NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
FRONT PWB
(
CUP11896Z-8
)
CUP11896Z
FRONT BK91 ns
p
ns
p
BRACKET BRACKET FLT CMD1A468
FRONT BK92 ns
p
ns
p
BRACKET BRACKET FLT CMD1A468
FRONT BN91 ns
p
ns
p
CORD WIRE ASS'Y CWB2B909370EN
FRONT BN92 ns
p
ns
p
CORD WIRE, ASS'Y CWB1C904220BM
FRONT BN93 ns
p
ns
p
CORD WIRE ASS'Y CWB2B906070EN
FRONT BN94 ns
p
ns
p
CORD WIRE ASS'Y CWB2B902080EN
FRONT C901 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C902 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C903 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C904 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C905 ns
p
00MOA47605020 ELECT CAP. 47UF 50V CCEA1HH470T
FRONT C906 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C907 ns
p
00MOA47605020 ELECT CAP. 47UF 50V CCEA1HH470T
FRONT C909 90M-EX000210R 90M-EX000210R BIG ELECT CAP. 0.33UF CCESDX5R5V334U
FRONT C910 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C911 ns
p
ns
p
CER. CAP. 18PF 50V JC HCBS1H180JCT
FRONT C912 ns
p
ns
p
CER. CAP. 18PF 50V JC HCBS1H180JCT
FRONT C913 ns
p
00MOA22505020 ELECT CAP. 2.2UF 50V CCEA1HH2R2T
FRONT C914 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C915 ns
p
00MOA47605020 ELECT CAP. 47UF 50V CCEA1HH470T
FRONT C916 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C917 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C918 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C919 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C920
/
N1B ns
p
ns
p
CER. CAP. 1000PF 50V B HCBS1H102KBT
FRONT C920
/
N1S ns
p
ns
p
CER. CAP. 1000PF 50V B HCBS1H102KBT
FRONT C921
/
N1B ns
p
ns
p
CER. CAP. 39PF 50V J HCBS1H390JT
FRONT C921
/
N1S ns
p
ns
p
CER. CAP. 39PF 50V J HCBS1H390JT
FRONT C922
/
N1B ns
p
ns
p
CER. CAP. 39PF 50V J HCBS1H390JT
FRONT C922
/
N1S ns
p
ns
p
CER. CAP. 39PF 50V J HCBS1H390JT
FRONT C923
/
N1B ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
FRONT C923
/
N1S ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
FRONT C924
/
N1B ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C924
/
N1S ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C925
/
N1B ns
p
ns
p
CER. CAP. 1000PF 50V B HCBS1H102KBT
FRONT C925
/
N1S ns
p
ns
p
CER. CAP. 1000PF 50V B HCBS1H102KBT
FRONT C926
/
N1B ns
p
00MOA10601620 ELECT CAP. 10UF 16V CCEA1CH100T
FRONT C926
/
N1S ns
p
00MOA10601620 ELECT CAP. 10UF 16V CCEA1CH100T
FRONT C928
/
N1B ns
p
ns
p
CER. CAP. 560PF 50V KB HCBS1H561KBT
FRONT C928
/
N1S ns
p
ns
p
CER. CAP. 560PF 50V KB HCBS1H561KBT
FRONT C931 ns
p
ns
p
CER. CAP. 0.022UF 50V Z HCBS1H223ZFT
FRONT C932 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
FRONT C934 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
FRONT C935 ns
p
00MOA22505020 ELECT CAP. 2.2UF 50V CCEA1HH2R2T
FRONT C936 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C938 ns
p
ns
p
CER. CAP. 33PF 50V J HCBS1H330JT
FRONT C941 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
FRONT C942 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
FRONT CN95 ns
p
ns
p
CONN. 17P WAFER CARD CABLE CJP17GA117ZY
FRONT D901 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
FRONT D903
/
N1B 00MHD30511000 00MHD30511000 ZENER DIODE MTZJ5.1B CVDZJ5.1BT
FRONT D903
/
N1S 00MHD30511000 00MHD30511000 ZENER DIODE MTZJ5.1B CVDZJ5.1BT
FRONT D904 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
FRONT D905 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
FRONT D906 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
FRONT D907 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
FRONT D910 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
FRONT D911 00MHD30431000 00MHD30431000 ZENER DIODE MTZJ4.3B HVDMTZJ4.3BT
FRONT ET71 ns
p
ns
p
BRACKET BRACKET SHIELD CMD1A512
FRONT ET72 ns
p
ns
p
BUFFER STOPPER IR SENSOR CHG1A262
FRONT FIP1 90M-HQ300350R 90M-HQ300350R DISPLAY FLD SVA09MS10 HFLSVA09MS10
FRONT IC71 90M-HC109700R 90M-HC109700R IC NJM2595M VIDEO SW CVINJM2595MTE1
FRONT IC91 90M-HS13CWT0R 90M-HS13CWT0R U-PRO TMP87PM78FG, SR4021 CVITMP87PM78FG
FRONT IC92 90M-HW100650R 90M-HW100650R PHOTO UNIT RPM6936-H4 HRVRPM6936H4
FRONT IC93
/
N1B 90M-HC109710R 90M-HC109710R IC LC72723M PLL
(
RDS
)
HVILC72723M
FRONT IC93
/
N1S 90M-HC109710R 90M-HC109710R IC LC72723M PLL
(
RDS
)
HVILC72723M
31
