1-28
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PCB
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
150B
/
N1G 00M18AK063130 00M18AK063130 ESCUTCHEON ESCUTCHEON TRAY GL MZ378
150B
/
N1S 00M18AK063230 00M18AK063230 ESCUTCHEON ESCUTCHEON TRAY SL
150B
/
S1G ns
p
00M18AK063130 ESCUTCHEON ESCUTCHEON TRAY GL MZ378
151B
/
F N ns
p
00M392K06316
0
ESCUTCHEON ESCUTCHEON SACD MOLD GL
151B
/
K1G ns
p
00M392K06316
0
ESCUTCHEON ESCUTCHEON SACD MOLD GL
151B
/
L1G ns
p
00M392K06316
0
ESCUTCHEON ESCUTCHEON SACD MOLD GL
151B
/
N1G 00M392K06316
0
00M392K06316
0
ESCUTCHEON ESCUTCHEON SACD MOLD GL
151B
/
N1S 00M392K06326
0
00M392K06326
0
ESCUTCHEON ESCUTCHEON SACD MOLD SL
151B
/
S1G ns
p
00M392K06316
0
ESCUTCHEON ESCUTCHEON SACD MOLD GL
001D
/
F N ns
p
00M18AK249110 SIDE PANEL SIDE PANEL AL GL
001D
/
K1G ns
p
00M18AK249110 SIDE PANEL SIDE PANEL AL GL
001D
/
L1G ns
p
00M18AK249110 SIDE PANEL SIDE PANEL AL GL
001D
/
N1G 00M18AK249110 00M18AK249110 SIDE PANEL SIDE PANEL AL GL
001D
/
N1S 00M18AK249210 00M18AK249210 SIDE PANEL SIDE PANEL AL SL
001D
/
S1G ns
p
00M18AK249110 SIDE PANEL SIDE PANEL AL GL
100D
/
F N ns
p
00M18AK257520 LID TOP COVER ASM GL
100D
/
K1G ns
p
00M18AK257520 LID TOP COVER ASM GL
100D
/
L1G ns
p
00M18AK257520 LID TOP COVER ASM GL
100D
/
N1G 00M18AK257520 00M18AK257520 LID TOP COVER ASM GL
100D
/
N1S 00M18AK257530 00M18AK257530 LID TOP COVER ASM SL
100D
/
S1G ns
p
00M18AK257520 LID TOP COVER ASM GL
005G
/
F N ns
p
00M04AJ05751
0
LEG LEG ASSY GL
005G
/
K1G ns
p
00M04AJ05751
0
LEG LEG ASSY GL
005G
/
L1G ns
p
00M04AJ05751
0
LEG LEG ASSY GL
005G
/
N1G 00M04AJ05751
0
00M04AJ05751
0
LEG LEG ASSY GL
005G
/
N1S 00M04AJ05752
0
00M04AJ05752
0
LEG LEG ASSY SL
005G
/
S1G ns
p
00M04AJ05751
0
LEG LEG ASSY GL
093G
/
F N ns
p
00M10AJ15412
0
KNOB KNOB HEAD PHONE AL CAP GL
093G
/
K1G ns
p
00M10AJ15412
0
KNOB KNOB HEAD PHONE AL CAP GL
093G
/
L1G ns
p
00M10AJ15412
0
KNOB KNOB HEAD PHONE AL CAP GL
093G
/
N1G 00M10AJ15412
0
00M10AJ15412
0
KNOB KNOB HEAD PHONE AL CAP GL
093G
/
N1S 00M10AJ15422
0
00M10AJ15422
0
KNOB KNOB HEAD PHONE AL CAP SL
093G
/
S1G ns
p
00M10AJ15412
0
KNOB KNOB HEAD PHONE AL CAP GL
001M ns
p
ns
p
MECHANISM SA-CD MECHA MODULE
014M 00M21AK304020 00M21AK304020 MECHANISM MECHA LOADER AND MECHA TRAVERSE
1000 00M18AK271520 00M18AK271520 HOLDER LCD UNIT KIT
1002 00MHQ21202990 00MHQ21202990 DISPLAY LCD WSTN NEGATIVE96X35 TRUL
Y
J001 00MYJ0400255
0
00MYJ0400255
0
JACK !AC INLET TYPE HF-301
J203 00MYT02011290 00MYT02011290 TERMINAL EW-2560T-LH-
W
J204 00MYT02011280 00MYT02011280 TERMINAL EW-2560T-LH-R
L001 00MFC50280040 00MFC50280040 FERRITE CORE TRCN-28-16-20 KITAGAW
A
L011 00MFC90280010 00MFC90280010 FERRITE CORE HF70SH28*2*10 FPC FERRITE CORE
L012 00MFC90280010 00MFC90280010 FERRITE CORE HF70SH28*2*10 FPC FERRITE CORE
L013 00MFC50270040 00MFC50270040 FERRITE CORE USB-4 SLEEVE FERRITE CLAMP
L014 00MFC50160030 00MFC50160030 FERRITE CORE FERRITE CORE TFCK-16-8-13
LH01
/
F N ns
p
00MTS16679050 TRANSF. # MAIN TRANSF.AC100V 50/60HZ EI66-3
0
LH01
/
K1G ns
p
00MTS15743070 TRANSF. # MAIN TRANSF. AC220V 50H
Z
LH01
/
L1G ns
p
00MTS15743050 TRANSF. # MAIN TRANSF. AC110V 60H
Z
LH01
/
N1G 00MTS15743080 00MTS15743080 TRANSF. # MAIN TRANSF. AC230V 50/60H
Z
LH01
/
N1S 00MTS15743080 00MTS15743080 TRANSF. # MAIN TRANSF. AC230V 50/60H
Z
LH01
/
S1G ns
p
00MTS15743080 TRANSF. # MAIN TRANSF. AC230V 50/60H
Z
W103 ns
p
00MYU15100520 FPC SMCD-15X100-BDX6-P1.0-S4
WY01 ns
p
00MYU15100520 FPC SMCD-15X100-BDX6-P1.0-S4
WY02 ns
p
00MYU04060520 FPC 2MCD-04X60-BDX6
(
BL
)
-P1.0-S4.0
WY03 ns
p
00MYU08060520 FPC SMCD-8X60.0-BDX6-P1.0-S4
PACKING
005T
/
F N ns
p
00M24AK851110 USER GUIDE USER GUIDE SA-15S1
(
F
)
005T
/
K1G ns
p
00M24AK851350 USER GUIDE USER GUIDE SA-15S1
(
S L
)
005T
/
L1G ns
p
00M24AK851350 USER GUIDE USER GUIDE SA-15S1
(
S L
)
005T
/
N1G 00M24AK851310 00M24AK851310 USER GUIDE USER GUIDE SA-15S1
(
N
)
005T
/
N1S 00M24AK851310 00M24AK851310 USER GUIDE USER GUIDE SA-15S1
(
N
)
005T
/
S1G ns
p
00M24AK851350 USER GUIDE USER GUIDE SA-15S1
(
S L
)
T100 00MZK18AK0010 00MZK18AK0010 UNIT KIT REMOTE CONTROLLER RC11SA
W001
/
F N ns
p
00MZC01802080 MAINS CORD # MAINS CORD MITY DC-302-J 125V 12
A
W001
/
K1G ns
p
00MZC01808030 MAINS CORD # MAINS CORD CHINA 250V 10
A
W001
/
L1G ns
p
00MZC01807030 MAINS CORD # MAINS CORD TAIWAN 10A 125
V
W001
/
N1G 00MZC01803080 00MZC01803080 MAINS CORD # 2P MAINS CORD 10A 250V CLASS2
