Marantz SR5300 - Page 73

95
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR6300
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
Q805 *BA001430R *BA001430R SEMI,BRT/PNP RB TR KRA107M PNP J601107M00050
Q806 HT805501B0 HT805501B0 SEMI,TR/GE NPN 2SC KTC2874B TO92-REEL J502287400010
Q806A HT805501B0 HT805501B0 SEMI,TR/GE NPN 2SC KTC2874B TO92-REEL J502287400010
Q808 *BA001190R *BA001190R SEMI,BRT/NPN RC KRC107M,0.4W/TO92M-REEL J6020107M0010
Q816 *HT100610R *HT100610R SEMI,TR/GE PNP 2SA 2SA933S,0.3W/TO92M-REEL J5000933S0050
Q851 *HT300890R *HT300890R SEMI,TR/GE NPN 2SC 2SC3199-GR/KTC3199-GR BULK J5023199G0000
Q852 *HT100610R *HT100610R SEMI,TR/GE PNP 2SA 2SA933S,0.3W/TO92M-REEL J5000933S0050
Q852A *HT100610R *HT100610R SEMI,TR/GE PNP 2SA 2SA933S,0.3W/TO92M-REEL J5000933S0050
Q854 *HT100610R *HT100610R SEMI,TR/GE PNP 2SA 2SA933S,0.3W/TO92M-REEL J5000933S0050
R801 nsp NN05680610 R,CHIP THICK 68-J,1/16W-1608REEL C20006806M160
R802 nsp NN05680610 R,CHIP THICK 68-J,1/16W-1608REEL C20006806M160
R803
nsp NN05750610 R,CHIP THICK 75-J,1/16W-1608REEL C20007506M160
R814
R815 nsp nsp R,CARBON FILM 2.2-J,1/5W-52RE-AX C0002R206P520
R816 nsp nsp R,CARBON FILM 1K-J,1/5W-52RE-AX C00001026P520
R816A nsp nsp R,CARBON FILM 1K-J,1/5W-52RE-AX C00001026P520
R817 nsp nsp R,CARBON FILM 1-J,1/5W-52RE-AX C0001R006P520
R818 nsp nsp R,CARBON FILM 2.2K-J,1/5W-52RE-AX C00002226P520
R818A nsp nsp R,CARBON FILM 2.2K-J,1/5W-52RE-AX C00002226P520
R823 nsp NN05224610 R,CHIP THICK 220K-J,1/16W-1608REEL C20002246M160
R823A nsp nsp R,CARBON FILM 75-J,1/5W-52RE-AX C00007506P520
R824 nsp nsp R,CARBON FILM 10-J,1/5W-52RE-AX C00001006P520
R825 nsp NN05221610 R,CHIP THICK 220-J,1/16W-1608REEL C20002216M160
R826 nsp NN05103610 R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160
R827 nsp NN05104610 R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160
R828 nsp NN05104610 R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160
R829 nsp nsp R,CARBON FILM 100K-J,1/5W-52RE-AX C00001046P520
R830 nsp NN05104610 R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160
R831 nsp NN05102610 R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160
R832 nsp NN05471610 R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160
R833 nsp NN05103610 R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160
R834 nsp NN05822610 R,CHIP THICK 8.2K-J,1/16W-1608REEL C20008226M160
R835 nsp NN05153610 R,CHIP THICK 15K-J,1/16W-1608REEL C20001536M160
R836 nsp NN05102610 R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160
R837 nsp NN05473610 R,CHIP THICK 47K-J,1/16W-1608REEL C20004736M160
R838 nsp NN05333610 R,CHIP THICK 33K-J,1/16W-1608REEL C20003336M160
R839 nsp nsp R,CARBON FILM 1K-J,1/5W-52RE-AX C00001026P520
R840 nsp nsp R,CARBON FILM 1K-J,1/5W-52RE-AX C00001026P520
R841 nsp nsp R,CARBON FILM 1K-J,1/5W-52RE-AX C00001026P520
R842 nsp NN05101610 R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160
R845 nsp nsp R,CARBON FILM 2.2K-J,1/5W-52RE-AX C00002226P520
R846 nsp NN05222610 R,CHIP THICK 2.2K-J,1/16W-1608REEL C20002226M160
R847 nsp NN05103610 R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160
R848 nsp nsp R,CARBON FILM 330-J,1/5W-52RE-AX C00003316P520
R849 nsp NN05105610 R,CHIP THICK 1M-J,1/16W-1608REEL C20001056M160
R850 nsp NN05154610 R,CHIP THICK 150K-J,1/16W-1608REEL C20001546M160
R851 nsp nsp R,CARBON FILM 470K-J,1/5W-52RE-AX C00004746P520
R852 nsp NN05333610 R,CHIP THICK 33K-J,1/16W-1608REEL C20003336M160
R852A nsp NN05123610 R,CHIP THICK 12K-J,1/16W-1608REEL C20001236M160
R853 nsp NN05474610 R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160
R861 nsp nsp R,CARBON FILM 100-J,1/5W-52RE C00001016P520
R861A nsp nsp R,CARBON FILM 47K-J,1/5W-52RE-AX C00004736P520
R862 nsp nsp R,CARBON FILM 47K-J,1/5W-52RE-AX C00004736P520
R862A nsp nsp R,CARBON FILM 100-J,1/5W-52RE C00001016P520
R863 nsp nsp R,CARBON FILM 100-J,1/5W-52RE C00001016P520
R863A nsp nsp R,CARBON FILM 12K-J,1/5W-52RE-AX C00001236P520
VIDEO PCB
- *YT002610R *YT002610R TER,RCA 2PIN RD-7106(Y Y)GND=0/JC0200095N G601200092020
- *YT002630R *YT002630R TER,RCA 3PIN JACK RD7106 (Y Y Y)GND=0,0/JC030012FN G606300125040
C871 nsp nsp C,CERAMIC T.C AXIAL SL47pF-J/50V-52RE D001470067520
C873 nsp *OA000080R CAP.E.GENERIC 470µF/6.3V(M) 8X11,P=5(LUXON-GR) 85,2000H N211247118110
C874 nsp nsp C,CERAMIC T.C AXIAL SL47pF-J/50V-52RE D001470067520
