Marantz SR4021 - Page 33

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
MAIN R346 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
MAIN R347 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
MAIN R348 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
MAIN R349 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
MAIN R350 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
MAIN R351 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
MAIN R352 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
MAIN R353 ns
p
ns
p
RES. 2.2 OHM 1/4W J CRD25TJ2R2T
MAIN R354 ns
p
ns
p
RES. 2.2 OHM 1/4W J CRD25TJ2R2T
MAIN R355 ns
p
ns
p
RES. 220 OHM 1/5W J CRD20TJ221T
MAIN R356 ns
p
ns
p
RES. 220 OHM 1/5W J CRD20TJ221T
MAIN R357 ns
p
ns
p
RES. 2.2 OHM 1/4W J CRD25TJ2R2T
MAIN R358 ns
p
ns
p
RES. 2.2 OHM 1/4W J CRD25TJ2R2T
MAIN R359 90M-GW000020R 90M-GW000020R RES. ! 0.22OHM
(
*2
)
, 5W CRF5EKR22HX2
MAIN R360 90M-GW000020R 90M-GW000020R RES. ! 0.22OHM
(
*2
)
, 5W CRF5EKR22HX2
MAIN R361 ns
p
ns
p
RES. 910 OHM 1/5W J CRD20TJ911T
MAIN R362 ns
p
ns
p
RES. 910 OHM 1/5W J CRD20TJ911T
MAIN R363 ns
p
ns
p
RES. 5.6K OHM 1/5W J CRD20TJ562T
MAIN R364 ns
p
ns
p
RES. 5.6K OHM 1/5W J CRD20TJ562T
MAIN R365 ns
p
ns
p
RES. 1.8K OHM 1/5W J CRD20TJ182T
MAIN R366 ns
p
ns
p
RES. 1.8K OHM 1/5W J CRD20TJ182T
MAIN R367 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
MAIN R368 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
MAIN R369 ns
p
ns
p
RES. 22 OHM 1/4W J CRD25TJ220T
MAIN R370 ns
p
ns
p
RES. 22 OHM 1/4W J CRD25TJ220T
MAIN R371 ns
p
ns
p
RES. 22 OHM 1/4W J CRD25TJ220T
MAIN R372 ns
p
ns
p
RES. 22 OHM 1/4W J CRD25TJ220T
MAIN R373 ns
p
ns
p
RES. METAL OXIDE FILM 10 OHM 1W CRG1ANJ100H
MAIN R374 ns
p
ns
p
RES. METAL OXIDE FILM 10 OHM 1W CRG1ANJ100H
MAIN R375 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
MAIN R376 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
MAIN R381 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473T
MAIN R382 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
MAIN R383 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
MAIN R384 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
MAIN R385 ns
p
ns
p
RES. 1.2K OHM 1/5W J CRD20TJ122T
MAIN R386 ns
p
ns
p
RES. 3.3K OHM 1/5W J CRD20TJ332T
MAIN R391 ns
p
ns
p
RES. METAL OXIDE FILM 10 OHM 1W CRG1ANJ100H
MAIN R392 ns
p
ns
p
RES. 10 OHM 1/5W J CRD20TJ100T
MAIN R393 ns
p
ns
p
RES. 10 OHM 1/5W J CRD20TJ100T
MAIN R401 ns
p
ns
p
RES. 39K OHM 1/4W J CRD25TJ393T
MAIN R402 ns
p
ns
p
RES. 39K OHM 1/4W J CRD25TJ393T
MAIN R403 ns
p
ns
p
RES. 39K OHM 1/4W J CRD25TJ393T
MAIN R404 ns
p
ns
p
RES. 39K OHM 1/4W J CRD25TJ393T
MAIN R405 ns
p
ns
p
RES. 15K OHM 1/4W J CRD25TJ153T
MAIN R406 ns
p
ns
p
RES. 15K OHM 1/4W J CRD25TJ153T
MAIN R407 ns
p
ns
p
RES. METAL OXIDE FILM 390 OHM 2W CRG2ANJ391H
MAIN R411 ns
p
ns
p
RES. 3.3K OHM 1/5W J CRD20TJ332T
MAIN R412 ns
p
ns
p
RES. 3.3K OHM 1/5W J CRD20TJ332T
MAIN R413 ns
p
ns
p
RES. 220 OHM 1/4W J CRD25TJ221T
MAIN R414 ns
p
ns
p
RES. 220 OHM 1/5W J CRD20TJ221T
MAIN R415 ns
p
ns
p
RES. METAL OXIDE FILM 390 OHM 2W CRG2ANJ391H
MAIN R419 ns
p
ns
p
RES. 39K OHM 1/5W J CRD20TJ393T
MAIN R420 ns
p
ns
p
RES. 39K OHM 1/5W J CRD20TJ393T
MAIN R421 ns
p
ns
p
RES. 10 OHM 1/4W J CRD25TJ100T
MAIN RY31 90M-LY000330R 90M-LY000330R RELAY OSA-SS-212DM3 HSL4A004ZU
MAIN RY32 90M-LY000330R 90M-LY000330R RELAY OSA-SS-212DM3 HSL4A004ZU
MAIN RY33 90M-LY000330R 90M-LY000330R RELAY OSA-SS-212DM3 HSL4A004ZU
MAIN SP31 90M-YT002990R 90M-YT002990R TERMINAL 8P SPEAKER CJJ5Q006Z
MAIN WF37 ns
p
ns
p
CONN. 13P WAFER CARD CABLE CJP13GA115ZY
MAIN WF95 ns
p
ns
p
CONN. 17P WAFER CARD CABLE CJP17GA117ZY
POWER 1 PWB
(
CUP11896Z-3
)
POWER1 BN35 ns
p
ns
p
CORD WIRE ASS'Y CWB3FB53150UP
POWER 2 PWB
(
CUP11896Z-2
)
POWER2 C101 00MOF15104040 00MOF15104040 FILM CAP. 0.1UF 50V J HCQI1H104JZT
POWER2 C102 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
POWER2 C103 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
43
