7
1.3.2 On the outer side of the case there are located («Type 01» – fig.2a, «Type 02» – fig.2b):
• conductive foil (5) with the electrodes (6);
• glass (7) between the electrodes for additional isolation;
• insulating film (not shown);
• fireproof coating (on the additional order) – not shown.
1.3.3 On the inner side of the product «Type 01» there are located (fig. 3):
• handle (8) and a brace (9) designed to hold the product safely;
• staples (10) designed to attach the electroshock device to the product;
• shock absorber (11) designed for additional internal insulation of the product.
fig.2
a) «Type 01» b) «Type 02»
5
7
6
6
