Marantz TT8001 - Page 22

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
MOTOR R154 90M-NP000030R CHIP RES.
CHIP
(
220 OHM,1/8W,0805,J,TP 150V
)
412-DV330-333
MOTOR R155 90M-NP000030R CHIP RES.
CHIP
(
220 OHM,1/8W,0805,J,TP 150V
)
412-DV330-333
MOTOR
R156
90M-NP000060R CHIP RES.
CHIP
(
100 OHM,1/8W,0805,J,TP 150V
)
412-DV330-304
MOTOR R157 90M-NP000060R CHIP RES.
CHIP
(
100 OHM,1/8W,0805,J,TP 150V
)
412-DV330-304
MOTOR R158 90M-NP000060R CHIP RES.
CHIP
(
100 OHM,1/8W,0805,J,TP 150V
)
412-DV330-304
MOTOR R159 90M-NP000060R CHIP RES.
CHIP
(
100 OHM,1/8W,0805,J,TP 150V
)
412-DV330-304
MOTOR R160 90M-NP000060R CHIP RES.
CHIP
(
100 OHM,1/8W,0805,J,TP 150V
)
412-DV330-304
MOTOR R161 90M-NP000060R CHIP RES.
CHIP
(
100 OHM,1/8W,0805,J,TP 150V
)
412-DV330-304
MOTOR R162 90M-NP000060R CHIP RES.
CHIP
(
100 OHM,1/8W,0805,J,TP 150V
)
412-DV330-304
MOTOR R163 90M-NP000060R CHIP RES.
CHIP
(
100 OHM,1/8W,0805,J,TP 150V
)
412-DV330-304
MOTOR R301 00D9410025346 CHIP RES.
CHIP
(
10K OHM,1/8W,0805,J,TP 150V
)
412-DV330-306
MOTOR R302 00D9410025359 CHIP RES.
CHIP
(
22K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-314
MOTOR R303 00D9410025359 CHIP RES.
CHIP
(
22K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-314
MOTOR
R304
90M-NP000090R CHIP RES.
CHIP
(
3.3K OHM,1/8W, 0805,J,TP,150V
)
412-DV330-317
MOTOR
R305
90M-NP000070R CHIP RES.
CHIP
(
1M OHM,1/8W, 0805,J,TP 150V
)
412-DV330-308
MOTOR R306 00D9410025333 CHIP RES.
CHIP
(
1K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-305
MOTOR R307 90M-NP000060R CHIP RES.
CHIP
(
100 OHM,1/8W,0805,J,TP 150V
)
412-DV330-304
MOTOR R308 00D9410025362 CHIP RES.
CHIP
(
47K OHM,1/8W,0805,J,TP 150V
)
412-DV330-321
MOTOR R309 00D9410025346 CHIP RES.
CHIP
(
10K OHM,1/8W,0805,J,TP 150V
)
412-DV330-306
MOTOR R310 00D9410025359 CHIP RES.
CHIP
(
22K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-314
MOTOR R311 00D9410025359 CHIP RES.
CHIP
(
22K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-314
MOTOR R312 90M-NP000090R CHIP RES.
CHIP
(
3.3K OHM,1/8W, 0805,J,TP,150V
)
412-DV330-317
MOTOR R313 90M-NP000070R CHIP RES.
CHIP
(
1M OHM,1/8W, 0805,J,TP 150V
)
412-DV330-308
MOTOR R314 00D9410025333 CHIP RES.
CHIP
(
1K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-305
MOTOR R315 90M-NP000060R CHIP RES.
CHIP
(
100 OHM,1/8W,0805,J,TP 150V
)
412-DV330-304
MOTOR R316 00D9410025362 CHIP RES.
CHIP
(
47K OHM,1/8W,0805,J,TP 150V
)
412-DV330-321
MOTOR
R319
90M-NP000100R CHIP RES.
CHIP
(
4.7K OHM,1/8W,0805,J,TP 150V
)
412-DV330-320
MOTOR R320 90M-NP000030R CHIP RES.
CHIP
(
220 OHM,1/8W,0805,J,TP 150V
)
412-DV330-333
MOTOR R321 00D9410025333 CHIP RES.
CHIP
(
1K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-305
MOTOR R322 00D9410025333 CHIP RES.
CHIP
(
1K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-305
MOTOR R323 00D9410025333 CHIP RES.
CHIP
(
1K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-305
MOTOR R324 00D9410025333 CHIP RES.
CHIP
(
1K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-305
MOTOR R325 00D9410025333 CHIP RES.
CHIP
(
1K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-305
MOTOR R326 90M-NP000100R CHIP RES.
CHIP
(
4.7K OHM,1/8W,0805,J,TP 150V
)
412-DV330-320
MOTOR R327 90M-NP000100R CHIP RES.
CHIP
(
4.7K OHM,1/8W,0805,J,TP 150V
)
412-DV330-320
MOTOR R328 90M-NP000100R CHIP RES.
CHIP
(
4.7K OHM,1/8W,0805,J,TP 150V
)
412-DV330-320
MOTOR R329 90M-NP000060R CHIP RES.
CHIP
(
100 OHM,1/8W,0805,J,TP 150V
)
412-DV330-304
MOTOR R330 90M-NP000070R CHIP RES.
CHIP
(
1M OHM,1/8W, 0805,J,TP 150V
)
412-DV330-308
MOTOR R331 00D9410025346 CHIP RES.
CHIP
(
10K OHM,1/8W,0805,J,TP 150V
)
412-DV330-306
MOTOR R332 00D9410025333 CHIP RES.
CHIP
(
1K OHM,1/8W, 0805,J,TP 150V
)
412-DV330-305
MOTOR R333 00D9410025346 CHIP RES.
CHIP
(
10K OHM,1/8W,0805,J,TP 150V
)
412-DV330-306
MOTOR R334 00D9410025346 CHIP RES.
CHIP
(
10K OHM,1/8W,0805,J,TP 150V
)
412-DV330-306
MOTOR R335 00D9410025346 CHIP RES.
CHIP
(
10K OHM,1/8W,0805,J,TP 150V
)
412-DV330-306
MOTOR R336 00D9410025346 CHIP RES.
CHIP
(
10K OHM,1/8W,0805,J,TP 150V
)
412-DV330-306
MOTOR R337 00D9410025346 CHIP RES.
CHIP
(
10K OHM,1/8W,0805,J,TP 150V
)
412-DV330-306
MOTOR R338 00D9410025346 CHIP RES.
CHIP
(
10K OHM,1/8W,0805,J,TP 150V
)
412-DV330-306
MOTOR
R901
nsp RES.
CARBON FILM
(
150K OHM,1/6W,J,T-26
)
412-3113-046
MOTOR
R902
00D2412401952 RES.
CARBON FILM
((
18K OHM,1/6W,J,T-26
)
412-3113-061
MOTOR
SW901
90M-SP001360R
SW POWER SW 403-8001-263
MOTOR
X301
00D9580074803
X'TAL CITIZEN BRAND
(
CSA-309,16MHz
)
427-CDN88-072
SENSOR PWB ASSY
SENSOR
IC103
90M-HW100770R
PHOTO UNIT IC
(
HEDS-9700#F51
)
417-PS2-504
28
