49 50
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS. NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
1 /A1B/N1B 26AW248010 26AW248010 FRONT PANEL FRONT PANEL (BLACK) ON/OFF FKV8.081.282
1 /U1B nsp 26AW248110 FRONT PANEL FRONT PANEL (BLACK) ON/STANDBY FKV8.081.282BKU
1 GOLD nsp 26AW248020 FRONT PANEL FRONT PANEL (GOLD) ON/OFF FKV8.081.282GD
1 SILVER 26AW248030 26AW248030 FRONT PANEL FRONT PANEL (SILVER) ON/OFF FKV8.081.282SR
2 BLACK,
GOLD
09AW158010 09AW158010 WINDOW WINDOW FKV8.647.221
2 SILVER 09AW158030 09AW158030 WINDOW WINDOW (SILVER) FKV8.647.314
3 BLACK 09AW270030 09AW270030 BUTTON KEY POWER (BLACK) FKV8.335.216BK
3 GOLD nsp 09AW270130 BUTTON KEY POWER (GOLD) FKV8.335.216GD
3 SILVER 09AW270230 09AW270230 BUTTON KEY POWER (SILVER) FKV8.335.216SR
4 BLACK 09AW270040 09AW270040 BUTTON KEY MEMO (BLACK) FKV8.335.218BK
4 GOLD nsp 09AW270150 BUTTON KEY MEMO (GOLD) FKV8.335.218GD
4 SILVER 09AW270140 09AW270140 BUTTON KEY MEMO (SILVER) FKV8.335.218SR
5 BLACK 09AW270050 09AW270050 BUTTON KEY TUNING (BLACK) FKV8.335.217BK
5 GOLD nsp 09AW270150 BUTTON KEY TUNING (GOLD) FKV8.335.217GD
5 SILVER 09AW270250 09AW270250 BUTTON KEY TUNING (SILVER) FKV8.335.217SR
6 BLACK 09AW270010 09AW270010 BUTTON KEY FUNC 5 (BLACK) FKV8.335.214BK
6 GOLD nsp 09AW270110 BUTTON KEY FUNC 5 (GOLD) FKV8.335.214GD
6 SILVER 09AW270210 09AW270210 BUTTON KEY FUNC 5 (SILVER) FKV8.335.214SR
7 BLACK 09AW270020 09AW270020 BUTTON KEY FUN 9 (BLACK) FKV8.335.215BK
7 GOLD nsp 09AW270120 BUTTON KEY FUN 9 (GOLD) FKV8.335.215GD
7 SILVER 09AW270220 09AW270220 BUTTON KEY FUN 9 (SILVER) FKV8.335.215SR
8 09AW355010 09AW355010 LENS INDICATOR FKV8.640.098
9 09AW271010 09AW271010 HOLDER PCB HOLDER FKV8.078.052
10 BLACK 27AW154110 27AW154110 KNOB AL KNOB (BLACK) FKV8.337.290
10 GOLD nsp 27AW154120 KNOB AL KNOB (GOLD) FKV8.337.290GD
10 SILVER 27AW154130 27AW154130 KNOB AL KNOB (SILVER) FKV8.337.290SR
11 BLACK,
GOLD
183J057010 183J057010 LEG LEG REAR FKV8.085.033
11 BLACK,
GOLD
183J057110 183J057110 LEG LEG FRONT FKV8.085.034
11 SILVER 183J057030 183J057030 LEG LEG REAR (SILVER) FKV8.085.043
11 SILVER 183J057130 183J057130 LEG LEG FRONT (SILVER) FKV8.085.044
12 BLACK,
GOLD
24AW251010 24AW251010 BADGE MARANTZ BADGE FKV8.807.174
12 SILVER 24AW251020 24AW251020 BADGE MARANTZ BADGE (SILVER) FKV8.807.174SR
13 nsp nsp HEATSINK HEATSINK MAIN FKV7.308.083
14 nsp nsp HEATSINK LITTLE HEATSINK WE FKV7.308.033
15 nsp nsp HOLDER HOLDER 1 FKV8.038.289
16 nsp nsp HOLDER HOLDER 2 FKV8.038.290
17 nsp nsp HOLDER HOLDER 3 FKV8.038.355
18 nsp nsp HOLDER HOLDER VFD FKV8.038.297
19 /A/K/N nsp nsp HOLDER HOLDER POWER SWITCH FKV8.038.296
20 nsp nsp HOLDER HOLDER PHONE JACK FKV8.038.295
21 nsp nsp HOLDER HOLDER FRONT L FKV8.038.293
22 nsp nsp HOLDER HOLDER FRONT R FKV8.038.294
23 nsp nsp HOLDER HOLDER TRANSFORMER FKV8.038.292
25 nsp nsp CASE BOTTOM PANEL FKV8.031.101
26 /N1B nsp nsp REAR PANEL REAR PANEL /N1B FKV8.040.500
26 /N1S nsp nsp REAR PANEL REAR PANEL /N1S FKV8.040.502
26 /U1B nsp nsp REAR PANEL REAR PANEL /U1B FKV8.040.503
26 /K1S nsp nsp REAR PANEL REAR PANEL /K1S FKV8.040.504
26 /K1G nsp nsp REAR PANEL REAR PANEL /K1G FKV8.040.505
26 /A1S nsp nsp REAR PANEL REAR PANEL /A1S FKV8.040.506
26 /A1B nsp nsp REAR PANEL REAR PANEL /A1B FKV8.040.507
27 nsp nsp SHEET POWER TR SHEET FKV7.840.014
28 nsp nsp BUFFER VFD BUFFER FKV8.817.490
29 /A/K/N *YJ002640R *YJ002640R TERMINAL MAINS INLET VJJ0911EI
E1 /U nsp *YC000720R CORD MAINS CORD 200CM VJA20050021
TRN901 /A/N *TS001810R *TS001810R TRANSF POWER TRANSF. 230AC 50HZ VTPAT7203
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
TRN901 /K nsp *TS001820R TRANSF POWER TRANSF. 220AC 50HZ VTPAT7213
TRN901 /U nsp *TS001830R TRANSF POWER TRANSF. 120AC 60HZ VTPAT7223
Wire
JFF101
-JFN702
nsp nsp CORD CONNECTIVE WIRE 7PIN 2.5MM 480MM UL VJP07XH48001TE
JFF103
-JS1
nsp nsp CORD CONNECTIVE WIRE 4PIN 2.0MM 100MM UL VJP04PH10001TE
JFF104
-JFL1
nsp nsp CORD CONNECTIVE WIRE 4PIN 2.0MM 120MM UL VJP04PH12001TE
JFK01
-JFS05
nsp nsp CORD CONNECTIVE WIRE 9PIN 2.0MM 200MM UL VJP09PH20001TE
JFN102
-JW104
nsp nsp CORD CONNECTIVE WIRE 5PIN 2.5MM 280MM UL VJP05XH28001TE
JFN509
-JFM04
nsp nsp CORD CONNECTIVE WIRE 4PIN 4.0MM 210MM UL VJP04VH21001E
JFN510
-JFM02
nsp nsp CORD CONNECTIVE WIRE 3PIN 4.0MM 180MM UL VJP03VH18001E
JFN511
-JFM03
nsp nsp CORD CONNECTIVE WIRE 3PIN 4.0MM 250MM UL VJP03VH25001E
JFN512
-JFM05
nsp nsp CORD CONNECTIVE WIRE 2PIN 2.0MM 240MM UL VJP02PH24001E
JFN601
-JH01
nsp nsp CORD CONNECTIVE WIRE 4PIN 2.0MM 470MM UL VJP04PH47001PE
JFS01
-JFK02
nsp nsp CORD CONNECTIVE WIRE 11PIN 2.0MM 80MM UL VJP11PH08001PE
JFS03
-JFM01
nsp nsp CORD CONNECTIVE WIRE 12PIN 2.0MM 60MM UL VJP12PH06001E
JFS06
-JFN508
nsp nsp CORD CONNECTIVE WIRE 10PIN 2.5MM 180MM UL VJP10XH18001TE
JFS09
-TUNER
MODULE
/K/U nsp *YU001210R FFC CABLE FLEXIBLE FLAT CORD 15P/1.25MM 140MM VWJ15140001
JFS09
-TUNER
MODULE
/A/N nsp *YU001110R FFC CABLE FLEXIBLE FLAT CORD 17P/1.25MM 140MM VWJ17140001
JFS10
-JFN101
nsp *YU001100R FFC CABLE FLEXIBLE FLAT CORD 16P/1.25MM 160MM VWJ16160001
JFS11
-JFF102
nsp *YU001090R FFC CABLE FLEXIBLE FLAT CORD 15P/1.25MM 320MM VWJ15320001
JFV101
-JFS08
nsp nsp CORD CONNECTIVE WIRE 5PIN 2.0MM 230MM UL VJP05PH23001E
JFV201
-JFN507
nsp nsp CORD CONNECTIVE WIRE 3PIN 2.0MM 380MM UL VJP03PH38001E
JW101
-MAINS
INLET
/A/K/N nsp nsp CORD CONNECTIVE WIRE 2PIN 8.0MM 130MM UL VJP02TH13002E
JW102
-JP1
/A/K/N nsp nsp CORD CONNECTIVE WIRE 2PIN 8.0MM 430MM UL VJP02TH43001E
PACKING
ZK27AW0010 ZK27AW0010 UNIT KIT REMOTE CONTROLLER RC5400SR VURRC129
/K nsp 26AW851350 USER GUIDE USER GUIDE SR4400 ENG. CIN. FKV2.804.194SS2
/U nsp 26AW851250 USER GUIDE USER GUIDE SR4400 4LANG. FKV2.804.194SS4
/A/N 26AW851310 26AW851310 USER GUIDE USER GUIDE SR4400 9LANG, FKV2.804.194ss9
E1 /K nsp *ZC000200R CORD MAINS CORD 180CM VJA180100102
E1 /N *ZC000220R *ZC000220R CORD MAINS CORD 180CM VJA1801400103
E1 /A nsp *ZC000210R CORD MAINS CORD 180CM VJA180400104
NOT STANDARD SPARE PARTS
/A/N/U nsp 26AW801010 CASE PACKING CASE FKV4.172.961
/K nsp 26AW801110 CASE PACKING CASE FKV4.172.961K
nsp 09AW809010 CUSHION CUSHION L FKV8.870.211
nsp 09AW809020 CUSHION CUSHION R FKV8.870.212
24 BLACK nsp 09AW257010 LID TOP COVER (BLACK) FKV8.040.386BK
24 GOLD nsp 09AW257110 LID TOP COVER (GOLD) FKV8.040.386GD
24 SILVER nsp 09AW257210 LID TOP COVER (SILVER) FKV8.040.386SR
