4.3.4 System Configurations
No. Item. Function Descriptions
1 Resolution Set the resolution of the camera. Resolutions supported by the camera are as follows:
3840x2160P 59.94/50/29.97 fps
1080P 59.94/50/29.97/25 fps
720P 59.94/50/29.97/25 fps
After switching to the resolution, the camera will restart. Please refresh the browser
2 Output signal According to the output resolution, selections are available for HDMI output, streaming
output, or HDMI + streaming output. For output signals supported by different resolution,
please refer to the following table:
3 HDMI YUV Select YUV422 or YUV420 (This function is only available for these two resolutions,
3840x2160/59.94p and 3840x2160/50p and remains in display mode for all other
resolutions)
4 Apply After the setting has been modified, select this button to apply the setting
Resolution Available output modes
3840x2160/59.94p HDMI or streaming single output
3840x2160/50p HDMI or streaming single output
3840x2160/29.97p
Simultaneous HDMI and streaming
outputs
3840x2160/25p
1080p/59.94
1080p/50
1080p/29.97
1080p/25
720p/59.94
720p/50
720p/29.97
720p/25
1
2
3
4
