89
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR6300
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
R475 nsp nsp R,CARBON FILM 4.7-J,1/5W-52RE-AX C0004R706P520
R481
nsp nsp R,CARBON FILM 470K-J,1/5W-52RE-AX C00004746P520
R484
R487
nsp nsp R,CARBON FILM 150-J,1/5W-52RE-AX C00001516P520
R490
R495
nsp nsp R,CARBON FILM 470K-J,1/5W-52RE-AX C00004746P520
R498
R503 nsp nsp R,CARBON FILM 1K-J,1/5W-52RE-AX C00001026P520
R504 nsp nsp R,CARBON FILM 1K-J,1/5W-52RE-AX C00001026P520
R505 nsp nsp R,CARBON FILM 1K-J,1/5W-52RE-AX C00001026P520
INPUT2 PCB
C448
/K/N nsp nsp C,CERAMIC HIK AXIAL B100pF-K/50V-52RE D005101177520
C453
C462 nsp nsp C,CERAMIC HIK AXIAL Y0.01µF-M/16V-52RE D005103773530
C463A nsp nsp C,CERAMIC HIK AXIAL F0.1µF-Z/50V-52RE D005104597530
C468 nsp nsp C,CERAMIC HIK AXIAL F0.1µF-Z/50V-52RE D005104597530
C599 nsp nsp C,CERAMIC HIK AXIAL F0.1µF-Z/50V-52RE D005104597530
CP112 nsp nsp CN.WAFER 2.0MM TUC-P14X-B1 BD-TO-BD 14P HOUSING ST L101100031410
D501 nsp *HD201720R D,SWITCHING 1N4148-52RE 75V 150MA DO-34 (MIC) K000414803520
D502 nsp *HD201720R D,SWITCHING 1N4148-52RE 75V 150MA DO-34 (MIC) K000414803520
J465 nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
J467 nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
J501
nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
J520
JACK501 *YT002640R *YT002640R TER,RCA 6PIN DAERYUNG/JK060046CN(+2GND G603060046020
JACK502 *YT002600R *YT002600R TER,RCA 2PIN DAERYUNG/JK020044HN G601020044300
R448A
nsp nsp R,CARBON FILM 470K-J,1/5W-52RE-AX C00004746P520
R453A
R517
nsp nsp R,CARBON FILM 470-J,1/5W-52RE-AX C00004716P520
R522
R535 nsp nsp R,CARBON FILM 47-J,1/5W-52RE-AX C00004706P520
ST/BY LED PCB
D303 *HI101020R *HI101020R LED,ROUND LED SLR-34URCF25 K500032101120
ST-BY S/W PCB
SW325 /U nsp *SP001140R SW,TACT SKHV10920A,5MM/260G-REEL G180000270010
J321
/U nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
J320
POWER SW PCB
CNT401 /K/N nsp nsp CN,WIRE 500MM 2P 35156-03,JE201-03 BK1617#22 7.92 L000501020020
SW401 /K/N *SP001160R *SP001160R SW,PUSH SDDL-005-S G000122006030
MULTI-CONTROL PCB
C371 nsp nsp C,CERAMIC HIK AXIAL B820pF-K/50V-52RE D005821287520
C372 nsp nsp C,CERAMIC HIK AXIAL B820pF-K/50V-52RE D005821287520
CN305 nsp nsp CN.WAFER 2.0MM GIL-S-03P-S2L2-EF L101220030010
MVOL302 *SR000190R *SR000190R SW,ENCODER EC16B12S00D4-ZZZ 12PULSE/360' G121161200010
H/P PCB
C701L nsp nsp C,CERAMIC HIK AXIAL B560pF-K/50V-52RE D005561277520
C701R nsp nsp C,CERAMIC HIK AXIAL B560pF-K/50V-52RE D005561277520
C702 nsp nsp C,CERAMIC HIK AXIAL F0.1µF-Z/50V-52RE D005104597530
CNT122A nsp nsp CN,WIRE 570MM/3P 5264-03X51088-03 RD1007#22 L000571030010
