Marantz SR5300 - Page 46

68
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR5300
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
WIRE701 nsp nsp CN,WIRE 160MM/1P B1813TOP-2=B1813TOP-2GRN1015#18 L000161010010
XTAL701 *JX000970R *JX000970R CRYSTAL 12.288MHZ,HC49U CL=20pF STRIGHT LEAD/REEL E80012R288070
FRONT PCB
FIP301 *HQ300570R *HQ300570R DISPLAY,FLT HNA-15MM25 130*33.5 GRN,ORG /R963 K530152500010
- nsp nsp HOLDER D-M2(L)ABS BK/FLT 4320210091010
VOL301 *SR000200R *SR000200R SW,ENCODER EC16B24T01D4-ZZZ G121162401400
JACK301 *YT002830R *YT002830R TER,RCA 3PIN JACK RCA 3P(FRONT-YWR)/JC03W0191G G606040320000
C301 nsp OA47601050 CAP.E.GENERIC 47µF/10V(M) 5X11,P=5(LUXON-GR) 85,2000H N211247028110
C302 nsp nsp C,CERAMIC HIK AXIAL F0.022µF-Z/25V-52RE D005223594520
C303 nsp nsp C,CERAMIC HIK AXIAL F0.047µF-Z/50V-52RE D005473597520
C304 nsp nsp C,CERAMIC HIK AXIAL B100pF-K/50V-52RE D005101177520
C305 nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C306 nsp nsp C,CERAMIC HIK AXIAL F0.047µF-Z/50V-52RE D005473597520
C307 nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C308 nsp nsp C,CERAMIC HIK AXIAL F0.022µF-Z/25V-52RE D005223594520
C309 nsp nsp C,CERAMIC HIK AXIAL B100pF-K/50V-52RE D005101177520
C310 nsp nsp C,CERAMIC HIK AXIAL F0.047µF-Z/50V-52RE D005473597520
C311 nsp nsp C,CERAMIC HIK AXIAL B100pF-K/50V-52RE D005101177520
C312 nsp nsp C,CERAMIC HIK AXIAL B100pF-K/50V-52RE D005101177520
C313 nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C314 nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C315 nsp nsp C,CERAMIC HIK AXIAL B820pF-K/50V-52RE D005821287520
C316 nsp nsp C,CERAMIC HIK AXIAL B820pF-K/50V-52RE D005821287520
C317 nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C318
nsp nsp C,CERAMIC HIK AXIAL B100pF-K/50V-52RE D005101177520
C321
C322 nsp nsp C,CERAMIC HIK AXIAL F0.1µF-Z/50V-52RE D005104597530
C323 nsp nsp C,CERAMIC HIK AXIAL F0.1µF-Z/50V-52RE D005104597530
CNT301 nsp nsp CN,WIRE 450/9 B2011-9=GILS-3,2,4 WH2547#26+BK1533#26 L000451090030
CNT303 nsp nsp CN,WIRE 100MM/4P 9073-04=9073-04 WH1007#26 L000101040060
CNT304 nsp nsp CN,WIRE 470MM/5P GILS-5=9073-5 WH1007#26 L000471050010
CNT305 nsp nsp CN,WIRE 80/3P GILS-03=9073-03 RD1007#26 L000800030030
D301 nsp *HD201720R D,SWITCHING 1N4148-52RE 75V 150MA DO-34 (MIC) K000414803520
D315 *HI101020R *HI101020R LED,ROUND LED SLR-34URCF25 K500032101120
D316M *HI101020R *HI101020R LED,ROUND LED SLR-34URCF25 K500032101120
D317 nsp *HD201720R D,SWITCHING 1N4148-52RE 75V 150MA DO-34 (MIC) K000414803520
D318 *HI101020R *HI101020R LED,ROUND LED SLR-34URCF25 K500032101120
D319 *HI101020R *HI101020R LED,ROUND LED SLR-34URCF25 K500032101120
D320 *HI101020R *HI101020R LED,ROUND LED SLR-34URCF25 K500032101120
D328 *HD301990R *HD301990R D,ZENER MTZJ11B-0.5W/5MA-52MM K06011R044520
D332
nsp *HD201720R D,SWITCHING 1N4148-52RE 75V 150MA DO-34 (MIC) K000414803520
D337
FPC101B nsp nsp CN.FPC 1.25MM 52492-2320 23P BOTTOM ENTRY L131524922320
IC301 *HC107290R *HC107290R IC,LINEAR-DRIVER LC75721E/QIP64 J127757210010
J301
nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
J341
JACK381 *YT002530R *YT002530R JACK,D6.5 C40160250N G402041810000
L302 nsp nsp COIL,FILTER-INDUCTOR 10UH-Q40/24M-R2.5-52RE 02TB D330100700520
Q301 *BA001190R *BA001190R SEMI,BRT/NPN RC KRC107M,0.4W/TO92M-REEL J6020107M0010
Q302 *BA001200R *BA001200R SEMI,BRT/PNP RA KRA111M,0.4W/TO92M-REEL J6000111M0010
Q303M
*BA001190R *BA001190R SEMI,BRT/NPN RC KRC107M,0.4W/TO92M-REEL J6020107M0010
Q308
Q309 *HT700050R *HT700050R SEMI,TR/GE NPN 2SC KTC3200BL,0.6W/TO92-REEL J5023200B0050
R301 nsp nsp R,CARBON FILM 68K-J,1/5W-52RE-AX C00006836P520
R302 nsp nsp R,CARBON FILM 68K-J,1/5W-52RE-AX C00006836P520
R303 nsp nsp R,CARBON FILM 330-J,1/5W-52RE-AX C00003316P520
R304 nsp nsp R,CARBON FILM 100-J,1/5W-52RE C00001016P520
R305 nsp nsp R,CARBON FILM 120-J,1/5W-52RE-AX C00001216P520
R306 nsp nsp R,CARBON FILM 150-J,1/5W-52RE-AX C00001516P520
