Marantz SR-19EX - Page 56

82
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
QP28 9965 000 01763 TRS. 2SA1216 O OR Y HT112162A0
QP29 4822 130 43233 TRS. 2SC2240 GR OR BL HT322402A0
QP30 4822 130 43233 TRS. 2SC2240 GR OR BL HT322402A0
Q861 4822 209 31631 IC NJM7805FA +5V HC38905090
Q871 4822 209 31631 IC NJM7805FA +5V HC38905090
Q881 4822 130 63635 TRS. 2SC4793 O OR Y HT347932A0
P754-MISCELLANEOUS
MN51 9965 000 01770 D.C MOTOR FBA08A12H0
DC FAN 12V
MM01200320
LP01 4822 157 70022 AIR COIL SPK CHOCK ML08010030
LP02 4822 157 70022 AIR COIL SPK CHOCK ML08010030
LN01 9965 000 01343 RELAY RELAY MR62-12SR LY20120510
ZN51 9965 000 01772 UNIT KIT DC FAN MOTOR
W 3P WIRE
ZK300J0020
P774-PO-AMP. TR-BLOCK
3CH CIRCUIT BOARD
P774-SEMICONDUCTORS
D799 4822 130 43564 VARISTOR
PTH9M04BE222TS2F333
HP00004230
QT15 4822 130 60117 TRS. 2SC3419 Y HT334191Y0
QT25 9965 000 01762 TRS. 2SC2922 O Y HT329222A0
QT27 9965 000 01763 TRS. 2SA1216 O Y HT112162A0
Q715 4822 130 60117 TRS. 2SC3419 Y HT334191Y0
Q716 4822 130 60117 TRS. 2SC3419 Y HT334191Y0
Q725 9965 000 01762 TRS. 2SC2922 O Y HT329222A0
Q726 9965 000 01762 TRS. 2SC2922 O Y HT329222A0
Q727 9965 000 01763 TRS. 2SA1216 O Y HT112162A0
Q728 9965 000 01763 TRS. 2SA1216 O Y HT112162A0
P804-POWER SUPPLY +-15V
CIRCUIT BOARD
P804-CAPACITORS
C801 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C802 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C803 4822 124 81133 ELECT 4700
F 25V RA-2 OA47802520
C804 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C805 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
C806 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C807 4822 124 81133 ELECT 4700
F 25V RA-2 OA47802520
C808 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C817 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
C818 4822 122 30043 CER. 0.01
F Z 50V DK18103310
P804-SEMICONDUCTORS
D801 4822 130 83067 DIODE D3SB 20 V=200V
IO=3.0A
HE20020290
D802 4822 130 82421 DIODE 1D3 1A 200V HD20002710
D807 4822 130 82421 DIODE 1D3 1A 200V HD20002710
Q801 4822 209 60826 IC NJM7812FA +12V 1A HC38912090
Q806 TRS. 2SD1415 HT41415100
P804-MISCELLANEOUS
F801 /C,/K,/S FUSE T2.0A 250V TR5 FS20200200
F801 /U FUSE T2A 250V TR5 NO.19374 FS20200210
F802 /C,/K,/S FUSE T2.0A 250V TR5 FS20200200
F802 /U FUSE T2A 250V TR5 NO.19374 FS20200210
P854-MAIN+ B
CIRCUIT BOARD
P854-CAPACITORS
C851 4822 126 12453 CER. 0.01
F Z E 500V DK18103560
C852 4822 126 12453 CER. 0.01
F Z E 500V DK18103560
C853 ELECT. 56000 F 71V x2 OB56907120
C854 4822 126 12453 CER. 0.01
F Z E 500V DK18103560
C857 4822 124 90357 ELECT 2.2
F M 50V RA-2 OA22505020
P854-SEMICONDUCTORS
D851 9965 000 01578 DIODE D25XB60 BRIDGE HE20029290
D853 4822 130 82421 DIODE 1D3 1A 200V HD20002710
D854 4822 130 82421 DIODE 1D3 1A 200V HD20002710
PB14-PRIMARY [/U]
CIRCUIT BOARD
PB14-CAPACITOR
CB01 /U CER. DE1607-1F DK17103910
PB14-RESISTOR
RB01 /U RES. 2.2M
10% 1/2W RC10225820
PB14-SEMICONDUCTOR
DB01 /U 4822 130 82421 DIODE 1D3 1A 200V HD20002710
PB14-MISCELLANEOUS
FB01 /U FUSE 12A 250V UL CSA MITI FS11200440
FB02 /U FUSE 630MA 250V UL CSA FS10063360
JB03 /U JACK MAINS OUTLET 2P
CCT1304-0212
YJ04002040
LB02 /U 4822 280 80773 RELAY VS24MB-NR TV-8
LISTED
LY10240240
PB64-PRIMARY [/C, /K, /S]
CIRCUIT BOARD
PB64-CAPACITOR
CB51 /C,/K,/S CER. DE1607-1F 103M-KH DK17103910
PB64-SEMICONDUCTOR
DB51 /C,/K,/S 4822 130 82421 DIODE 1D3 1A 200V HD20002710
PB64-MISCELLANEOUS
FB51 /C,/K,/S 4822 070 36302 FUSE T6.3A 250V BS LISTED FS10630850
FB52 /C,/K,/S 4822 070 32001 FUSE T200MA 250V BS
LISTED
FS10020850
LB52 /C,/K,/S 4822 280 80773 RELAY VS24MB-NR TV-8
LISTED
LY10240240
PB74-POWER SW
CIRCUIT BOARD
CB71 CER. CAP. DE1610F 103M-KH DK17103900
SB71 9965 000 01777 PUSH SWITCH SDDLB1
POWER TV-5
SP01012460
PL04-CVBS VIDEO SELECTOR
CIRCUIT BOARD
PL04-CAPACITORS
CC53 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CC54 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CC55 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CC56 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CC59 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CC60 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CC61 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CC62 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CC64 4822 124 41535 ELECT 100
F M 25V RA-2 OA10702520
CC65 4822 124 41535 ELECT 100
F M 25V RA-2 OA10702520
CC67 /S
4822 122 31205 CER. 47pF J CH 50V BLK DD15470300
CC70 /S
CC73 ELECT 22
F 25V EA22602520
CC74 ELECT 22
F 25V EA22602520
CC75 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CC76 4822 122 30043 CER. 0.01
F Z 50V DK18103310
