Marco Ecoboiler WMT5 - External Arrangement; Internal Arrangement

Service Manual Ecoboiler wallmount 1000671 100676 061010 Page 7 of 18
4.2. EXTERNAL ARRANGEMENT:
4.3. INTERNAL ARRANGEMENT:
Side Panel
Tap/
Push Button
Fixed centre
panel
Top tank access Lid
High Level Probe Assembly (2300463)
Low Level Probe
Assembly (2300463)
PCB Ecoboiler
Control (1600345)
ELEMENT 2.4kW
230V 1500950
Valve inlet
Solenoid (1502190)
Overflow
TuberHose
Mid Level Probe Assembly (2300463)
Thermal Switch
130Deg (1502087)
Terminal Mains
Connector
1502011
Thermistor Pocket U Shape
2300765
PCB Bracket
