March SKALA - Technical Characteristics; Product Specifications

5
1.2 Technical characteristics
1.2.1 Product specifications are given in Table 2.
Table 2
Specification Parameter value «Type 01» «Type 02»
Overall dimensions, mm
(1020±15) (H)
(573±50) (L)
(116±20) (W)
(1020±15) (H)
(573±50) (L)
(116±20) (W)
Weight (without the electroshock device
AIR-107 «SСORPION-A» (350) «Type 01»), kg
3,8 ±0,5 4,1 ± 0,5
Sparking voltage, kW 70.0 – 120.0 70.0 – 120.0
Average impact power at the load resistance
of 1 kOhm, W
7,0 – 10,0 7,0 – 10,0
The maximum allowable impact power reduction
when applied at clothes, %
< 25 < 25
Maximum permissible exposure
to temporary loads, J
< 50 < 50
Temperature range of application,°С From –20 to +40 From –20 to +40
Relative air humidity up to 98% at 25°С up to 98% at 25°С
