Marantz SR4021 - Page 35

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
VIDEO D706 00MHD30621000 00MHD30621000 ZENER DIODE MTZJ6.2B CVDZJ6.2BT
VIDEO D707 ns
p
90M-HD201730R DIODE 1N4003 CVD1N4003ST
VIDEO D708 ns
p
90M-HD201730R DIODE 1N4003 CVD1N4003ST
VIDEO D709 ns
p
90M-HD201730R DIODE 1N4003 CVD1N4003ST
VIDEO D710 ns
p
90M-HD201730R DIODE 1N4003 CVD1N4003ST
VIDEO D711 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
VIDEO D712 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
VIDEO D713 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
VIDEO D714 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
VIDEO DC15 90M-HI200020R 90M-HI200020R L.E.D. SIR-34ST3F BVDSIR34ST3F
VIDEO F701 ns
p
ns
p
CONN. HOLDER, FUSE KJCFC5S
VIDEO F702
/
U1B ns
p
90M-FS001070R FUSE ! AC250V T2.5AL KBA2D2500TLET
VIDEO F703 90M-FS001070R 90M-FS001070R FUSE ! AC250V T2.5AL KBA2D2500TLET
VIDEO IC16 90M-HW100690R 90M-HW100690R PHOTO UNIT RPM674CBR-S BRVRPM6936
VIDEO J234 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VIDEO J238 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VIDEO J330 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VIDEO J338 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VIDEO J341 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VIDEO J343 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VIDEO J352
/
U1B ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VIDEO J353
/
U1B ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VIDEO J428 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VIDEO J813 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VIDEO J814 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VIDEO JK71 90M-YT002940R 90M-YT002940R TERMINAL CINCH 3P YELLOW SILVER CJJ4S010Z
VIDEO JK72 90M-YT002940R 90M-YT002940R TERMINAL CINCH 3P YELLOW SILVER CJJ4S010Z
VIDEO JK73 90M-YT003120R 90M-YT003120R TERMINAL CINCH 2P
(
GOLD
)
REMOTE CJJ4N036Z
VIDEO JK74 90M-YT004860R 90M-YT004860R TERMINAL 3.5MM JACK STEREO CJJ2D008Z
VIDEO OL91
/
N1B 90M-YT002430R 90M-YT002430R TERMINAL ! A302D0061P AC
(
EUR/1P
)
KJJ7A022Z
VIDEO OL91
/
N1S 90M-YT002430R 90M-YT002430R TERMINAL ! A302D0061P AC
(
EUR/1P
)
KJJ7A022Z
VIDEO OL91
/
U1B ns
p
90M-YT002410R TERMINAL ! A204D0041P AC
(
UL/2P/SEP
)
KJJ7A015Z
VIDEO Q112 00MBA10001000 00MBA10001000 TRS. KRA102M HVTKRA102MT
VIDEO Q701 90M-HT800040R 90M-HT800040R TRS. ! KSC2316Y HVTKSC2316YT
VIDEO Q702 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
VIDEO R396 ns
p
ns
p
RES. 200 OHM 1/5 W CRD20TJ201T
VIDEO R397 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
VIDEO R398 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
VIDEO R408 ns
p
ns
p
RES. 200 OHM 1/5 W CRD20TJ201T
VIDEO R701 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750T
VIDEO R702 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750T
VIDEO R703 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750T
VIDEO R704 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750T
VIDEO R705 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750T
VIDEO R706 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750T
VIDEO R708 ns
p
ns
p
RES. 390 OHM CRG2ANJ391H
VIDEO R710 ns
p
ns
p
RES. 390 OHM CRG2ANJ391H
VIDEO R713 ns
p
ns
p
RES. 2.2 OHM 1/4W J CRD25TJ2R2T
VIDEO R714 ns
p
ns
p
RES. 2.7K OHM 1/5W J CRD20TJ272T
VIDEO R716
/
U1B ns
p
90M-GG000010R RES. ! 3.3M OHM 1/10W J HRDERC12UGK335T
VIDEO R719 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473T
VIDEO R720 ns
p
ns
p
RES. 47 OHM 1/5W J CRD20TJ470T
VIDEO RY71 00MLY10090010 00MLY10090010 RELAY ! SDT-S-109DMR HSL1D016ZE
VIDEO T701
/
N1B 90M-TS001940R 90M-TS001940R TRANSF. ! SUB SR5400
(
6400
)
/N1 CLT5I002ZE
VIDEO T701
/
N1S 90M-TS001940R 90M-TS001940R TRANSF. ! SUB SR5400
(
6400
)
/N1 CLT5I002ZE
VIDEO T701
/
U1B ns
p
90M-TS001970R TRANSF. ! SUB SR5400
(
6400
)
/U1 CLT5I002ZU
45
