Marantz TT8001 - Page 21

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
MOTOR L323 00D9580016900 FERRITE CORE
BEAD CORE
(
86-019-A
)
415-HV3500K-090
MOTOR L324 00D9580016900 FERRITE CORE
BEAD CORE
(
86-019-A
)
415-HV3500K-090
MOTOR L325 00D9580016900 FERRITE CORE
BEAD CORE
(
86-019-A
)
415-HV3500K-090
MOTOR
Q101
00D9580040400 TRS.
DIGITAL TRS.
(
DTC124TS OR 2SC4120
)
416-1330-020
MOTOR
Q102
00D9580040808 TRS.
TRS.
(
DTA124TS/2SA1589/DTA124TSATP
)
416-KE200S-024
MOTOR
Q105
00D9410023607 TRS.
TRS.
(
2SD1889,TO-220FP
)
416-DJ5500-206
MOTOR
Q106
00D9410023500 TRS.
TRS.
(
2SB1340,TO-220FP
)
416-DJ5500-205
MOTOR Q107 00D9410023607 TRS.
TRS.
(
2SD1889,TO-220FP
)
416-DJ5500-206
MOTOR Q108 00D9410023500 TRS.
TRS.
(
2SB1340,TO-220FP
)
416-DJ5500-205
MOTOR
Q301
00D9580040507 TRS.
TRS.
(
2SC1740R
)
416-3113-007
MOTOR
R101
90M-NP000110R CHIP RES.
CHIP
(
6.8K OHM,1/8W, 0805 ,J,TP,150V
)
412-HDJ2650-102
MOTOR
R102
90M-NP000040R CHIP RES.
CHIP
(
680 OHM,1/8W, 0805,J,TP 150V
)
412-DV330-323
MOTOR
R103
90M-NP000050R CHIP RES.
CHIP
((
560K OHM,1/8W,J,TP 0805,150V
)
412-DJ5000-520
MOTOR
R104
00D9410025359 CHIP RES.
CHIP
(
22K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-314
MOTOR
R105
90M-NP000080R CHIP RES.
CHIP
(
270 OHM 1/8W 0805 J TP 150V
)
412-CDN88-014
MOTOR R106 90M-NP000080R CHIP RES.
CHIP
(
270 OHM 1/8W 0805 J TP 150V
)
412-CDN88-014
MOTOR R107 00D9410025359 CHIP RES.
CHIP
(
22K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-314
MOTOR R108 90M-NP000110R CHIP RES.
CHIP
(
6.8K OHM,1/8W, 0805 ,J,TP,150V
)
412-HDJ2650-102
MOTOR R109 90M-NP000040R CHIP RES.
CHIP
(
680 OHM,1/8W, 0805,J,TP 150V
)
412-DV330-323
MOTOR R110 90M-NP000050R CHIP RES.
CHIP
((
560K OHM,1/8W,J,TP 0805,150V
)
412-DJ5000-520
MOTOR R111 90M-NP000080R CHIP RES.
CHIP
(
270 OHM 1/8W 0805 J TP 150V
)
412-CDN88-014
MOTOR R112 00D9410025359 CHIP RES.
CHIP
(
22K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-314
MOTOR R113 90M-NP000080R CHIP RES.
CHIP
(
270 OHM 1/8W 0805 J TP 150V
)
412-CDN88-014
MOTOR R114 00D9410025359 CHIP RES.
CHIP
(
22K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-314
MOTOR R115 90M-NP000110R CHIP RES.
CHIP
(
6.8K OHM,1/8W, 0805 ,J,TP,150V
)
412-HDJ2650-102
MOTOR R116 90M-NP000040R CHIP RES.
CHIP
(
680 OHM,1/8W, 0805,J,TP 150V
)
412-DV330-323
MOTOR R117 90M-NP000050R CHIP RES.
CHIP
((
560K OHM,1/8W,J,TP 0805,150V
)
412-DJ5000-520
MOTOR R118 90M-NP000080R CHIP RES.
CHIP
(
270 OHM 1/8W 0805 J TP 150V
)
412-CDN88-014
MOTOR R119 00D9410025359 CHIP RES.
CHIP
(
22K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-314
MOTOR R120 90M-NP000080R CHIP RES.
CHIP
(
270 OHM 1/8W 0805 J TP 150V
)
412-CDN88-014
MOTOR R121 00D9410025359 CHIP RES.
CHIP
(
22K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-314
MOTOR
R122
00D9410024101 RES.
METAL OXIDE FILM
(
1 OHM,1W,T-73
)
412-DJ5500-661
MOTOR R123 00D9410024101 RES.
METAL OXIDE FILM
(
1 OHM,1W,T-73
)
412-DJ5500-661
MOTOR R124 00D9410024101 RES.
METAL OXIDE FILM
(
1 OHM,1W,T-73
)
412-DJ5500-661
MOTOR R125 00D9410025346 CHIP RES.
CHIP
(
10K OHM,1/8W,0805,J,TP 150V
)
412-DV330-306
MOTOR
R126
00D9410025317 CHIP RES.
CHIP
(
680K OHM,1/8W,0805,J,TP ,150V
)
412-CDN88-024
MOTOR
R127
nsp RES.
METAL FILM
(
18K OHM,1/6W,F,T-26
)
412-8001-1057
MOTOR
R128
00D9410025346 CHIP RES.
CHIP
(
10K OHM,1/8W,0805,J,TP 150V
)
412-DV330-306
MOTOR R129 00D9410025317 CHIP RES.
CHIP
(
680K OHM,1/8W,0805,J,TP ,150V
)
412-CDN88-024
MOTOR R130 nsp RES.
METAL FILM
(
18K OHM,1/6W,F,T-26
)
412-8001-1057
MOTOR
R131
nsp RES.
METAL FILM
(
22K OHM,1/6W,F,T-26
)
412-5500-884
MOTOR R132 nsp RES.
METAL FILM
(
22K OHM,1/6W,F,T-26
)
412-5500-884
MOTOR
R133
00D9410025375 CHIP RES.
CHIP
(
12K OHM,1/8W, 0805,J,TP,150V
)
412-DV330-330
MOTOR
R134
00D9410024305 RES.
RESISTOR
(
4.7KB OHM,ø6,RH0615CS3J
)
412-KC220-127
MOTOR
R135
00D9410025391 CHIP RES.
CHIP
(
2.7K OHM,1/8W, 0805,J,TP,150V
)
412-QSPAND-496
MOTOR
R136
00D9410025304 CHIP RES.
CHIP
(
18K OHM 1/8W 0805 J TP 150V
)
412-AMC110D-5057
MOTOR R137 00D9410025304 CHIP RES.
CHIP
(
18K OHM 1/8W 0805 J TP 150V
)
412-AMC110D-5057
MOTOR R138 00D9410025304 CHIP RES.
CHIP
(
18K OHM 1/8W 0805 J TP 150V
)
412-AMC110D-5057
MOTOR R139 00D9410025359 CHIP RES.
CHIP
(
22K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-314
MOTOR R140 00D9410025359 CHIP RES.
CHIP
(
22K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-314
MOTOR
R141
00D9410025362 CHIP RES.
CHIP
(
47K OHM,1/8W,0805,J,TP 150V
)
412-DV330-321
MOTOR R142 00D9410025359 CHIP RES.
CHIP
(
22K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-314
MOTOR R143 00D9410025359 CHIP RES.
CHIP
(
22K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-314
MOTOR
R144
00D9410025333 CHIP RES.
CHIP
(
1K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-305
MOTOR R145 00D9410025333 CHIP RES.
CHIP
(
1K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-305
MOTOR R146 00D9410024101 RES.
METAL OXIDE FILM
(
1 OHM,1W,T-73
)
412-DJ5500-661
MOTOR R147 00D9410024101 RES.
METAL OXIDE FILM
(
1 OHM,1W,T-73
)
412-DJ5500-661
MOTOR R148 00D9410024101 RES.
METAL OXIDE FILM
(
1 OHM,1W,T-73
)
412-DJ5500-661
MOTOR R149 00D9410025346 CHIP RES.
CHIP
(
10K OHM,1/8W,0805,J,TP 150V
)
412-DV330-306
MOTOR R150 00D9410025333 CHIP RES.
CHIP
(
1K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-305
MOTOR R151 00D9410025333 CHIP RES.
CHIP
(
1K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-305
MOTOR R152 00D9410025333 CHIP RES.
CHIP
(
1K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-305
MOTOR
R153
90M-NP000030R CHIP RES.
CHIP
(
220 OHM,1/8W,0805,J,TP 150V
)
412-DV330-333
27
