12
shown in the following drawing.
B
B
B
B
B
B
B
red
Make sure that the red wire is connected to the red contact
“B”. An incorrect connection will cause a short circuit,
which will trigger the overload protection in the switched
mode power pack.
74371
74391
4
4
4
