SR6005
Home Theater Receiver
©2010 Marantz America, LLC · www.marantz.com
All specifications, dimensions and weights are subject to change without notice.
D&M Holdings, Marantz, Marantz America, LLC. or any of its subsidiaries will not assume any liability for errors in this spec sheet which may result in consequential errors
Being made by dealers, designers, custom installers, cabinet makers or end users, etc based upon information contained within this document.
AUDIO SECTION
Frequency response: 5 Hz – 10 MHz — +1, –3 dB
• Power amplifier • Color component video connector
Rated output: Front: Input/output level and impedance: Y (brightness) signal — 1 Vp-p, 75
110 W + 110 W (8 , 20 Hz – 20 kHz with 0.08 % T.H.D.) PB / CB signal — 0.7 Vp-p, 75
Center: PR / CR signal — 0.7 Vp-p, 75
110 W (8 , 20 Hz – 20 kHz with 0.08 % T.H.D.) Frequency response: 5 Hz – 60 MHz — +0, –3 dB
Surround:
TUNER SECTION [FM] [AM]
110 W + 110 W (8 , 20 Hz – 20 kHz with 0.08 % T.H.D.) (Note: μV at 75 , 0 dBf = 1 x 10–15 W)
Surround back / Front height: Receiving Range: FM 87.5 MHz – 108.0 MHz, AM 522 kHz – 1611 kHz
110 W + 110 W (8 , 20 Hz – 20 kHz with 0.08 % T.H.D.) Usable Sensitivity: FM1.2 μV (12.8 dBf), AM 18 μV
Maximum effective output power: Front: 50 dB Quieting Sensitivity: MONO 2.0 μV (17.3 dBf)
190 W + 190 W (6 , 1 kHz with 10 % T.H.D.) STEREO 42 μV (34.5 dBf)
Center: S/N (IHF-A): MONO 72 dB
190 W (6 , 1 kHz with 10 % T.H.D.) STEREO 67 dB
Surround: Total harmonic Distortion (at 1 kHz): MONO 0.3 %
190 W + 190 W (6 , 1 kHz with 10 % T.H.D.) STEREO 0.7 %
Surround back / Front height:
GENERAL
190 W + 190 W (6 , 1 kHz with 10 % T.H.D.) Power supply: AC 230 V, 50 Hz
Output connectors: 6 – 8 (SPEAKER A + B : 8 ) Power consumption: 650 W
• Analog 0.2 W (Standby)
Input sensitivity/Input impedance: 175 mV/50 k 3.0 W (CEC standby)
Frequency response: 10 Hz – 100 kHz — ±3 dB (Source
Direct mode)
Maximum external dimensions: 440 (W) x 161 (H) x 389 (D) mm
S/N: 98 dB (IHF–A weighted, Source Direct mode) Weight: 11.8 kg
VIDEO SECTION REMOTE CONTROL UNIT (RC011SR)
• Standard video connectors Batteries: R03/AAA Type (two batteries)
Input/output level and impedance: 1 Vp-p, 75

Other manuals for Marantz SR6005

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Marantz SR6005 and is the answer not in the manual?

Marantz SR6005 Specifications

General IconGeneral
Channels7.1
Power Output110W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs6
HDMI Outputs1
Dolby TechnologiesDolby TrueHD, Dolby Digital Plus, Dolby Pro Logic IIz
NetworkingNo
3D SupportYes
Audio Return Channel (ARC)Yes
Phono InputYes
Total Harmonic Distortion0.08%
Signal-to-Noise Ratio100 dB
Input Sensitivity200 mV
USB PortYes
DTS TechnologiesDTS-HD Master Audio, DTS Neo:6
Multi-roomYes
Frequency Response10Hz-100kHz
Video UpconversionYes
