Marcy RB1016 - Page 9

9
STEP 4
Insert the sliding tube (68) into seat support bracket (25). Line up the holes and secure sliding tube
(68) with quick release knob (24).
Attach seat cushion (32) to the seat support bracket (25). Secure using four allen screws (8).
Attach the sliding tube (68) to the sliding frame (26). Secure using eight allen screws (8).
Attach back cushion (28) to the seat support bracket (25). Secure using four allen screws (8).
28
60
32
8
25
24
68
8
8
8
8
8
26
