.3V RA-2 OA47700620
C708 9965 000 01040 ELECT 470
F M 6.3V RA-2 OA47700620
C711 9965 000 02644 ELECT 220
F M 100V RA-2 OA22710020
C712 9965 000 02644 ELECT 220
F M 100V RA-2 OA22710020
C713 9965 000 02644 ELECT 220
F M 100V RA-2 OA22710020
C714 9965 000 02644 ELECT 220
F M 100V RA-2 OA22710020
C715 4822 124 11533 ELECT 1
F M 100V RA-2 OA10510020
C716 4822 124 11533 ELECT 1
F M 100V RA-2 OA10510020
C717 9965 000 01561 MICA 10pF D 250WV DF31100520
C718 9965 000 01561 MICA 10pF D 250WV DF31100520
C719 9965 000 05892 ELECT 4.7
F 100V EA47510010
C720 9965 000 05892 ELECT 4.7
F 100V EA47510010
C727
9965 000 00438 FILM 120pF J 100V OF15121540
C730
P704-CAPACITORS(COMMON)
PLASTIC FILM CAPACITOR
5% 50V : C721-C726 CT21
CT23 CT25
P704-RESISTORS
RT07 1.5k 5% 1/6W GG05152160
RT09 1.5k 5% 1/6W GG05152160
RT15 4822 100 11471 TRIM. 100k
RH0638CJ4R RA01040780
RT25 4822 052 10561 560 5% 1/6W GG05561160
RT27 4822 052 10561 560 5% 1/6W GG05561160
RT29 4822 052 10561 560 5% 1/6W GG05561160
RT31 4822 052 10561 560 5% 1/6W GG05561160
RT33 4822 052 10569 56 5% 1/6W GG05560160
RT35 4822 052 10569 56 5% 1/6W GG05560160
RT43 4822 100 20681 TRIM. 2.2k
RH0638CJ3R RA02220780
RT49 4822 052 10109 10 5% 1/4W GG05100140
RT51 4822 052 10109 10 5% 1/4W GG05100140
RT53 4822 052 10101 100 5% 1/6W GG05101160
RT55 4822 052 10101 100 5% 1/6W GG05101160
RT61 4822 052 10102 1k 5% 1/6W GG05102160
RT63 4822 052 10229 22 5% 1/6W GG05220160
RT65 4822 052 10229 22 5% 1/6W GG05220160
RT67 4822 116 60319 220 J 1/2W FUSIBLE NH05221120
RT69 4822 052 10228 2.2 5% 1/6W GG05022160
RT71 4822 052 10228 2.2 5% 1/6W GG05022160
RT73 4822 111 91422 COMPO. 0.1 K 5WX2RGC-55 BW10000050
RT75 4822 052 10102 1k 5% 1/6W GG05102160
RT77 4822 050 22202 2.2k 5% 1/6W GG05222160
RT83 4822 116 83929 220 5% 1/4W GG05221140
RT85 4822 053 10109 10 5% 1W GA05100010
R707
1.5k 5% 1/6W GG05152160
R710
R715 4822 100 11471 TRIM. 100k
RH0638CJ4R RA01040780
R716 4822 100 11471 TRIM. 100k
RH0638CJ4R RA01040780
R725
4822 052 10561 560 5% 1/6W GG05561160
R732
R733
4822 052 10569 56 5% 1/6W GG05560160
R736
R743 4822 100 20681 TRIM. 2.2k
RH0638CJ3R RA02220780
R744 4822 100 20681 TRIM. 2.2k
RH0638CJ3R RA02220780
R749
4822 052 10109 10 5% 1/4W GG05100140
R752
R753
4822 052 10101 100 5% 1/6W GG05101160
R756
R761 4822 052 10102 1k 5% 1/6W GG05102160
R762 4822 052 10102 1k 5% 1/6W GG05102160
R763
4822 052 10229 22 5% 1/6W GG05220160
R766
R767 4822 116 60319 220 J 1/2W FUSIBLE NH05221120
R768 4822 116 60319 220 J 1/2W FUSIBLE NH05221120
R769
4822 052 10228 2.2 5% 1/6W GG05022160
R772
R773 4822 111 91422 COMPO. 0.1 K 5WX2RGC-55 BW10000050
R774 4822 111 91422 COMPO. 0.1 K 5WX2RGC-55 BW10000050
R775 4822 052 10102 1k 5% 1/6W GG05102160
R776 4822 052 10102 1k 5% 1/6W GG05102160
R777 4822 050 22202 2.2k 5% 1/6W GG05222160
R778 4822 050 22202 2.2k 5% 1/6W GG05222160
R783 4822 116 83929 220 5% 1/4W GG05221140
R784 4822 116 83929 220 5% 1/4W GG05221140
R785 4822 053 10109 10 5% 1W GA05100010
R786 4822 053 10109 10 5% 1W GA05100010
P704-RESISTORS(COMMON)
CARBON FILM FIXED RES.
5% 1/6W : R701-R706
R711-R714 R717-R724
R737-R742 R745-R748
R779-R782 R787-R790
RT01 RT03 RT05 RT11 RT13
RT17 RT19 RT21 RT23 RT37
RT39 RT41 RT45 RT47 RT79
RT81 RT87 RT89
P704-SEMICONDUCTORS
DT01 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DT03 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DT13 4822 130 80837 DIODE HSS81TD 150V 150MA HD20027010
DT15 4822 130 80837 DIODE HSS81TD 150V 150MA HD20027010
DT17 4822 130 80317 ZENER DIODE ZENER 5.1V HD30511000
C
R
