FX20 INSTALL GUIDE
VERSION 1.6 | APRIL 26, 2024
SIGN-OFF UPON COMPLETION
Upon completing the installation, please ll this form out and return it to Markforged at the address below.
FX20 Machine ID: ________-____-____-____-____________
GANTRY SKEW UTILITY MEASUREMENTS
Part A: ______________________________________
Part B: ______________________________________
PRINTER LEVEL MEASUREMENTS
X-level, chassis to earth: ______________________________________
Y-level, chassis to earth: ______________________________________
Y0 rail: ______________________________________
Y1 rail: ______________________________________
Bed level (printer Y-axis): ______________________________________
Bed level (printer X-axis): ______________________________________
Purchasing Organization:______________________________________
Customer Contact:___________________________________________
Address:___________________________________________________
Date:______________________________________________________
______________________________________________
(Customer signature)
____________________________________ ____________________________________
(Reseller signature) (Reseller print name)
RESELLER
INSTRUCTIONS
Please complete, sign, scan, and
email to preinstall@markforged.
com
Include:
● Photographs of the
parts printed with the
Nozzle Oset Utility,
● Log File associated with
the Nozzle Oset Utility
● Photos of the Air Intake
First Print
