Mark-10 DC Series User Manual

Series DC Digital Controllers
10
5.1 Speed
Independent speeds can be set for both directions of movement. The
parameters are labeled as follows:
Default speed settings and available speeds are as follows:
Test stand Parameter labels
ESMH L SPEED, R SPEED
ESM UP SPEED, DN SPEED
TSFM500 /
TSFM500H
UP SPEED, DN SPEED
TSTM /
TSTMH
CW SPEED, CCW SPEED
Test stand Default
speed
ESMH 10 in/min
ESM 10 in/min
TSFM500 /
TSFM500H
5 in/min
TSTM / TSTMH 6 RPM
Available settings
in/min [mm/min]
0.2 - 50 [5 - 1270]
0.02 - 36 [0.5 - 900]
0.01 - 6 [0.2 - 150]
0.01 - 15 RPM [0.05 - 90°/s]
UP SPEED: 10.73
ESC ENTR
+
_
+
Increments the speed setting. Holding down + will
increment at an increasingly faster rate.
–
Decrements the speed setting. Holding down – will
decrement at an increasingly faster rate.
ENTR
Returns to the Test Parameter Setup menu
ESC
Exits the parameter without saving changes
