Marantz SR4021 - Page 30

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
MAIN J911 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J912 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J913 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J914 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J915 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J916 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J917 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J918 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J919 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J920 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J921 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J922 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J923 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J924 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J925 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J926 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J927 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J928 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J930 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN JK21 90M-YT003130R 90M-YT003130R TERMINAL CINCH 2P AUDIO CJJ4N034Z
MAIN JK22 90M-YT004010R 90M-YT004010R TERMINAL 6P AUDIO CJJ4R019W
MAIN JK23 90M-YT004010R 90M-YT004010R TERMINAL 6P AUDIO CJJ4R019W
MAIN JK24 90M-YT004010R 90M-YT004010R TERMINAL 6P AUDIO CJJ4R019W
MAIN JK25 90M-YT004010R 90M-YT004010R TERMINAL 6P AUDIO CJJ4R019W
MAIN L301 90M-LC107310R 90M-LC107310R COIL 0.5UH K CLEY0R5KAK
MAIN L302 90M-LC107310R 90M-LC107310R COIL 0.5UH K CLEY0R5KAK
MAIN Q201 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
MAIN Q202 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
MAIN Q205 90M-BA001450R 90M-BA001450R TRS. KRA107M HVTKRA107MT
MAIN Q301 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q302 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q303 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q304 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q305 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q306 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q307 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q308 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q309 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q310 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q311 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q312 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q313 90M-HT100540R 90M-HT100540R TRS. KTA1360Y HVTKTA1360Y
MAIN Q314 90M-HT100540R 90M-HT100540R TRS. KTA1360Y HVTKTA1360Y
MAIN Q315 90M-HT900100R 90M-HT900100R TRS. KTD600KGR HVTKTD600KGR
MAIN Q316 90M-HT900100R 90M-HT900100R TRS. KTD600KGR HVTKTD600KGR
MAIN Q317 90M-HT300820R 90M-HT300820R TRS. KTC3423Y HVTKTC3423Y
MAIN Q318 90M-HT300820R 90M-HT300820R TRS. KTC3423Y HVTKTC3423Y
MAIN Q319 90M-HT900110R 90M-HT900110R TRS. KTD2061Y HVTKTD2061Y
MAIN Q320 90M-HT900110R 90M-HT900110R TRS. KTD2061Y HVTKTD2061Y
MAIN Q321 90M-HT700080R 90M-HT700080R TRS. KTB1369Y HVTKTB1369Y
MAIN Q322 90M-HT700080R 90M-HT700080R TRS. KTB1369Y HVTKTB1369Y
MAIN Q323 90M-HT300930R 90M-HT300930R TRS. ! 2SC4468 HVT2SC4468
MAIN Q324 90M-HT300930R 90M-HT300930R TRS. ! 2SC4468 HVT2SC4468
MAIN Q325 90M-HT100680R 90M-HT100680R TRS. ! 2SA1695 HVT2SA1695
MAIN Q326 90M-HT100680R 90M-HT100680R TRS. ! 2SA1695 HVT2SA1695
MAIN Q327 00MHT327851H0 00MHT327851H0 TRS. KSC2785Y HVTKSC2785YT
MAIN Q328 00MHT327851H0 00MHT327851H0 TRS. KSC2785Y HVTKSC2785YT
MAIN Q381 90M-HT100390R 90M-HT100390R TRS. KSA1175Y HVTKSA1175YT
MAIN Q382 90M-BA001450R 90M-BA001450R TRS. KRA107M HVTKRA107MT
MAIN Q383 00MHT327851H0 00MHT327851H0 TRS. KSC2785Y HVTKSC2785YT
MAIN Q384 00MHT327851H0 00MHT327851H0 TRS. KSC2785Y HVTKSC2785YT
MAIN Q391 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
MAIN Q392 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
MAIN Q395 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
MAIN R201 ns
p
ns
p
RES. 220 OHM 1/5W J CRD20TJ221T
MAIN R202 ns
p
ns
p
RES. 220 OHM 1/5W J CRD20TJ221T
MAIN R203 ns
p
ns
p
RES. 220 OHM 1/5W J CRD20TJ221T
40
