Marantz SR5300 - Page 41

63
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR5300
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
AMP PCB
- nsp nsp CN,WIRE 80MM/10P 5264-10=5395-10 RD1007#20 2.5MM L000800100030
- nsp nsp CN,WIRE 80MM/9P 5264-09=5395-09 RD1007#20 2.5MM L000800090020
C201xx nsp OA47505020 CAP.E.GENERIC 4.7µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247978110
C202xx nsp nsp C,CERAMIC HIK AXIAL B330pF-K/50V-52RE D005331277520
C203xx nsp nsp C,CERAMIC HIK AXIAL B0.001µF-K/50V-52RE D005102177530
C204xx nsp OA22605020 CAP.E.GENERIC 22µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211222078110
C205xx nsp OA22605020 CAP.E.GENERIC 22µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211222078110
C206xx nsp OA22701020 CAP.E.GENERIC 220µF/10V(M) 6.3x11,P=5(LUXON-GR) 85,2000H N211222128110
C209xx nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C210xx nsp *OA000090R CAP.E.GENERIC 47µF/100V(M) 10x15,P=5(LUXON-GR) 85,2000H N2112470C8110
C211xx nsp *OA000090R CAP.E.GENERIC 47µF/100V(M) 10x15,P=5(LUXON-GR) 85,2000H N2112470C8110
C212xx nsp nsp C,CERAMIC HIK DISC F0.022µF-Z/50V-5RE D004223597050
C214xx nsp nsp C,CERAMIC T.C AXIAL SL4.7pF-K/50V-52RE D0014R7077530
C215xx nsp nsp C,CERAMIC HIK AXIAL B100pF-K/50V-52RE D005101177520
CP201 nsp nsp CN.WAFER 2.0MM GIL-S-12P-S2T2-EF L101220120000
D202xx nsp *HD201720R D,SWITCHING 1N4148-52RE 75V 150MA DO-34 (MIC) K000414803520
D203xx nsp *HD201720R D,SWITCHING 1N4148-52RE 75V 150MA DO-34 (MIC) K000414803520
J201
nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
J277
L201xx nsp nsp COIL,FILTER-INDUCTOR INDUCTOR COIL J9000031 D330900001320
Q201xx
*HT100590R *HT100590R SEMI,TR/GE PNP 2SA KSA992F,0.5W/TO92-REEL J5000992F0050
Q204xx
Q205xx *HT300860R *HT300860R SEMI,TR/GE NPN 2SC KSC1845F,0.5W/TO92-REEL J5021845F0000
Q206xx *HT300860R *HT300860R SEMI,TR/GE NPN 2SC KSC1845F,0.5W/TO92-REEL J5021845F0000
Q207xx *HT100590R *HT100590R SEMI,TR/GE PNP 2SA KSA992F,0.5W/TO92-REEL J5000992F0050
Q208xx *HT100640R *HT100640R SEMI,TR/GE PNP 2SA KTA1024Y,1W/TO92L-REEL J5001024Y0050
Q209xx *HT300920R *HT300920R SEMI,TR/GE NPN 2SC KTC3206Y,1W/TO92L-REEL J5023206Y0050
Q213xx *HT200410R *HT200410R SEMI TR/GE PNP 2SB SAP16PY 150W LF550(5P) POWER Tr. J501151000010
Q214xx *HT400480R *HT400480R SEMI TR/GE NPN 2SD SAP16NO 150W LF550(5P) POWER Tr. J503151000010
Q215xx *HT300860R *HT300860R SEMI,TR/GE NPN 2SC KSC1845F,0.5W/TO92-REEL J5021845F0000
R201xx nsp nsp R,CARBON FILM 470-J,1/5W-52RE-AX C00004716P520
R202xx nsp nsp R,CARBON FILM 33K-J,1/5W-52RE-AX C00003336P520
R203xx nsp nsp R,CARBON FILM 15-J,1/5W-52RE-AX C00001506P520
R204xx nsp nsp R,CARBON FILM 15-J,1/5W-52RE-AX C00001506P520
R205xx nsp nsp R,CARBON FILM 750-J,1/5W-52RE-AX C00007516P520
R206xx nsp nsp R,CARBON FILM 750-J,1/5W-52RE-AX C00007516P520
R207xx nsp nsp R,CARBON FILM 470-J,1/5W-52RE-AX C00004716P520
R208xx nsp nsp R,CARBON FILM 68-J,1/5W-52RE-AX C00006806P520
R209xx nsp nsp R,CARBON FILM 150-J,1/5W-52RE-AX C00001516P520
R210xx nsp nsp R,CARBON FILM 10K-J,1/5W-52RE-AX C00001036P520
R211xx nsp nsp R,CARBON FILM 43K-J,1/5W-52RE-AX C00004336P520
R212xx nsp nsp R,CARBON FILM 1.3K-J,1/5W-52RE-AX C00001326P520
R213xx nsp nsp R,CARBON FILM 33K-J,1/5W-52RE-AX C00003336P520
R214xx
nsp nsp R,CARBON FILM 560-J,1/5W-52RE-AX C00005616P520
R220xx
R221xx nsp nsp R,CARBON FILM 82-J,1/5W-52RE-AX C00008206P520
R222xx nsp nsp R,CARBON FILM 82-J,1/5W-52RE-AX C00008206P520
R223xx nsp nsp R,CARBON FILM 22K-J,1/5W-52RE-AX C00002236P520
R224xx nsp nsp R,CARBON FILM 22K-J,1/5W-52RE-AX C00002236P520
R225xx nsp nsp R,CARBON FILM 4.7-J,1/5W-52RE-AX C0004R706P520
R228xx nsp nsp R,METAL FILM 100PPM 220-J,1/4W-R.REEL C060022163050
R229xx nsp nsp R,METAL FILM 100PPM 220-J,1/4W-R.REEL C060022163050
R231xx nsp nsp R,CARBON FILM 4.7-J,1/5W-52RE-AX C0004R706P520
R232xx nsp nsp R,CARBON FILM 4.7-J,1/5W-52RE-AX C0004R706P520
R233xx nsp nsp R,CARBON FILM 10K-J,1/5W-52RE-AX C00001036P520
R235xx nsp nsp R,CARBON FILM 10K-J,1/5W-52RE-AX C00001036P520
R236xx nsp nsp R,CARBON FILM 2.2K-J,1/5W-52RE-AX C00002226P520
R237xx
nsp nsp R,CARBON FILM 39-J,1/5W-52RE-AX C00003906P520
R240xx
