Example connection when using one set of height speakers
.
C
FL FR
SBL
SBR
SW
SL SR
FHL FHR
0
Set “Height” - “Height Sp” to “2ch” in the menu when connecting in this
configuration. (v
p. 224)
.
FR FL C SR SL
SW
SBR SBL
FHR FHL
HEIGHT 1
z
z
The rear height speakers can be connected instead of the front height speakers.
In this case, set the height speakers to be connected under “Height” - “Layout” in
the menu. (v
p. 225)
