Marantz SR5300 - SR6300 Parts List

POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
1 322W158040 322W158040 WINDOW FL 5077210573040
2 GOLD 313W154510 313W154510 KNOB VOLUME (GOLD) 5080210448010
2 BLACK 313W154500 313W154500 KNOB VOLUME (BLACK) 5080210448000
3 168W251010 168W251010 BADGE MARANTZ 563704097802A
4 /K nsp 15AW248120 PANEL FRONT AL(GOLD) FOR /K 3067210638040
4 /N1G 15AW248120 15AW248120 PANEL FRONT AL(GOLD) FOR /N 3067210638030
4 /N1B 15AW248020 15AW248020 PANEL FRONT AL(BLACK) FOR /N 3067210638020
4 /U nsp 15AW248010 PANEL FRONT AL(BLACK) FOR /U 3067210638010
5 322W355010 322W355010 INDICATOR ACRYL MILK/LED 5160210063000
6 GOLD 322W053110 322W053110 DECORATION CAP (GOLD) 5127210151010
6 BLACK 322W053010 322W053010 DECORATION CAP (BLACK) 5127210151000
7 322W303010 322W303010 FILTER COVER LED 5200210102000
8 GOLD 322W105120 322W105120 BODY PANEL FRONT MOLD (GOLD) 3417210081010
8 BLACK 322W105020 322W105020 BODY PANEL FRONT MOLD (BLACK) 3417210081000
9 GOLD 322W270140 322W270140 BUTTON MUTE/SPEAKERS A B (GOLD) 5097211281010
9 BLACK 322W270040 322W270040 BUTTON MUTE/SPEAKERS A B (BLACK) 5097211281000
10 GOLD 322W270130 322W270130 BUTTON MODE F/P (GOLD) 5097211291010
10 BLACK 322W270030 322W270030 BUTTON MODE F/P (BLACK) 5097211291000
11 GOLD 322W270120 322W270120 BUTTON TUNING/PRESET (GOLD) 5097211301010
11 BLACK 322W270020 322W270020 BUTTON TUNING/PRESET (BLACK) 5097211301000
12 GOLD 322W270150 322W270150 BUTTON DIMMER/SLEEP etc (GOLD) 5097211311010
12 BLACK 322W270050 322W270050 BUTTON DIMMER/SLEEP etc (BLACK) 5097211311000
13 GOLD 322W270160 322W270160 BUTTON TV/DVD etc (GOLD) 5097211321010
13 BLACK 322W270060 322W270060 BUTTON TV/DVD etc (BLACK) 5097211321000
14 GOLD 322W270110 322W270110 BUTTON POWER (GOLD) 5097211271010
14 BLACK 322W270010 322W270010 BUTTON POWER (BLACK) 5097211271000
15 nsp nsp P.C.B SUB ASSY ST-BY LED 7028061873010
16 /U nsp nsp P.C.B SUB ASSY POWER SW FOR /U 7028061874010
16 /K/N nsp nsp P.C.B SUB ASSY POWER SW FOR /K/N 7028061878010
17 /K/N *SP001160R *SP001160R SW PUSH POWER SDDL-005-S G000122006030
18 /K/N nsp nsp BRACKET POWER 4010210876000
19 /K/N nsp nsp P.C.B SUB ASSY HEAD PHONE 7028060774010
19 /U nsp nsp P.C.B SUB ASSY HEAD PHONE 7028061879010
20 *YT002550R *YT002550R JACK HEADPHONE D6.5-9P G402040221930
21 nsp nsp P.C.B SUB ASSY M-CONTROL 7028061872010
22 *SR000190R *SR000190R SW ENCODER EC16B12S00D4-ZZZ G121161200010
23 nsp nsp P.C.B SUB ASSY FRONT 7028061871010
24 *YT002830R *YT002830R TERMINAL CINCH JACK RCA 3P G606040320000
25 *YT002530R *YT002530R JACK C40160250N / S-VIDEO 1P D6.5 G402041810000
26 *SR000200R *SR000200R SW ENCODER EC16B24T01D4-ZZZ G121162401400
27 *HW100630R *HW100630R REMOTE IR RPM7136-H4 36.0KHZ IR SENSOR (RMC301) E940713640000
28 nsp nsp HOLDER FL-TUBE 4320210091010
29 *HQ300570R *HQ300570R DISPLAY FLT HNA-15MM25 130*33.5 GRN,ORG (FIP301) K530152500010
30 nsp nsp P.C.B SUB ASSY AMP 7028061891010
31 nsp nsp BRACKET HEATSINK 4010056906010
32 nsp nsp HEAT SINK FOR POWER TR. 2120210278000
33 nsp nsp CHASSIS ASSY 3208210276300
34 322W057010 322W057010 FOOT HOT STAMPING 4007040241030
35 nsp nsp P.C.B SUB ASSY GUIDE LEFT 7028061886010
36 nsp nsp P.C.B SUB ASSY GUIDE RIGHT 7028061887010
37 nsp nsp SPACER MAIN PCB SUPPORT 4300040561010
38 nsp nsp P.C.B SUB ASSY MAIN 7028061861010
39 nsp nsp HEAT SINK 46(W) X 60(H) 2120043538020
40 nsp nsp HEAT SINK 46(W) X 70(H) 2120043538050
41 GOLD nsp nsp CABINET TOP COVER (GOLD) 3007210076030
41 BLACK nsp nsp CABINET TOP COVER (BLACK) 3007210076010
42 nsp nsp CUSHION BUFFER RS-717 4050045669010
43 /K nsp *AV000200R TUNER BOARD ASSY FM/AM KST-M9014MA1-7 E900901410040
43 /N *AV000210R *AV000210R TUNER BOARD ASSY FM/MW KST-M9014MA1-7 E900901410040
43 /U nsp *AV000220R TUNER BOARD ASSY FM/AM KST-M9014MA0-7 E900901400040
44 nsp nsp P.C.B SUB ASSY VOLUME 7028061881010
45 *YT001600R *YT001600R TERMINAL CINCH JACK / JK0400450N RCA 4PIN G602040045000
46 *YT002650R *YT002650R TERMINAL CINCH JACK / JK060046EN RCA 6PIN G603600460050
47 nsp nsp P.C.B SUB ASSY DSP 7028061901010
48 *YT002730R *YT002730R TERMINAL CINCH JACK RCA 2PIN G601200099060
49 *YT002720R *YT002720R TERMINAL CINCH JACK RCA 2PIN G601200099070
50 *YT002570R *YT002570R MODULE GP1FA502RZ / OPT. RX E100150200020
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
51 *YT002580R *YT002580R MODULE GP1FA502TZ / OPT. TX E100150200030
52 nsp nsp P.C.B SUB ASSY INPUT 2 7028061876010
53 *YT002640R *YT002640R TERMINAL CINCH JACK / JK060046CN RCA 6PIN G603060046020
54 *YT002600R *YT002600R TERMINAL CINCH JACK / JK020044HN RCA 2PIN G601020044300
55 nsp nsp P.C.B SUB ASSY INPUT1 7028061875010
56 *YT001600R *YT001600R TERMINAL CINCH JACK / JK0400450N RCA 4PIN G602040045000
57 *YT002640R *YT002640R TERMINAL CINCH JACK / JK060046CN RCA 6PIN G603060046020
58 nsp nsp P.C.B SUB ASSY VIDEO 7028061884010
59 *YT002610R *YT002610R TERMINAL CINCH JACK / JC0200095N RCA 2PIN G601200092020
60 *YT002630R *YT002630R TERMINAL CINCH JACK / JC030012FN RCA 3PIN G606300125040
61 nsp nsp P.C.B SUB ASSY S-VIDEO 7028061883010
62 *YT002540R *YT002540R JACK YKF51-5516 / S-VIDEO 2P D6.5 G402042190000
63 *YT002560R *YT002560R JACK YKF51-5512 / S-VIDEO 3P DIN G403040010010
64 nsp nsp P.C.B SUB ASSY SPEAKR 7028061882010
65 *YT001290R *YT001290R SPEAKER TERMINAL BOARD SCREW 8P / SH0810360P G61408103600A
66 *YT002590R *YT002590R SPEAKER TERMINAL BOARD SCREW 4P / SH0410370P G612041037320
67 nsp nsp BUSHING FOR SPEAKER TERMINAL 2410040353010
68 nsp nsp P.C.B SUB ASSY SPEAKR B 7028061885010
69 *YT002780R *YT002780R TER BOARD SCREW 4P SPEAKER TERMINAL/SH0410770P G612040290000
70 nsp nsp BUSHING FOR SPEAKER TERMINAL 2410040353010
71 nsp nsp P.C.B SUB ASSY POWER 7028061885010
72 /K/N *YT002820R *YT002820R SOCKET AC OUTLET YKE31-0090 G435040110000
72 /U nsp *YT002810R SOCKET AC OUTLET CCT1304-0212 G435040070000
73 /K nsp *TS001730R TRANSFORMER MAINS FOR /K 8200111710140
73 /N *TS001740R *TS001740R TRANSFORMER MAINS FOR /N 8200111710130
73 /U nsp *TS001750R TRANSFORMER MAINS FOR /U 8200111710120
74 /K nsp nsp CHASSIS REAR PANEL FOR SR6300/K1G 3207210726340
74 /N1G nsp nsp CHASSIS REAR PANEL FOR SR6300/N1G 3207210726330
74 /N1B nsp nsp CHASSIS REAR PANEL FOR SR6300/N1B 3207210726320
74 /U nsp nsp CHASSIS REAR PANEL FOR SR6300/U1B 3208210276310
75 /U/K nsp 323W259030 STOPPER CORD HOLDER 4380040162010
72 /K nsp *ZC000140R CORD ASSY MAINS WITH CORE FOR K L068000970030
72 /U nsp *ZC000150R CORD ASSY MAINS WITH CORE FOR U L068020030080
S1 nsp nsp SCREW TAP TITE +2S 3*8 B-TYPE ZNY/BH B020030081B10
S2 nsp nsp SCREW TAP TITE +2S 3*8 B-TYPE BK/FH B020030083F10
S3 nsp nsp SCREW TAP TITE 3X18 B-TYPE ZNY/BH B020030181B10
S4 nsp nsp SCREW TAP TITE ASSY +3S 4*10 P+S-WASHER ZNY/BH B028940101B10
S5 nsp nsp SCREW TAP TITE +2S 4*8 B-TYPE Bsbm/BH B020040086B10
S6 nsp nsp SCREW TAP TITE +2S 3*16 P+S-WASHER ZNY/HH 1507041146010
S7 nsp nsp SCREW TAP TITE +2S 3*10 B-TYPE(DOT)BH Bsbm B020030106B11
S8 nsp nsp SCREW TAP TITE +2S 3*8 ZNY WASHER 1500001456010
PACKING
- ZK15AW0010 ZK15AW0010 REMOTE CONTROLLER RC7300SR 8300030010010
- /N *ZC000230R *ZC000230R MAINS CORD FOR /N L061000000020
- /K nsp 15AW851350 INSTRUCTION MANUAL USER GUIDE FOR /K 5707210480060
- /N 15AW851310 15AW851310 INSTRUCTION MANUAL USER GUIDE FOR /N 5707210480050
- /U nsp 15AW851250 INSTRUCTION MANUAL USER GUIDE FOR /U 5707210480040
NOT STANDARD SPARE PARTS
- /N/U nsp nsp PACKING CASE FOR SR6300 6017210020200
- /K nsp nsp PACKING CASE FOR SR6300 /K 6017210020201
- /U nsp nsp CARD WARRANTY (USA) 5777200120011
- /U nsp nsp CARD WARRANTY (CANADA) 5777200120021
- /N nsp nsp CARD IMPORTANT 5777200120051
- nsp nsp CUSHION SNOW R956(A) EPS WHITE 6230210134000
- nsp nsp PE SHEET FILM SOFT PE 6320040052010
- nsp nsp ANTENNA AM LOOP E601010000000
- nsp nsp ANTENNA WIRE DIPOLE E605010010000
- /U nsp nsp FM ANTENA ADAPTER FOR /U L109284007400
- /K/N nsp nsp FM ANTENA ADAPTER FOR /K/N L109284007300
- nsp nsp BATTERY DRY LR6(1.5V)AA G670001R50010
SR6300 SR6300
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS. NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
57 58
