93
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR6300
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
SPK A PCB
C903xx /K/N *OF100270R *OF100270R C,FILM POLYESTER ST-0.0022µF-J/100V-5RE D02022206C060
C904xxG /K/N nsp nsp C,CERAMIC HIK AXIAL X0.0047µF-K/16V-52RE D005472773530
J940 /K/N nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
J946 /K/N nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
J947 /K/N nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
- *YT002590R *YT002590R TER,BOARD SCREW 4P R956 (L=BB R=RR)/SH0410370P G612041037320
- *YT001290R *YT001290R TER,BOARD SCREW 8P SH0810360P G61408103600A
CP101 nsp nsp CN.WAFER 2.5MM PLUG BD,BD 52668-1317 13P 2.5 ANG ZIP L102526681310
J933
nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
J954
S-VIDEO PCB
C850
/K/N nsp nsp C,CERAMIC T.C DISC CH22pF-J/50V-5RE D000220167060
C853
C854 /K/N nsp nsp C,CERAMIC HIK AXIAL Y0.01µF-M/16V-52RE D005103773530
C855 /K/N nsp nsp C,CERAMIC HIK AXIAL Y0.01µF-M/16V-52RE D005103773530
IC807 /K/N HC700400Z0 HC700400Z0 IC,LOGIC MM74HCU04MX SOP14 /HEX INVERTER J040740400100
IC808 /K/N *HC700310R *HC700310R IC,LOGIC GD74HC00D (GOLDSTAR) J040740000040
J848 /K/N nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
J849 /K/N nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
R854 /K/N nsp nsp R,CARBON FILM 1M-J,1/5W-52RE-AX C00001056P520
R855 /K/N nsp nsp R,CARBON FILM 470-J,1/5W-52RE-AX C00004716P520
R856 /K/N nsp nsp R,CARBON FILM 1M-J,1/5W-52RE-AX C00001056P520
R857 /K/N nsp nsp R,CARBON FILM 470-J,1/5W-52RE-AX C00004716P520
R858 /K/N nsp nsp R,CARBON FILM 1K-J,1/5W-52RE-AX C00001026P520
R859 /K/N nsp nsp R,CARBON FILM 4.7-J,1/5W-52RE-AX C0004R706P520
R860 /K/N nsp nsp R,CARBON FILM 220-J,1/5W-52RE-AX C00002216P520
XTAL802 /K/N *JX000990R *JX000990R CRYSTAL 17.734476MHz HC/49U CL;18pF E80017R734420
XTAL803 /K/N *JX000980R *JX000980R CRYSTAL 14.31818MHZ,HC49U-CL;18pF E80014R318040
C840U /U nsp nsp C,CERAMIC T.C DISC CH20pF-J/50V-5RE D000200167060
C841U /U nsp nsp C,CERAMIC T.C DISC CH20pF-J/50V-5RE D000200167060
R843U /U nsp nsp R,CARBON FILM 470-J,1/5W-52RE-AX C00004716P520
R844U /U nsp nsp R,CARBON FILM 1M-J,1/5W-52RE-AX C00001056P520
XTAL801U /U nsp *JX000980R CRYSTAL 14.31818MHZ,HC49U-CL;18pF E80014R318040
- *YT002540R *YT002540R JACK,D6.5 ALL R945 YKF51-5516/S-VHS 3P G402042190000
- *YT002560R *YT002560R JACK,DIN AVP9080 DOM YKF51-5512 G403040010010
C801 nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C802 nsp *OA000080R CAP.E.GENERIC 470µF/6.3V(M) 8X11,P=5(LUXON-GR) 85,2000H N211247118110
C802N nsp DD95470300 C,CERAMIC CHIP T.C COG47pF-J/50V-1608REEL D010470167160
C803 nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C803N nsp DD95470300 C,CERAMIC CHIP T.C COG47pF-J/50V-1608REEL D010470167160
C804 nsp *OA000080R CAP.E.GENERIC 470µF/6.3V(M) 8X11,P=5(LUXON-GR) 85,2000H N211247118110
C804N nsp DD95470300 C,CERAMIC CHIP T.C COG47pF-J/50V-1608REEL D010470167160
C805 nsp *OA000080R CAP.E.GENERIC 470µF/6.3V(M) 8X11,P=5(LUXON-GR) 85,2000H N211247118110
C805N nsp DD95470300 C,CERAMIC CHIP T.C COG47pF-J/50V-1608REEL D010470167160
C806 nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C806N nsp DD95470300 C,CERAMIC CHIP T.C COG47pF-J/50V-1608REEL D010470167160
C807 nsp OA47505020 CAP.E.GENERIC 4.7µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247978110
C807N nsp DD95470300 C,CERAMIC CHIP T.C COG47pF-J/50V-1608REEL D010470167160
C808 nsp OA47505020 CAP.E.GENERIC 4.7µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247978110
C809 nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C810 nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C810A nsp DD95470300 C,CERAMIC CHIP T.C COG47pF-J/50V-1608REEL D010470167160
C811 nsp OA47601640 CAP.E.GENERIC 47µF/16V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247038110
C811A nsp DD95470300 C,CERAMIC CHIP T.C COG47pF-J/50V-1608REEL D010470167160
C812 nsp OA47505020 CAP.E.GENERIC 4.7µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247978110
C813 nsp OA47505020 CAP.E.GENERIC 4.7µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247978110
C814 nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C815 nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C816 nsp OA10701620 CAP.E.GENERIC 100µF/16V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210138110
C817 nsp DK98103300 C,CERAMIC CHIP HIK Y5V0.01µF-Z/50V-1608REEL D011103597160
