Marantz SR-19EX - Page 54

80
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
DT19 4822 130 80317 ZENER DIODE ZENER 5.1V HD30511000
DT21 4822 130 80837 DIODE HSS81TD 150V 150MA HD20027010
D701
D704
4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D713
4822 130 80837 DIODE HSS81TD 150V 150MA HD20027010
D716
D717
4822 130 80317 ZENER DIODE ZENER 5.1V HD30511000
D720
D721 4822 130 80837 DIODE HSS81TD 150V 150MA HD20027010
D722 4822 130 80837 DIODE HSS81TD 150V 150MA HD20027010
K761 TRS. KIT 2SA1360 2SC3423
O OR Y
HK136019C0
K762 TRS. KIT 2SA1360 2SC3423
O OR Y
HK136019C0
K763 TRS. KIT 2SA1360 2SC3423
O OR Y
HK136019C0
K766 TRS. KIT A1837 C4793 HFE HK183719C0
K767 TRS. KIT A1837 C4793 HFE HK183719C0
K768 TRS. KIT A1837 C4793 HFE HK183719C0
K771 4822 130 11394 TRS. KIT 2SA1216 2SC2922
O Y
HK121619F0
K772 4822 130 11394 TRS. KIT 2SA1216 2SC2922
O Y
HK121619F0
K773 4822 130 11394 TRS. KIT 2SA1216 2SC2922
O Y
HK121619F0
QT01 4822 130 42949 TRS. 2SA970 GR OR BL HT109702A0
QT03 4822 130 42949 TRS. 2SA970 GR OR BL HT109702A0
QT05 4822 130 42999 TRS. 2SA1145 O OR Y HT111452A0
QT07 4822 130 43283 TRS. 2SC2705 O OR Y HT327052A0
QT09 4822 130 43283 TRS. 2SC2705 O OR Y HT327052A0
QT11 5322 130 61728 TRS. 2SA1360 O OR Y HT113602A0
QT13 5322 130 61737 TRS. 2SC3423 O OR Y HT334232A0
QT17 4822 130 43283 TRS. 2SC2705 O OR Y HT327052A0
QT19 4822 130 42999 TRS. 2SA1145 O OR Y HT111452A0
QT21 4822 130 63635 TRS. 2SC4793 O OR Y HT347932A0
QT23 4822 130 63634 TRS. 2SA1837 O OR Y HT118372A0
QT29 4822 130 43233 TRS. 2SC2240 GR OR BL HT322402A0
Q701
4822 130 42949 TRS. 2SA970 GR OR BL HT109702A0
Q704
Q705 4822 130 42999 TRS. 2SA1145 O OR Y HT111452A0
Q706 4822 130 42999 TRS. 2SA1145 O OR Y HT111452A0
Q707
4822 130 43283 TRS. 2SC2705 O OR Y HT327052A0
Q710
Q711 5322 130 61728 TRS. 2SA1360 O OR Y HT113602A0
Q712 5322 130 61728 TRS. 2SA1360 O OR Y HT113602A0
Q713 5322 130 61737 TRS. 2SC3423 O OR Y HT334232A0
Q714 5322 130 61737 TRS. 2SC3423 O OR Y HT334232A0
Q717 4822 130 43283 TRS. 2SC2705 O OR Y HT327052A0
Q718 4822 130 43283 TRS. 2SC2705 O OR Y HT327052A0
Q719 4822 130 42999 TRS. 2SA1145 O OR Y HT111452A0
Q720 4822 130 42999 TRS. 2SA1145 O OR Y HT111452A0
Q721 4822 130 63635 TRS. 2SC4793 O OR Y HT347932A0
Q722 4822 130 63635 TRS. 2SC4793 O OR Y HT347932A0
Q723 4822 130 63634 TRS. 2SA1837 O OR Y HT118372A0
Q724 4822 130 63634 TRS. 2SA1837 O OR Y HT118372A0
Q729 4822 130 43233 TRS. 2SC2240 GR OR BL HT322402A0
Q730 4822 130 43233 TRS. 2SC2240 GR OR BL HT322402A0
P704-MISCELLANEOUS
LT01 4822 157 70022 AIR COIL SPK CHOCK ML08010030
L701 4822 157 70022 AIR COIL SPK CHOCK ML08010030
L702 4822 157 70022 AIR COIL SPK CHOCK ML08010030
S701 9965 000 01765 CIRCUIT BREAKER TEMP-SW
120DEG. OHD3-120B
FR31200020
S702 9965 000 01765 CIRCUIT BREAKER TEMP-SW
120DEG. OHD3-120B
FR31200020
P754-2CH POWER-AMP.
CIRCUIT BOARD
P754-CAPACITORS
CN01 4822 122 40617 CER. 0.1
F +80% -20% 50V DD38104010
CN02 4822 124 41539 ELECT 47
F M 16V RA-2 OA47601620
CN03 4822 124 41539 ELECT 47
F M 16V RA-2 OA47601620
CN04 4822 122 40617 CER. 0.1
F +80% -20% 50V DD38104010
CN05 4822 124 90354 ELECT 100
F M 16V RA-2 OA10701620
CN06 4822 124 90354 ELECT 100
F M 16V RA-2 OA10701620
CN07 4822 124 41543 ELECT 1
F M 50V RA-2 OA10505020
CN08 4822 122 40617 CER. 0.1
F +80% -20% 50V DD38104010
CN09 4822 124 90353 ELECT 100
F M 10V RA-2 OA10701020
CN10 4822 124 90362 ELECT 22
F M 50V RA-2 OA22605020
CN11 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CN12 4822 124 41539 ELECT 47
F M 16V RA-2 OA47601620
CN13 4822 124 90354 ELECT 100
F M 16V RA-2 OA10701620
CN14 4822 124 90354 ELECT 100U
F M 16V RA-2 OA10701620
CN15 4822 122 40617 CER. 0.1
F +80% -20% 50V DD38104010
CN16 9965 000 01040 ELECT 470
F M 6.3V RA-2 OA47700620
CN17 ELECT 47
F 16V EQ47601630
CP01 4822 124 22275 ELECT 47
F M 10V RA-2 OA47601020
CP02 4822 124 22275 ELECT 47
F M 10V RA-2 OA47601020
CP03
9965 000 05891 FILM 470pF J 100V OF15471540
CP06
CP07 9965 000 01040 ELECT 470
F M 6.3V RA-2 OA47700620
CP08 9965 000 01040 ELECT 470
F M 6.3V RA-2 OA47700620
CP11
9965 000 02644 ELECT 220 F M 100V RA-2 OA22710020
CP14
CP15 4822 124 11533 ELECT 1
F M 100V RA-2 OA10510020
CP16 4822 124 11533 ELECT 1
F M 100V RA-2 OA10510020
CP17 9965 000 01561 MICA 10pF D 250WV DF31100520
CP18 9965 000 01561 MICA 10pF D 250WV DF31100520
CP19 9965 000 05892 ELECT 4.7
F 100V EA47510010
CP20 9965 000 05892 ELECT 4.7
F 100V EA47510010
CP27
9965 000 00438 FILM 120pF J 100V OF15121540
CP30
C861 4822 124 90354 ELECT 100
F M 16V RA-2 OA10701620
C862 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C871 4822 124 90354 ELECT 100
F M 16V RA-2 OA10701620
C872 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C881 4822 124 90354 ELECT 100
F M 16V RA-2 OA10701620
C882 4822 126 10935 ELECT 100
F 6.3V EJ10700610
P754-CAPACITORS(COMMON)
PLASTIC FILM CAPACITOR
5% 50V : CP21-CP26
P754-RESISTORS
RN04 4822 050 21503 15k 5% 1/2W GG05153120
RN08 4822 050 23303 33k 5% 1/4W GG05333140
RN16 4822 052 10109 10 5% 1/6W GG05100160
RN44 4822 053 10221 220 5% 1W GA05221010
RN45 4822 053 10331 330 5% 1W GA05331010
RN46 4822 053 10331 330 5% 1W GA05331010
C
