97
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR6300
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
- /U nsp nsp P.C.B INS ASSY SR6300/U1B(MARANTZ)/POWER-MANUAL 7027061885M10
- /U nsp nsp P.C.B INS ASSY SR6300/U1B(MARANTZ)/POWER-RADIAL 7027061885R10
OUT710 /U nsp *YT002810R SOCKET,POW RECEPT AC OUTLET CCT1304-0212 G435040070000
CNT953 /K nsp nsp CN,WIRE 120/3P 210-05=YH396-05V WH1617#22 7.92 L000121030070
CP713 /K/N nsp nsp CN.WAFER 3.96MM 35328-0210 L104353280200
C710 *OF100300R *OF100300R C,FILM POLYESTER ST-0.047µF-J/100V-5RE D02047306C060
C711 *OF100300R *OF100300R C,FILM POLYESTER ST-0.047µF-J/100V-5RE D02047306C060
C712 *OF100300R *OF100300R C,FILM POLYESTER ST-0.047µF-J/100V-5RE D02047306C060
C713 nsp nsp C,CERAMIC SEMI DISC F0.1µF-Z/50V-5RE PI6 D006104597050
C714 DK17472900 DK17472900 C,CERAMIC AC(SAFETY) DE2F3KH108MN4A(DE1310-469E472M) P10 D00847208K060
C717 nsp OA47702520 CAP.E.GENERIC 470µF/25V(M) 10x15,P=5(LUXON-GR) 85,2000H N211247148110
C718 nsp OA10505020 CAP.E.GENERIC 1µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210978110
C719 nsp OA22705020 CAP.E.GENERIC 220µF/50V(M) 10x17,P=5(LUXON-GR) 85,2000H N211222178110
CN119 nsp nsp CN.WAFER 2.5MM 5267-04A 4P L102526700400
CP711 nsp nsp CN.WAFER 3.96MM 35328-0210 L104353280200
CP712 nsp nsp CN.WAFER 7.92MM YW396V(03AV) L108039602010
CP715 nsp nsp CN.WAFER 2.0MM G1L-S-4P-S2T2-EF L101220040000
CP716 nsp nsp CN.WAFER 2.0MM G1L-S-5P-S2T2-EF L101220050000
D710
nsp *HD201570R D,SWITCHING IN4007 52REEL 1000V 1A K000400700520
D713
D714 nsp *HD201720R D,SWITCHING 1N4148-52RE 75V 150MA DO-34 (MIC) K000414803520
D715 nsp *HD201720R D,SWITCHING 1N4148-52RE 75V 150MA DO-34 (MIC) K000414803520
D719 nsp *HD201570R D,SWITCHING IN4007 52REEL 1000V 1A K000400700520
F711 /N/U *FS000950R *FS000950R FUSE GLASS 20MM T2.5A /250V-SVBRTC(K) 218 N751222501110
F711A /N/U nsp nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010
F711B /N/U nsp nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010
F712 /K/U nsp *FS000940R FUSE CERAMIC 20MM T8A /250V-SVBRTC(K) 215 N752228001110
F712 /N *FS000960R *FS000960R FUSE GLASS 20MM T6.3A /250V-SVBRTC(K) 218 N751226301110
F712A nsp nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010
F712B nsp nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010
F715 /U nsp *FS000950R FUSE GLASS 20MM T2.5A /250V-SVBRTC(K) 218 N751222501110
F715A /U nsp nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010
F715B /U nsp nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010
GND711 nsp nsp TERMINAL ALL PBST/GND PLATE-REEL 3790040876010
IC710 HC38906090 HC38906090 IC,LINEAR-REGULATOR MC7806CT TO220 (ON SEMI)(METAL TYPE) J126780600160
J701 nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
J716 /N/U nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
J716U /U nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
Q714 /K/U nsp *BA001190R SEMI,BRT/NPN RC KRC107M,0.4W/TO92M-REEL J6020107M0010
OUT710 /N *YT002820R *YT002820R SOCKET,POW.RECEPT. AC OUTLET YKE31-0090 G435040110000
L710 nsp nsp COIL,FILTER-INDUCTOR 10UH-Q40/24M-R2.5-52RE 02TB D330100700520
L711 nsp nsp COIL,FILTER-INDUCTOR 10UH-Q40/24M-R2.5-52RE 02TB D330100700520
L712 nsp nsp COIL,FILTER-INDUCTOR 10UH-Q40/24M-R2.5-52RE 02TB D330100700520
Q711 *BA001190R *BA001190R SEMI,BRT/NPN RC KRC107M,0.4W/TO92M-REEL J6020107M0010
Q712 *HT100600R *HT100600R SEMI,TR/GE PNP 2SA KSA916Y,0.9W/TO92L-REEL J5000916Y0050
R710U /U nsp nsp R,METAL FILM 100PPM ERC-12UGK225-BULK C060022574000
T710 /K nsp *TS001680R POWER TRANS AVR1603(GE1)115,230V/50,60HZ STAND BY 35*15 8200350150140
T710 /N *TS001690R *TS001690R POWER TRANS AVR1603(KE2)230V/50HZ STAND BY 35*15 8200350150120
T710 /U nsp *TS001700R POWER TRANS AVR1603(KE3)120V/60HZ STAND BY 35*15 8200350150110
R712 nsp nsp R,CARBON FILM 470-J,1/5W-52RE-AX C00004716P520
R713 nsp nsp R,CARBON FILM 10K-J,1/5W-52RE-AX C00001036P520
R714 nsp nsp R,CARBON FILM 15K-J,1/5W-52RE-AX C00001536P520
R716 nsp nsp R,FIXED,METAL RN-T-1/4WJ-47 2.8*6.4(MAX) N112113647010
R718 nsp nsp R,CARBON FILM 1.8K-J,1/5W-52RE-AX C00001826P520
RY710 *LY000200R *LY000200R RELAY HR-CR7-DC12V/10A G680000210000
ZD711 *HD301980R *HD301980R D,ZENER MTZJ7.5B-0.5W/5MA-52MM K06007R544520
ZD712 *HD302000R *HD302000R D,ZENER MTZJ15B-0.5W/5MA-52MM K06015R044520
ZD713 *HD302000R *HD302000R D,ZENER MTZJ15B-0.5W/5MA-52MM K06015R044520
ZD715 HD30431000 HD30431000 D,ZENER MTZJ4.3B-0.5W/5MA-52MM K06004R344520
ZD716 /K/U nsp *HD301950R D,ZENER MTZJ20B-0.5W/5MA-52MM K06020R044520
AMP PCB
- nsp nsp CN,WIRE 80MM/10P 5264-10=5395-10 RD1007#20 2.5MM L000800100030
