AMP ASSEMBLY TABLES
TABLE 1 - MAINS TRANSFORMERS
VOLTAGE SPEC QTY DESCRIPTION STOCK NO.
A, D, E, H, I,K, L, Q,
S, X
1 POWER TRANSFORMER MD173DE TXMA-91066
B, C, F, M, T, U 1 POWER TRANSFORMER MD173DU TXMA-91067
J 1 POWER TRANSFORMER MD173DJ TXMA-91068
TABLE 2- FRONT PANELS
MODEL QTY DESCRIPTION STOCK NO.
DSL40CR 1 DSL40CR FRONT PANEL PANL-91096
TABLE 3 - REAR PANELS - COMBO
VOLTAGE SPEC QTY DESCRIPTION STOCK NO.
A, D, E, H, I,K, L, Q,
S, X
1 DSL40CR REAR PANEL 230V PANL-91097
B, C, F, M, T, U 1 DSL40CR REAR PANEL 120V PANL-91098
J 1 DSL40CR REAR PANEL 100V PANL-91099
DSL40CR (CCC) 1 DSL40CR REAR PANEL (CCC) PANL-91100
TABLE 5 - KNOBS
MODEL QTY DESCRIPTION STOCK NO.
DSL40CR 1 BROWN BODY GOLD CAP D FLAT D=19.5,
LINE OPP, FLAT TOL 5%
KNOB-90047
TABLE - 4 MAINS INPUT FUSES
VOLTAGE SPEC QTY DESCRIPTION STOCK NO.
A, D, E, H, I, K, L, Q,
S, X
1 T1A 5X20 0219001.MXAP FUSE-90018
B, C, F, J, M, T, U 1 T2A 5X20 0219002.MXAP FUSE-90017
TABLE 6 - MAIN SWITCHES
VOLTAGE SPEC QTY DESCRIPTION STOCK NO.
A, D, E, H, I, K, L, Q,
S, X
1 MAIN SWITCH WITH RED LIGHT 220V SWTM-90009
B, C, F, J, M, T, U 1 MAIN SWITCH WITH RED LIGHT 110V SWTM-90012
9DSL40CR service manual
BOOK-80015-01 | M3390.069
