34
ENGLISH
SURROUND
INPUT SIGNAL
OUTPUT CHANNELS FLUORESCENT INDICATOR
MODE L/R C
SL/SR
SC SW FORMAT STATUS & SURROUND MODE TEMPORARY DISPLAY STATUS
CS2 CINEMA DOLBY DIGITAL(5.1CH) - - - - -
CS2 MUSIC DOLBY DIGITAL(2CH) - - - - -
CS2 MONO DOLBY DIGITAL(2CH:Lt/Rt) - - - - -
DOLBY DIGITAL EX(6.1CH) - - - - -
96KHZ PCM - - - - -
PCM(AUDIO)
OOOOO
PCM CS-2 CINEMA or MUSIC or MONO
ANALOG
OOOOO
CS-2 CINEMA or MUSIC or MONO
DTS(5.1CH) - - - - -
DTS-ES(6.1CH) - - - - -
VIRTUAL DOLBY DIGITAL(5.1CH)
O
---
O
VIRTUAL, DOLBY, DIGITAL VIRTUAL
DOLBY DIGITAL(2CH)
O
---
O
VIRTUAL, DOLBY, DIGITAL, PRO LOGIC VIRTUAL
DOLBY DIGITAL(2CH:Lt/Rt)
O
---
O
VIRTUAL, DOLBY, DIGITAL, PRO LOGIC VIRTUAL
DOLBY DIGITAL EX(6.1CH)
O
---
O
VIRTUAL, DOLBY, DIGITAL VIRTUAL
96KHZ PCM - - - - -
PCM(AUDIO)
O
---
O
VIRTUAL, PRO LOGIC, PCM VIRTUAL
ANALOG
O
---
O
VIRTUAL, PRO LOGIC VIRTUAL
DTS(5.1CH)
O
---
O
VIRTUAL, DTS VIRTUAL
DTS-ES(6.1CH)
O
---
O
VIRTUAL, DTS VIRTUAL
(DSP SURROUND)
DOLBY DIGITAL(5.1CH) - - - - -
MOVIE DOLBY DIGITAL(2CH) - - - - -
HALL DOLBY DIGITAL(2CH:Lt/Rt) - - - - -
STADIUM DOLBY DIGITAL EX(6.1CH) - - - - -
MATRIX 96KHZ PCM - - - - -
PCM(AUDIO)
OOOOO
DSP SOUND, PCM MOVIE or HALL or STADIUM or MATRIX
ANALOG
OOOOO
DSP SOUND MOVIE or HALL or STADIUM or MATRIX
DTS(5.1CH) - - - - -
DTS-ES(6.1CH) - - - - -
STEREO DOLBY DIGITAL(5.1CH)
O
---
O
STEREO, DOLBY, DIGITAL STEREO
DOLBY DIGITAL(2CH)
O
---
O
STEREO, DOLBY, DIGITAL STEREO
DOLBY DIGITAL(2CH:Lt/Rt)
O
---
O
STEREO, DOLBY, DIGITAL STEREO
DOLBY DIGITAL EX(6.1CH)
O
---
O
STEREO, DOLBY, DIGITAL STEREO
96KHZ PCM
O
- - - - STEREO, PCM STEREO -> 96KHz
PCM(AUDIO)
O
---
O
STEREO, PCM STEREO
ANALOG
O
---
O
STEREO STEREO
DTS(5.1CH)
O
---
O
STEREO, DTS STEREO
DTS-ES(6.1CH)
O
---
O
STEREO, DTS STEREO
S-DIRECT DOLBY DIGITAL(5.1CH)
OOO
-
O
DIRECT, DOLBY, DIGITAL S-DIRECT
DOLBY DIGITAL(2CH)
O
---
O
DIRECT, DOLBY, DIGITAL S-DIRECT
DOLBY DIGITAL(2CH:Lt/Rt)
OOO
-
O
DIRECT, DOLBY, DIGITAL S-DIRECT
DOLBY DIGITAL EX(6.1CH)
OOOOO
DIRECT, DOLBY, DIGITAL, SURROUND EX S-DIRECT
96KHZ PCM
O
- - - - DIRECT, STEREO, PCM S-DIRECT -> 96KHz
PCM(AUDIO)
O
---
O
DIRECT, STEREO, PCM S-DIRECT
ANALOG
O
---
O
DIRECT, STEREO S-DIRECT
DTS(5.1CH)
OOO
-
O
DIRECT, DTS S-DIRECT
DTS-ES(6.1CH)
OOOOO
DIRECT, DTS, ES S-DIRECT
Note:
• Dolby Digital (2 ch: Lt/Rt): signal with Dolby Surround flag
Speakers are full set.
• No sound outputs from the surround speaker, center speaker and
subwoofer if the DVD disc has no surround data.
L/R : Front speakers
C : Center speaker
SL/SR : Surround speakers
SC : Surround Center speaker
SW : Sub woofer speaker
