• pump (2) with drain screw (9)
• clear cover of pump suction chamber (8)
• connection exible hose (3)
• valve (4)
• 2x hose stud (only one will be used)
• sealing:
– 2x O-rings for pump sockets
– sealing for pump suction chamber
• 2 screwed joints for assembly of the pump
• 1x hose clamp:
Technical data
Sand ltration equipment (400 mm ltration vessel), pump motor with coarse
pre-lter, 6- way valve and plastic base.
Flow rate 6.6 m³/h
Tension 230 V/ 50Hz
Power input 450 W
IP class IP X4
Maximum water temperature 35°C
Sand fill max. 17 kg
Grain size of filtration sand 0,6 - 1,2 mm
Weight without fill Approx. 15 kg
Dimensions 69 x 46 x 33 cm
Max. working pressure 1,5 bar
Location of filtration device
Firstly select suitable place for location of ltration. Such a place should have even
base, with good access, protected from rain, sunlight and possible ooding. Do not
install the device in sumps, shafts etc. because there is high risk of ooding of elec-
trical pump. Select a place where at lease 10 cm space will remain behind the pump
motor for air supply to cool the motor. Also above the ltration and around it must
be sucient space for inspections and maintenance. Near to the installation place
a single-phase socket meeting CSN requirements must be. If you use some exten-
sion cable, it must be of the type H07RN-F, with minimal core section 1 mm
2
.
Under the ltration unit we recommend to use some even (concrete, earthenware
etc.) plate of suitable size and under the pump a rubber pad should be placed to
damper vibrations and noise. Due to safety reasons install the ltration so that the
smallest distance from pool edge is 2 m. Suction and go-and -return pipe should be
led to be the most direct and is possible under gradient to the pump or valve. Big
-
ger distance between the unit and pool and too complicated piping have negative
eect on ltration unit properties. Install the ltration unit under water level in the
pool with a pump located at the bottom of the pool (this is a ow pump).
