Marantz SR5300 - Page 53

75
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR5300
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
R188 /A/N nsp nsp R,CARBON FILM 47K-J,1/5W-52RE-AX C00004736P520
R189 nsp nsp R,CARBON FILM 10K-J,1/5W-52RE-AX C00001036P520
R190 nsp nsp R,CARBON FILM 10K-J,1/5W-52RE-AX C00001036P520
R191 /A/N nsp nsp R,CARBON FILM 560-J,1/5W-52RE-AX C00005616P520
R192 nsp nsp R,CARBON FILM 47K-J,1/5W-52RE-AX C00004736P520
R193 nsp nsp R,METAL FILM 100PPM 3.3-J,1W-52RE-AX C0603R3065520
R194
nsp nsp R,CARBON FILM 10K-J,1/5W-52RE-AX C00001036P520
R198
R199 nsp nsp R,CARBON FILM 1K-J,1/5W-52RE-AX C00001026P520
R200 nsp nsp R,CARBON FILM 47K-J,1/5W-52RE-AX C00004736P520
R202 nsp nsp R,METAL FILM 100PPM 100-J,1/4W-R.REEL C060010163050
RLY101 *LY000290R *LY000290R RELAY RSB24S 24V 2A30VDC /SMALL SIGNAL G680240202010
RLY102
LY20240490 LY20240490 RELAY G5PA-28 24V 5A G680240502020
RLY106
XTAL101 *FQ000530R *FQ000530R RESONATOR,CERAMIC CST12.0MTW-TF01/REEL CSTLA12M0T55-A0 E830120000050
XTAL102 /A/N *JX001000R *JX001000R CRYSTAL 4.332MHZ;CL=20.8pF HC49U STRIGHT LEAD E8004R3320080
ZD121 HD30511000 HD30511000 D,ZENER MTZJ5.1B-0.5W/5MA-52MM K06005R144520
ZD122 HD30511000 HD30511000 D,ZENER MTZJ5.1B-0.5W/5MA-52MM K06005R144520
ZD129 /A/N HD30511000 HD30511000 D,ZENER MTZJ5.1B-0.5W/5MA-52MM K06005R144520
PROCESSOR PCB
C515xx nsp DD95101300 C,CERAMIC CHIP T.C COG100pF-J/50V-1608REEL D010101167160
C528xx nsp OA22505020 CAP.E.GENERIC 2.2µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211222978110
C528SW nsp OA47505020 CAP.E.GENERIC 4.7µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247978110
C533xx nsp DD95101300 C,CERAMIC CHIP T.C COG100pF-J/50V-1608REEL D010101167160
C533SW nsp DK96122300 C,CERAMIC CHIP HIK X7R1200pF-K/50V-1608REEL D01112277716C
C541xx nsp DD95101300 C,CERAMIC CHIP T.C COG100pF-J/50V-1608REEL D010101167160
C543 nsp DK96104300 C,CERAMIC CHIP HIK X7R0.1µF-K/50V-1608REEL D011104577160
C544 nsp DK96104300 C,CERAMIC CHIP HIK X7R0.1µF-K/50V-1608REEL D011104577160
C545xx nsp OA47505020 CAP.E.GENERIC 4.7µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247978110
C546xx nsp OA47505020 CAP.E.GENERIC 4.7µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247978110
C552
nsp DK96104300 C,CERAMIC CHIP HIK X7R0.1µF-K/50V-1608REEL D011104577160
C556
C557
nsp OA47602520 CAP.E.GENERIC 47µF/25V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247048110
C560
C561
nsp DK96104300 C,CERAMIC CHIP HIK X7R0.1µF-K/50V-1608REEL D011104577160
C564
C565 nsp OA47602520 CAP.E.GENERIC 47µF/25V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247048110
C566 nsp OA47602520 CAP.E.GENERIC 47µF/25V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247048110
C567 nsp DK96104300 C,CERAMIC CHIP HIK X7R0.1µF-K/50V-1608REEL D011104577160
C568 nsp DK96104300 C,CERAMIC CHIP HIK X7R0.1µF-K/50V-1608REEL D011104577160
C571xx nsp OA47505020 CAP.E.GENERIC 4.7µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247978110
C576
nsp DD95101300 C,CERAMIC CHIP T.C COG100pF-J/50V-1608REEL D010101167160
C584
C585 nsp DK96104300 C,CERAMIC CHIP HIK X7R0.1µF-K/50V-1608REEL D011104577160
C586 nsp DK96104300 C,CERAMIC CHIP HIK X7R0.1µF-K/50V-1608REEL D011104577160
C587 nsp OA10602550 CAP.E.GENERIC 10µF/25V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210048110
C588 nsp OA10602550 CAP.E.GENERIC 10µF/25V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210048110
C589 nsp OA47601640 CAP.E.GENERIC 47µF/16V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247038110
C590 nsp OA47601640 CAP.E.GENERIC 47µF/16V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247038110
C591 nsp DD95470300 C,CERAMIC CHIP T.C COG47pF-J/50V-1608REEL D010470167160
C592 nsp DD95470300 C,CERAMIC CHIP T.C COG47pF-J/50V-1608REEL D010470167160
C593 nsp DK96104300 C,CERAMIC CHIP HIK X7R0.1µF-K/50V-1608REEL D011104577160
C594 nsp DK96104300 C,CERAMIC CHIP HIK X7R0.1µF-K/50V-1608REEL D011104577160
C595 nsp DD95470300 C,CERAMIC CHIP T.C COG47pF-J/50V-1608REEL D010470167160
C596 nsp DD95470300 C,CERAMIC CHIP T.C COG47pF-J/50V-1608REEL D010470167160
