Partner: Marantz
Model: SR8500 + SR7500
Device Type: Surround Receiver
bass/treble$
S
Serial signal indicating the current bass and treble level. This is the same as the
front panel of the receiver.
video_mute_on/off_fb D High to indicate the current state of the video mute.
display_input/surr./auto_off/off_fb D High to indicate the currently selected front panel display mode.
speaker_*_on/off_fb D High to indicate the current state for speakers a and b.
sleep_timer_off_fb D High to indicate that the sleep timer is off.
sleep_timer_bar
A
Analog value indicating the time remaining before the sleep mode will turn the
receiver off. To be displayed using a bar graph on a touch panel.
sleep$ S Serial signal indicating the sleep time remaining.
osd_on/off_fb D High to indicate the current state of the on screen display.
night_mode_on/off_fb D High to indicate the current state of the night mode.
DC_trig1/2_on/off_fb D High to indicate the current state of the DC triggers 1 & 2.
setup_menu_on/off_fb D High to indicate the current state of the setup menu.
surr._*_fb D High to indicate the currently selected surround mode.
dolby_HP_*_fb D High to indicate the currently active headphone mode.
test_tone_on/off_fb D High to indicate the current state of the test tone.
test_tone_auto/manual_mode_fb D High to indicate the current test tone mode.
test_tone_ch_*_fb D High to indicate the current channel of test tone.
lip_sync_off_fb D High to indicate that the lip sync function is currently off.
lip_sync_bar
A
Analog value indicating the current lip sync delay. To be displayed using a bar
graph on a touch panel.
lip_sync$ S Serial signal indicating the current lip sync delay.
tuner_stereo/mono_fb D High to indicate the current stereo/mono mode of the tuner.
tuner_frequency_fm
A
Analog value indicating the currently tuned FM channel. To be display using a
digital gauge in the format XXX.XX.
