POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
SW01 /U nsp *YJ002620R CONNECTOR OUTLET VJJ0921E
T1 /A/N *TS001760R *TS001760R TRANSF INPUT;230VAC50HZ VTPAT5003
T1 /K nsp *TS001770R TRANSF INPUT:220VAC50HZ VTPAT5013
T1 /U nsp *TS001780R TRANSF INPUT:120VAC60HZ VTPAT5023
STANDBY LED PCB
DF1 *HI101030R *HI101030R LED ODIGPR2703
J1 nsp nsp JUMPER WIRE JPL0000
J2 nsp nsp JUMPER WIRE JPL0000
J3 nsp nsp JUMPER WIRE JPL0000
J4 nsp nsp JUMPER WIRE JPL0000
JF1 nsp nsp CONNECTOR 4pin, 2.0mm, UL VJS04PH01E
SURROUND PCB
JFS1 nsp nsp CONNECTOR 4pin, 2.0mm, UL VJS04PH11E
RFS1 nsp nsp RES. 10kΩ, 1/6W ERD16TJ103T
RFS2 nsp nsp RES. 10kΩ, 1/6W ERD16TJ103T
RFS3 nsp nsp RES. 10kΩ, 1/6W ERD16TJ103T
RFS4 nsp nsp RES. 10kΩ, 1/6W ERD16TJ103T
SWS1 *SR000210R *SR000210R ENCODER EVAR1612E25D112CP
TUNER MODULE
/A/N *AV000250R *AV000250R TUNER AM/FM TUNER KST-MB114LA1-0 TUNMB114LA10
/K nsp *AV000240R TUNER AM/FM TUNER KST-MB014MA1-0 TUNMB014MA10
/U nsp *AV000230R TUNER AM/FM TUNER KST-MB014MA0-0 TUNMB014MA00
VIDEO PCB
CV101 nsp OA47502550 ELECT. CAP 4.7µF, 16V ECEA1CAE4R7MB
CV102 nsp OA47502550 ELECT. CAP 4.7µF, 16V ECEA1CAE4R7MB
CV103 nsp OA47502550 ELECT. CAP 4.7µF, 16V ECEA1CAE4R7MB
CV104 nsp OA47502550 ELECT. CAP 4.7µF, 16V ECEA1CAE4R7MB
CV105 nsp DD95470300 CHIP CAP. 50V, 47pF ECUV1H470JCN
CV106 nsp DD95470300 CHIP CAP. 50V, 47pF ECUV1H470JCN
CV107 nsp OA47701020 ELECT. CAP 470µF, 6.3v ECEA0JQE471MB
CV108 nsp DD95470300 CHIP CAP. 50V, 47pF ECUV1H470JCN
CV109 nsp OA10602550 ELECT. CAP 16V, 10µF ECEA1CAE100MB
CV111 nsp OA10602550 ELECT. CAP 16V, 10µF ECEA1CAE100MB
CV112 nsp OA10701620 ELECT. CAP 16V, 100µF ECEA1CAE101MB
CV113 nsp DK96104300 CHIP CAP. 50V, 0.1µF ECUV1H104ZFN
CV114 nsp OA10602550 ELECT. CAP 16V, 10µF ECEA1CAE100MB
CV115 nsp OA10602550 ELECT. CAP 16V, 10µF ECEA1CAE100MB
CV116 nsp OA47701020 ELECT. CAP 470µF, 6.3v ECEA0JQE471MB
CV121 nsp OA47701020 ELECT. CAP 470µF, 6.3v ECEA0JQE471MB
CV122 nsp OA10701620 ELECT. CAP 16V, 100µF ECEA1CAE101MB
CV123 nsp DK96104300 CHIP CAP. 50V, 0.1µF ECUV1H104ZFN
CV124 nsp DK96104300 CHIP CAP. 50V, 0.1µF ECUV1H104ZFN
CV152 nsp OA10602550 ELECT. CAP 16V, 10µF ECEA1CAE100MB
CV153 nsp DK96103300 CHIP CAP. 50V, 0.01µF ECUV1H103KBN
CV154 nsp DK96103300 CHIP CAP. 50V, 0.01µF ECUV1H103KBN
CV155 nsp OA10602550 ELECT. CAP 16V, 10µF ECEA1CAE100MB
CV156 nsp DK96103300 CHIP CAP. 50V, 0.01µF ECUV1H103KBN
CV169 nsp DK96103300 CHIP CAP. 50V, 0.01µF ECUV1H103KBN
CV172 nsp DK96104300 CHIP CAP. 50V, 0.1µF ECUV1H104ZFN
CV173 nsp DK96104300 CHIP CAP. 50V, 0.1µF ECUV1H104ZFN
CV174 nsp DK96102300 CHIP CAP. 50V, 1000pF ECUV1H102KBN
CV175 nsp DK96102300 CHIP CAP. 50V, 1000pF ECUV1H102KBN
CV176 nsp DK96102300 CHIP CAP. 50V, 1000pF ECUV1H102KBN
CV177 nsp DK96102300 CHIP CAP. 50V, 1000pF ECUV1H102KBN
CV186 nsp DD95470300 CHIP CAP. 50V, 47pF ECUV1H470JCN
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
