71
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR5300
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
R448A
nsp nsp R,CARBON FILM 470K-J,1/5W-52RE-AX C00004746P520
R453A
R517
nsp nsp R,CARBON FILM 470-J,1/5W-52RE-AX C00004716P520
R522
R535 nsp nsp R,CARBON FILM 47-J,1/5W-52RE-AX C00004706P520
ST/BY LED PCB
D303 *HI101020R *HI101020R LED,ROUND LED SLR-34URCF25 K500032101120
ST-BY SW PCB
J320
/U nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
J323
SW325 /U nsp *SP000900R SW,TACT SKHV10920A,5MM/260G-REEL G180000270010
POWER SW PCB
CNT401 /A/K/N nsp nsp CN,WIRE 500MM 2P 35156-03,JE201-03 BK1617#22 7.92 L000501020020
SW401 /A/K/N *SP001160R *SP001160R SW,PUSH SDDL-005-S G000122006030
MULTI-CONTROL PCB
C371 nsp nsp C,CERAMIC HIK AXIAL B820pF-K/50V-52RE D005821287520
C372 nsp nsp C,CERAMIC HIK AXIAL B820pF-K/50V-52RE D005821287520
CN305 nsp nsp CN.WAFER 2.0MM GIL-S-03P-S2L2-EF L101220030010
MVOL302 *SR000190R *SR000190R SW,ENCODER EC16B12S00D4-ZZZ 12PULSE/360' G121161200010
H/P PCB
C464
nsp nsp C,CERAMIC HIK AXIAL Y0.01µF-M/16V-52RE D005103773530
C467
CNT122B nsp nsp CN,WIRE 570MM/4P 5264-04=51088-04 RD1007#22 L000571040010
JACK404 *YJ002580R *YJ002580R JACK,D6.5 JACK PHONE 9P H20980060G G402041940010
R536 nsp nsp R,METAL FILM 100PPM RES MF 330 2W 5% C060033166520
R537 nsp nsp R,METAL FILM 100PPM RES MF 330 2W 5% C060033166520
WIRE401 nsp nsp RING,TER WIRE 200MM/1P 61640BS-2(PI3.2)=B1812TOP-2 BK 8410201010030
VOLTAGE SEL PCB
- /K nsp nsp SUPPORTER AVR1601(KE2) KIFCO(PS801) /P.C. 4070210192000
- /K nsp nsp SPACER AVC1500(N) NYLON66 MPS-10-0/CARD 4300210062000
CN951 /K nsp nsp CN.WAFER 3.96MM 35328-0510 L104353280500
CN953 /K nsp nsp CN.WAFER 7.92MM 35979-0320 3P ANGLE L108359790320
CNT711 /K nsp nsp CN,WIRE 120MM/2P 35191-02=210-03 BK1617#22 7.92 L000121020050
F913 /K nsp *FS000960R FUSE GLASS 20MM T6.3A /250V-SVBRTC(K) 218 N751226301110
F913A /K nsp nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010
F913B /K nsp nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010
J901
/K nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
J907
JK912 /K nsp *SS000720R SW,SLIDE 3C2P,ESD26832A AC250V/5A G060268320010
MAIN PCB
- /U nsp nsp P.C.B SR6300/U 330*247 1.6T FR1 /MAIN 7020061860000
BEAD101
*FC500010R *FC500010R BEAD,COIL BAS3580T0 3.5PHI*8 52RE 7610035800020
BEAD105
C135
nsp nsp C,CERAMIC HIK AXIAL F0.1µF-Z/50V-52RE D005104597530
C148
C148A nsp nsp C,CERAMIC HIK AXIAL B0.001µF-K/50V-52RE D005102177530
C152 nsp nsp C,CERAMIC HIK AXIAL B100pF-K/50V-52RE D005101177520
C153 /A/N nsp nsp C,CERAMIC HIK AXIAL F0.1µF-Z/50V-52RE D005104597530
C157 /A/N nsp nsp C,CERAMIC HIK AXIAL B270pF-K/50V-52RE D005271277520
