Marantz TT8001 - Page 20

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
MOTOR D902 00D9580018607 DIODE
DIODE(1N4002/1N4002TA,1A/100V) 414-DV300-5014
MOTOR D903 00D9580018607 DIODE
DIODE(1N4002/1N4002TA,1A/100V) 414-DV300-5014
MOTOR D904 00D9580018607 DIODE
DIODE(1N4002/1N4002TA,1A/100V) 414-DV300-5014
MOTOR D905 00D9580018607 DIODE
DIODE(1N4002/1N4002TA,1A/100V) 414-DV300-5014
MOTOR D906 00D9580018607 DIODE
DIODE(1N4002/1N4002TA,1A/100V) 414-DV300-5014
MOTOR
D907
00D9580018607 DIODE
DIODE(1N4002/1N4002TA,1A/100V) 414-DV300-5014
MOTOR D908 00D9580018607 DIODE
DIODE(1N4002/1N4002TA,1A/100V) 414-DV300-5014
MOTOR
FUSE901
90M-FS001350R FUSE
FUSE(5A/125V) 422-8001-077
MOTOR
FUSE902
90M-FS001350R FUSE
FUSE(5A/125V) 422-8001-077
MOTOR
FUSE903
90M-FS001360R FUSE
CHIP FUSE(1A/63V) 422-120-063
MOTOR
FUSE904
00D9410030001 FUSE
FUSE(2.5A/125V) 422-1300-051
MOTOR
FUSE905
00D9410030001 FUSE
FUSE(2.5A/125V) 422-1300-051
MOTOR
GND
nsp
CORD 1P WIRE(L=100mm,AWM1617 AWG22,BLACK) 406-DD2250-526
MOTOR IC101 00D9410021104 IC
IC(NJM2147D,DIP8) 417-DJ5500-579
MOTOR
IC102
00D9410021104 IC
IC(NJM2147D,DIP8) 417-DJ5500-579
MOTOR
IC104
00MHC10011090 IC
IC(NJM-4558M-TE3,8PIN,SMD) 417-PS2-577
MOTOR IC105 00MHC10011090 IC
IC(NJM-4558M-TE3,8PIN,SMD) 417-PS2-577
MOTOR
IC106
00D9410021502 IC
IC(TC4066BFN/BU4066BCF.SOP-14) 417-QMX2-190
MOTOR
IC301
00D9410021900 IC
IC(BD4745G/BD4745G-TR) 417-HDJ2000-503
MOTOR
IC302
00D9410021803 IC
IC(BA10393F/BA10393FE2,SOP-8) 417-DV330-197
MOTOR
IC303
00D9410021706 IC
IC(MAX003,FP-100B) 417-DJ5500-578
MOTOR
IC304
00D9410025003 IC
IC SOCKET(28PIN P=2.54mm) 404-HV3500K-613
MOTOR
IC304
90M-HS09CWX0R
U-PRO IC(W27E512-12/W27C512-45,DIP-28,OTP 704-8001-6157
MOTOR
IC901
90M-HC300880R IC
IC(BA05ST,TO-220FP) 417-8001-764
MOTOR
IC905
00D9410021308 IC
IC(NJM7815FA 3PIN) 417-DV330-216
MOTOR
IC906
00D9410021405 IC
IC(NJM7915FA) 417-RCC955A-291
MOTOR
J152
nsp
CORD JUMPER(ø0.6mm,L=5mm,H=10mm) 406-2002-106
MOTOR
JR01
00D9410025320 CHIP RES.
CHIP(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414
MOTOR JR02 00D9410025320 CHIP RES.
CHIP(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414
MOTOR JR03 00D9410025320 CHIP RES.
CHIP(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414
MOTOR
JR04
00D9410025320 CHIP RES.
CHIP(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414
MOTOR JR05 00D9410025320 CHIP RES.
CHIP(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414
MOTOR JR06 00D9410025320 CHIP RES.
CHIP(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414
MOTOR JR07 00D9410025320 CHIP RES.
CHIP(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414
MOTOR
JR08
00D9410025320 CHIP RES.
CHIP(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414
MOTOR JR09 00D9410025320 CHIP RES.
CHIP(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414
MOTOR JR10 00D9410025320 CHIP RES.
CHIP(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414
MOTOR
JR11
00D9410025320 CHIP RES.
CHIP(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414
MOTOR JR12 00D9410025320 CHIP RES.
CHIP(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414
MOTOR JR13 00D9410025320 CHIP RES.
CHIP(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414
MOTOR
JR14
00D9410025320 CHIP RES.
CHIP(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414
MOTOR JR15 00D9410025320 CHIP RES.
CHIP(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414
MOTOR
L301
00D9580016900 FERRITE CORE
BEAD CORE(86-019-A) 415-HV3500K-090
MOTOR L303 00D9580016900 FERRITE CORE
BEAD CORE(86-019-A) 415-HV3500K-090
MOTOR
L304
90M-FC900430R FERRITE CORE
CHIP BEAD(SBK201209T-601Y-S) 415-1300-240
MOTOR L305 90M-FC900430R FERRITE CORE
CHIP BEAD(SBK201209T-601Y-S) 415-1300-240
MOTOR L306 90M-FC900430R FERRITE CORE
CHIP BEAD(SBK201209T-601Y-S) 415-1300-240
MOTOR L307 90M-FC900430R FERRITE CORE
CHIP BEAD(SBK201209T-601Y-S) 415-1300-240
MOTOR L308 90M-FC900430R FERRITE CORE
CHIP BEAD(SBK201209T-601Y-S) 415-1300-240
MOTOR L309 90M-FC900430R FERRITE CORE
CHIP BEAD(SBK201209T-601Y-S) 415-1300-240
MOTOR L310 90M-FC900430R FERRITE CORE
CHIP BEAD(SBK201209T-601Y-S) 415-1300-240
MOTOR L311 90M-FC900430R FERRITE CORE
CHIP BEAD(SBK201209T-601Y-S) 415-1300-240
MOTOR L312 00D9580016900 FERRITE CORE
BEAD CORE(86-019-A) 415-HV3500K-090
MOTOR L313 90M-FC900430R FERRITE CORE
CHIP BEAD(SBK201209T-601Y-S) 415-1300-240
MOTOR L314 90M-FC900430R FERRITE CORE
CHIP BEAD(SBK201209T-601Y-S) 415-1300-240
MOTOR L315 90M-FC900430R FERRITE CORE
CHIP BEAD(SBK201209T-601Y-S) 415-1300-240
MOTOR L316 90M-FC900430R FERRITE CORE
CHIP BEAD(SBK201209T-601Y-S) 415-1300-240
MOTOR L317 90M-FC900430R FERRITE CORE
CHIP BEAD(SBK201209T-601Y-S) 415-1300-240
MOTOR L318 90M-FC900430R FERRITE CORE
CHIP BEAD(SBK201209T-601Y-S) 415-1300-240
MOTOR L319 90M-FC900430R FERRITE CORE
CHIP BEAD(SBK201209T-601Y-S) 415-1300-240
MOTOR L320 90M-FC900430R FERRITE CORE
CHIP BEAD(SBK201209T-601Y-S) 415-1300-240
MOTOR L321 90M-FC900430R FERRITE CORE
CHIP BEAD(SBK201209T-601Y-S) 415-1300-240
MOTOR L322 90M-FC900430R FERRITE CORE
CHIP BEAD(SBK201209T-601Y-S) 415-1300-240
