NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
MOTOR C306 00D9410024606 CER. CAP.
0.1uF/ 50V,Z,0805 TYPE,Y5V 413-DV330-313
MOTOR C307 00D9410024606 CER. CAP.
0.1uF/ 50V,Z,0805 TYPE,Y5V 413-DV330-313
MOTOR C308 00D9410024237 ELECT CAP.
100uF/16V,M,105°C 5*11
(
Cd,Pb,H
g
,Cr
)
413-PXE90-109
MOTOR
C309
00D9410024703 ELECT CAP.
1uF/50V,M,105°C 5*11
(
Cd,Pb,H
g
,Cr
)
413-3113-049
MOTOR C310 00D9410024606 CER. CAP.
0.1uF/ 50V,Z,0805 TYPE,Y5V 413-DV330-313
MOTOR C311 00D9410024237 ELECT CAP.
100uF/16V,M,105°C 5*11
(
Cd,Pb,H
g
,Cr
)
413-PXE90-109
MOTOR
C317
90M-DD000010R CER. CAP.
CHIP
(
20
p
F/ 50V,J,0805 TYPE,NPO
)
413-DV330-315
MOTOR C318 90M-DD000010R CER. CAP.
CHIP
(
20
p
F/ 50V,J,0805 TYPE,NPO
)
413-DV330-315
MOTOR C319 00D9410024606 CER. CAP.
0.1uF/ 50V,Z,0805 TYPE,Y5V 413-DV330-313
MOTOR C320 00D9410024237 ELECT CAP.
100uF/16V,M,105°C 5*11
(
Cd,Pb,H
g
,Cr
)
413-PXE90-109
MOTOR C321 00D9410024606 CER. CAP.
0.1uF/ 50V,Z,0805 TYPE,Y5V 413-DV330-313
MOTOR C322 00D9410024606 CER. CAP.
0.1uF/ 50V,Z,0805 TYPE,Y5V 413-DV330-313
MOTOR
C323
90M-DD000020R CER. CAP.
CHIP
(
68
p
F/50V,J,0805 TYPE,NPO
)
413-QMX2-133
MOTOR C324 00D9410024606 CER. CAP.
0.1uF/ 50V,Z,0805 TYPE,Y5V 413-DV330-313
MOTOR C325 00D9410024606 CER. CAP.
0.1uF/ 50V,Z,0805 TYPE,Y5V 413-DV330-313
MOTOR C326 00D9410024237 ELECT CAP.
100uF/16V,M,105°C 5*11
(
Cd,Pb,H
g
,Cr
)
413-PXE90-109
MOTOR
C901
90M-OA000520R ELECT CAP.
1000uF/16V,M, 105°C 10*17
(
Cd,Pb,H
g
,Cr
)
413-F202-001
MOTOR C905 00D9410024237 ELECT CAP.
100uF/16V,M,105°C 5*11
(
Cd,Pb,H
g
,Cr
)
413-PXE90-109
MOTOR C906 00D9410024606 CER. CAP.
0.1uF/ 50V,Z,0805 TYPE,Y5V 413-DV330-313
MOTOR
C907
nsp FILM CAP.
METAL POLYESTER
(
0.1uF/AC125V,K
)
413-DJ3500-884
MOTOR C908 nsp FILM CAP.
METAL POLYESTER
(
0.1uF/AC125V,K
)
413-DJ3500-884
MOTOR
C909
00D9410024402 ELECT CAP.
2200uF/35V,M, 105°C 16*26
(
Cd,Pb,H
g
,Cr
)
413-HT7016-223
MOTOR C910 00D9410024402 ELECT CAP.
2200uF/35V,M, 105°C 16*26
(
Cd,Pb,H
g
,Cr
)
413-HT7016-223
MOTOR C911 00D9410024211 ELECT CAP.
100uF/35V,M,105°C,6.3*11
(
Cd,Pb,H
g
,Cr
)
413-HMD5000-356
MOTOR C912 00D9410024606 CER. CAP.
0.1uF/ 50V,Z,0805 TYPE,Y5V 413-DV330-313
MOTOR C913 00D9410024211 ELECT CAP.
100uF/35V,M,105°C,6.3*11
(
Cd,Pb,H
g
,Cr
)
413-HMD5000-356
MOTOR C914 00D9410024606 CER. CAP.
0.1uF/ 50V,Z,0805 TYPE,Y5V 413-DV330-313
MOTOR C915 00D9410024224 ELECT CAP.
100uF/25V,M,105°C 6.3*11
(
Cd,Pb,H
g
,Cr
)
413-HS100-180
MOTOR C916 00D9410024606 CER. CAP.
0.1uF/ 50V,Z,0805 TYPE,Y5V 413-DV330-313
MOTOR C917 00D9410024224 ELECT CAP.
100uF/25V,M,105°C 6.3*11
(
Cd,Pb,H
g
,Cr
)
413-HS100-180
MOTOR C918 nsp FILM CAP.
METAL POLYESTER
(
0.1uF/AC125V,K
)
413-DJ3500-884
MOTOR C919 00D9410024606 CER. CAP.
0.1uF/ 50V,Z,0805 TYPE,Y5V 413-DV330-313
MOTOR
CN101
00D9580042204 CONN.
3P 2.54 STRIP PIN HEADER
(
H=12.6mm,180°
)
424-KT350-005
MOTOR
CN301
nsp
CONN. 8P FFC CONNECTOR
(
528070810
)
404-8001-2237
MOTOR
CN901
90M-YT004830R
TERMINAL 5P DIN SOCKET
(
JY-5001A
)
420-CDN88-085
MOTOR
D101
90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D102 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D103 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D104 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D105 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D106 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D107 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D108 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D109 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D110 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D111 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D112 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D113 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D114 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D115 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D116 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D117 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D118 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D119 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR
D120
00D9580075103 ZENER DIODE
ZENER DIODE
(
MTZJ5.1-B,1/2W,T-77
)
414-HDJ200-056
MOTOR D121 00D9580075103 ZENER DIODE
ZENER DIODE
(
MTZJ5.1-B,1/2W,T-77
)
414-HDJ200-056
MOTOR D301 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D302 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D303 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D304 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D305 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D306 90M-HZ200200R DIODE
SWITCHING DIODE
(
1SS355,UMD2,SMD
)
414-CD1000-075
MOTOR D901 00D9580018607 DIODE
DIODE
(
1N4002/1N4002TA,1A/100V
)
414-DV300-5014
