86
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR6300
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
R170 nsp nsp R,CARBON FILM 100K-J,1/5W-52RE-AX C00001046P520
R171 nsp nsp R,CARBON FILM 47K-J,1/5W-52RE-AX C00004736P520
R172 /K/N nsp nsp R,CARBON FILM 10K-J,1/5W-52RE-AX C00001036P520
R173 /K nsp nsp R,CARBON FILM 15K-J,1/5W-52RE-AX C00001536P520
R173 /N/U nsp nsp R,CARBON FILM 47K-J,1/5W-52RE-AX C00004736P520
R183 /K/U nsp nsp R,CARBON FILM 47K-J,1/5W-52RE-AX C00004736P520
R182 /N nsp nsp R,CARBON FILM 2.2M-J,1/5W-52RE-AX C00002256P520
R174 nsp nsp R,CARBON FILM 47K-J,1/5W-52RE-AX C00004736P520
R176 nsp nsp R,CARBON FILM 47K-J,1/5W-52RE-AX C00004736P520
R177 nsp nsp R,CARBON FILM 470K-J,1/5W-52RE-AX C00004746P520
R178 nsp nsp R,CARBON FILM 100-J,1/5W-52RE C00001016P520
R179 nsp nsp R,CARBON FILM 47K-J,1/5W-52RE-AX C00004736P520
R181 nsp nsp R,CARBON FILM 10K-J,1/5W-52RE-AX C00001036P520
R187 /N nsp nsp R,CARBON FILM 47K-J,1/5W-52RE-AX C00004736P520
R188 /N nsp nsp R,CARBON FILM 47K-J,1/5W-52RE-AX C00004736P520
R191 /N nsp nsp R,CARBON FILM 560-J,1/5W-52RE-AX C00005616P520
XTAL102 /N *JX001000R *JX001000R CRYSTAL 4.332MHZ;CL=20.8pF HC49U E8004R3320080
ZD129 /N HD30511000 HD30511000 D,ZENER MTZJ5.1B-0.5W/5MA-52MM K06005R144520
R184 nsp nsp R,CARBON FILM 10K-J,1/5W-52RE-AX C00001036P520
R185 nsp nsp R,CARBON FILM 100K-J,1/5W-52RE-AX C00001046P520
R186 nsp nsp R,CARBON FILM 100K-J,1/5W-52RE-AX C00001046P520
R189 nsp nsp R,CARBON FILM 10K-J,1/5W-52RE-AX C00001036P520
R190 nsp nsp R,CARBON FILM 10K-J,1/5W-52RE-AX C00001036P520
R192 nsp nsp R,CARBON FILM 47K-J,1/5W-52RE-AX C00004736P520
R193 nsp nsp R,METAL FILM 100PPM 3.3-J,1W-52RE-AX C0603R3065520
R194
nsp nsp R,CARBON FILM 10K-J,1/5W-52RE-AX C00001036P520
R198
R199 nsp nsp R,CARBON FILM 1K-J,1/5W-52RE-AX C00001026P520
R200 nsp nsp R,CARBON FILM 47K-J,1/5W-52RE-AX C00004736P520
R202 nsp nsp R,METAL FILM 100PPM 100-J,1/4W-R.REEL C060010163050
RLY102
LY20240490 LY20240490 RELAY G5PA-28 24V 5A G680240502020
RLY106
XTAL101 *FQ000530R *FQ000530R RESONATOR,CERAMIC CST12.0MTW-TF01/REEL CSTLA12M0T55-A0 E830120000050
ZD121 HD30511000 HD30511000 D,ZENER MTZJ5.1B-0.5W/5MA-52MM K06005R144520
ZD122 HD30511000 HD30511000 D,ZENER MTZJ5.1B-0.5W/5MA-52MM K06005R144520
FRONT PCB
FIP301 *HQ300570R *HQ300570R DISPLAY,FLT HNA-15MM25 130*33.5 GRN,ORG /R963 K530152500010
- nsp nsp HOLDER D-M2(L) ABS BK/FLT 4320210091010
VOL301 *SR000200R *SR000200R SW,ENCODER EC16B24T01D4-ZZZ G121162401400
JACK382 *YT002830R *YT002830R TER,RCA 3PIN JACK RCA 3P(FRONT-YWR)/JC03W0191G G606040320000
C301 nsp OA47601050 CAP.E.GENERIC 47µF/10V(M) 5X11,P=5(LUXON-GR) 85,2000H N211247028110
C302 nsp nsp C,CERAMIC HIK AXIAL F0.022µF-Z/25V-52RE D005223594520
C303 nsp nsp C,CERAMIC HIK AXIAL F0.047µF-Z/50V-52RE D005473597520
C304 nsp nsp C,CERAMIC HIK AXIAL B100pF-K/50V-52RE D005101177520
C305 nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C306 nsp nsp C,CERAMIC HIK AXIAL F0.047µF-Z/50V-52RE D005473597520
C307 nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C308 nsp nsp C,CERAMIC HIK AXIAL F0.022µF-Z/25V-52RE D005223594520
C309 nsp nsp C,CERAMIC HIK AXIAL B100pF-K/50V-52RE D005101177520
C310 nsp nsp C,CERAMIC HIK AXIAL F0.047µF-Z/50V-52RE D005473597520
C311 nsp nsp C,CERAMIC HIK AXIAL B100pF-K/50V-52RE D005101177520
C312 nsp nsp C,CERAMIC HIK AXIAL B100pF-K/50V-52RE D005101177520
C313 nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C314 nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C315 nsp nsp C,CERAMIC HIK AXIAL B820pF-K/50V-52RE D005821287520
C316 nsp nsp C,CERAMIC HIK AXIAL B820pF-K/50V-52RE D005821287520
C317 nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C318
nsp nsp C,CERAMIC HIK AXIAL B100pF-K/50V-52RE D005101177520
C321
C322 nsp nsp C,CERAMIC HIK AXIAL F0.1µF-Z/50V-52RE D005104597530
To Next Page
