Marshall Amplification CV420-30X-IP User Manual

9
4. Network Function Settings
4.1 Web System Requirements
4.1.1 Web Browser :
• Internet Explorer 11 or above
• FireFox 66.0.3 or above
• Chrome 73 or above
• Edge 42.17134 or above
• Safari 12.1 or above
4.2 Connecting Camera to Network
4.2.1 Connecting to Internet
Two common connection methods are shown below
1. Connecting via switch or router
2. If the camera is connected to the computer directly, the computer IP address must be
modified to have the same network segment as the camera
For example, the factory-preset default IP address of CV420-30X-IP is 192.168.100.100. The
computer IP address must be set with the same subnet, such as 192.168.100.101, so that the
computer can be connected correctly with the camera
• Connection Diagram
• Change network settings

Marshall Amplification CV420-30X-IP Specifications

General

Brand	Marshall Amplification
Model	CV420-30X-IP
Category	Security Camera
Language	English
