Marantz SR5300 - Page 51

73
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR5300
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
CNT119 nsp nsp CN,WIRE 420MM/4P GIL-S-4=9073-4 WH1007#26 L000421040010
D101
nsp *HD201570R D,SWITCHING IN4007 52REEL 1000V 1A K000400700520
D105
D106 *HE200300R *HE200300R D,RECTIFIER BRIDGE KBPC604 6A K047604000020
D107 *HE200300R *HE200300R D,RECTIFIER BRIDGE KBPC604 6A K047604000020
D108 nsp *HD201570R D,SWITCHING IN4007 52REEL 1000V 1A K000400700520
D109 nsp *HD201570R D,SWITCHING IN4007 52REEL 1000V 1A K000400700520
D110 nsp *HD201720R D,SWITCHING 1N4148-52RE 75V 150MA DO-34 (MIC) K000414803520
D110A nsp *HD201720R D,SWITCHING 1N4148-52RE 75V 150MA DO-34 (MIC) K000414803520
D111 nsp *HD201570R D,SWITCHING IN4007 52REEL 1000V 1A K000400700520
D112
nsp *HD201720R D,SWITCHING 1N4148-52RE 75V 150MA DO-34 (MIC) K000414803520
D129
FPC101 *YU000930R *YU000930R CABLE FLAT CARD FPC23P FPC101A&FPC101B L301241230010
FPC101A nsp nsp CN.FPC 1.25MM 8370-231 23P ST L131837002300
GND101
nsp nsp TERMINAL ALL PBST/GND PLATE-REEL 3790040876010
GND107
IC101 HC38915090 HC38915090 IC,LINEAR-REGULATOR MC7815CT TO220 (ON SEMI)(METAL TYPE) J126781500070
IC102 *HC300200R *HC300200R IC,LINEAR-REGULATOR KIA7915PI,20W-TO220IS MOLD J126791500030
IC103 HC38905090 HC38905090 IC,LINEAR-REGULATOR MC7805CT TO220 (ON SEMI)(METAL TYPE) J126780500380
IC104 HC38905090 HC38905090 IC,LINEAR-REGULATOR MC7805CT TO220 (ON SEMI)(METAL TYPE) J126780500380
IC105 *HC300190R *HC300190R IC,LINEAR-REGULATOR KIA7905PI,20W-TO220IS MOLD J126790500070
IC106 *HC400020R *HC400020R IC,LOGIC CD4094BCN DIP16 /8BIT SHIFT REGISTER J040409400050
IC107 *HU100610R *HU100610R IC,CPU CXP740010-163Q DWP586 QFP100 /SR5300 J020740010163
IC108 /A/N *HC107330R *HC107330R IC,ANALOG TDA7330BD-SOP20P /RDS DEMODULATOR J080733000010
J101
nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
J300
Q101 *HT100340R *HT100340R SEMI,TR/GE PNP 2SA KTA1268BL,0.3W/TO92-REEL J5001268B0050
Q102 *HT700050R *HT700050R SEMI,TR/GE NPN 2SC KTC3200BL,0.6W/TO92-REEL J5023200B0050
Q103 *HT100340R *HT100340R SEMI,TR/GE PNP 2SA KTA1268BL,0.3W/TO92-REEL J5001268B0050
Q104 *HT100340R *HT100340R SEMI,TR/GE PNP 2SA KTA1268BL,0.3W/TO92-REEL J5001268B0050
Q105 *HT700050R *HT700050R SEMI,TR/GE NPN 2SC KTC3200BL,0.6W/TO92-REEL J5023200B0050
Q106 *HT100340R *HT100340R SEMI,TR/GE PNP 2SA KTA1268BL,0.3W/TO92-REEL J5001268B0050
Q107 *HT700050R *HT700050R SEMI,TR/GE NPN 2SC KTC3200BL,0.6W/TO92-REEL J5023200B0050
Q108
*BA001190R *BA001190R SEMI,BRT/NPN RC KRC107M,0.4W/TO92M-REEL J6020107M0010
Q113
Q115 *HT700050R *HT700050R SEMI,TR/GE NPN 2SC KTC3200BL,0.6W/TO92-REEL J5023200B0050
Q116 *HT700050R *HT700050R SEMI,TR/GE NPN 2SC KTC3200BL,0.6W/TO92-REEL J5023200B0050
Q117 *HT100340R *HT100340R SEMI,TR/GE PNP 2SA KTA1268BL,0.3W/TO92-REEL J5001268B0050
Q118 *HT100340R *HT100340R SEMI,TR/GE PNP 2SA KTA1268BL,0.3W/TO92-REEL J5001268B0050
Q119 *HT700050R *HT700050R SEMI,TR/GE NPN 2SC KTC3200BL,0.6W/TO92-REEL J5023200B0050
Q120 *HT700050R *HT700050R SEMI,TR/GE NPN 2SC KTC3200BL,0.6W/TO92-REEL J5023200B0050
Q122 *BA001210R *BA001210R SEMI,BRT/PNP RA KRA102M,0.3W/TO92M-REEL J6002202M0010
Q123 *BA001180R *BA001180R SEMI,BRT/NPN RC KRC102M,0.4W/TO92M-REEL J6020102M0010
Q124 *BA001210R *BA001210R SEMI,BRT/PNP RA KRA102M,0.3W/TO92M-REEL J6002202M0010
Q128 *BA001210R *BA001210R SEMI,BRT/PNP RA KRA102M,0.3W/TO92M-REEL J6002202M0010
Q129 *BA001180R *BA001180R SEMI,BRT/NPN RC KRC102M,0.4W/TO92M-REEL J6020102M0010
Q130 *BA001190R *BA001190R SEMI,BRT/NPN RC KRC107M,0.4W/TO92M-REEL J6020107M0010
Q131
*BA001420R *BA001420R SEMI,BRT/PNP RA DTA114YS,0.3W/TO92M-REEL J6000114Y0010
Q135
Q136 *HT100590R *HT100590R SEMI,TR/GE PNP 2SA KSA992F,0.5W/TO92-REEL J5000992F0050
R101
nsp nsp R,METAL FILM 100PPM 0.22-J,1W-R.REEL C060R22065050
R104
R105xx nsp nsp R,METAL FILM 100PPM 10-J,2W-52RE-AX C060010066520
R107 nsp nsp R,CARBON FILM 2.2K-J,1/5W-52RE-AX C00002226P520
R108 nsp nsp R,CARBON FILM 2.2K-J,1/5W-52RE-AX C00002226P520
R109 nsp nsp R,CARBON FILM 560K-J,1/5W-52RE-AX C00005646P520
R110 nsp nsp R,CARBON FILM 3.6K-J,1/5W-52RE-AX C00003626P520
