Marantz SR-19EX - Page 57

83
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
CC81 4822 122 30043 CER. 0.01 F Z 50V DK18103310
CC82 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CC85 4822 126 10362 CER. 22pF
5% DA15220110
CC86 ELECT 22
F 25V EA22602520
CC87 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CC88 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CC95 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CL01 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL02 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL03 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL05 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL07 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL08 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL09 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL11
4822 124 22571 ELECT 10 F M 50V RA-2 OA10605020
CL22
CL23 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL24 9965 000 01040 ELECT 470
F M 6.3V RA-2 OA47700620
CL25
4822 124 22571 ELECT 10 F M 50V RA-2 OA10605020
CL31
CL32 9965 000 01040 ELECT 470
F M 6.3V RA-2 OA47700620
CL33 9965 000 01040 ELECT 470
F M 6.3V RA-2 OA47700620
CL34 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CL35 4822 124 41537 ELECT 220
F M 6.3V RA-2 OA22700620
CL36 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CL37 4822 124 90353 ELECT 100
F M 10V RA-2 OA10701020
CL38 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CL39 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CL40 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CL41 4822 124 90353 ELECT 100
F M 10V RA-2 OA10701020
CL42 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CL43 4822 124 41537 ELECT 220
F M 6.3V RA-2 OA22700620
CL44 4822 122 40617 CER. 0.1
F +80% -20% 50V DD38104010
CL45 4822 124 90353 ELECT 100
F M 10V RA-2 OA10701020
CL46 /C,/K,/S 4822 126 10362 CER. 22pF
5% DA15220110
CL47 /C,/K,/S 4822 126 11553 CER. 15pF
5% DA15150120
CL48 /C,/K,/S 4822 126 10362 CER. 22pF
5% DA15220110
CL48 /U 4822 122 33638 CER. 27pF
5% DA15270110
CL49 4822 126 11591 CER. 24pF J CH 50V BLK DD15240300
CL50 4822 126 10362 CER. 22pF
5% DA15220110
CL52 4822 124 41543 ELECT 1
F M 50V RA-2 OA10505020
CL53 4822 122 40617 CER. 0.1
F +80% -20% 50V DD38104010
CL54 4822 124 41537 ELECT 220
F M 6.3V RA-2 OA22700620
CL55 4822 124 41543 ELECT 1
F M 50V RA-2 OA10505020
CL56 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL57 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL58 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL59 9965 000 01040 ELECT 470
F M 6.3V RA-2 OA47700620
CL60 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL61 4822 124 90353 ELECT 100
F M 10V RA-2 OA10701020
CL62 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CL63 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CL64 4822 124 41537 ELECT 220
F M 6.3V RA-2 OA22700620
CL65 4822 122 40617 CER. 0.1
F +80% -20% 50V DD38104010
CL67 /U 4822 126 10362 CER. 22pF 5% DA15220110
CL68 4822 124 41543 ELECT 1
F M 50V RA-2 OA10505020
CL69 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL70 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CL71
4822 126 11558 CER. CER.0.1 F Z 50V DA17104110
CL74
CL75 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL79 4822 124 41543 ELECT 1
F M 50V RA-2 OA10505020
CL80 4822 122 30043 CER. 0.01
F Z 50V DK18103310
CL81 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL82 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL83 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL86 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL98 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL99 4822 122 30043 CER. 0.01
F Z 50V DK18103310
PL04-CAPACITORS(COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR
10% 50V :
CC51 CC52 CC57 CC58 CL51
CL76 CL77
ELECTROLYTIC CAPACITOR
20% : CC71 CC72
PLASTIC FILM CAPACITOR
5% 50V : CC79 CC80 CC83
CC84 CL78
PL04-RESISTORS(COMMON)
CARBON FILM FIXED RES.
5% 1/6W : RC51-RC54
RC57-RC64 RC66-RC79
RC83 RC86 RC87 RC89 RC91
RC93-RC97 RL02 RL04 RL06
RL08 RL10-RL15 RL18-RL26
RL28-RL32 RL39-RL43 RL51
RL52 RL54
PL04-RESISTORS
RL01 4822 111 41355 75
5% 1/6W GD05750160
RL03 4822 111 41355 75
5% 1/6W GD05750160
RL05 4822 111 41355 75
5% 1/6W GD05750160
RL07 4822 111 41355 75
5% 1/6W GD05750160
RL09 4822 111 41355 75
5% 1/6W GD05750160
PL04-SEMICONDUCTORS
DL07 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DL21 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DL22 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
QC51 IC OP-AMP NJM4580DD DUAL HC10112090
QC52 IC OP-AMP NJM4580DD DUAL HC10112090
QC71 IC NJM4580DD HC10112090
QC72 IC NJM4580DD HC10112090
QC73 IC NJM4580DD HC10112090
QC95 4822 209 63471 IC 74HC08 HC700800B0
QL01 9965 000 01371 IC MM1140XF HC10083550
QL02 IC BA7612N HC10201210
QL03 9965 000 01372 IC BA7649A G-1 VIDEO SW HC10179210
QL04 IC BA7613N HC10202210
QL05 9965 000 01372 IC BA7649A G-1 VIDEO SW HC10179210
QL06 IC BA7613N HC10202210
QL07 4822 209 16846 IC NJU3718L HC10171090
QL08 4822 209 32246 IC NJM2244
3IN SW 75 W DRIVER
HC10119090
QL09 IC OSD IC LC74781 HC10377030
QL10 /C,/K,/S 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
QL11 /C,/K,/S 4822 130 61189 DIG. TRS.
DTC114TS UN4215 10k
BA20004000
QL12 /C,/K,/S 4822 130 61189 DIG. TRS.
DTC114TS UN4215 10k
BA20004000
QL14 4822 209 32246 IC NJM2244
3IN SW 75 W DRIVER
HC10119090
