CV355-30X-IP Manual
www.marshall-usa.com5 6
2.2 Tally Indicator Light Function Description
2.2.1 The tally indicator light function may be enabled through the control of VISCA command.
The setting method is as follows:
Tally Mode : 8x 01 7E 01 0A 01 0p FF
p = 0 : OFF
p = 4 : On (half-brightness)
p = 5 : On (full-brightness)
3.1 Installation Basics
3.1.1 CV355-30X-IP Dimensions
Length x Width x Height : 186.71 x 67.0 x 67.0 mm
Weight : 1 Kg
3.2 Connecting devices
3. 2.1 HDMI connection to display, switch, or media
3. Installation Instructions
HDMI Cable
3G-SDI Cable
Monitor or HDTV
Monitor or HDTV
