020.
TECHNICAL INFORMATION
SOUND SPECIFICATION
• ACTIVE STEREO LOUDSPEAKER WITH BASS REFLEX SYSTEM
• DIGITAL CLASS D AMPLIFIER: 2X20W + 1X40W
• ¾” DOME TWEETERS: 2X
• 5 ¼” WOOFER: 1X
• BASS AND TREBLE TONE CONTROLS
• FREQUENCY RESPONSE: 45 - 22 000Hz +-3db
• CROSSOVER FREQUENCY: 2500Hz
• CONNECTIVITY:
- BLUETOOTH: STANDARD V4.0 + EDR APTX® CODEC
- INPUT 1 - 3.5MM: 1X
- INPUT 2 - RCA: 1X
- OPTICAL INPUT: 1X
• MAX POWER OUTPUT: 80W RMS
TECHNICAL INFORMATION
• MAINS INPUT VOLTAGE: 100-240V~ /200W
• NOMINAL RATING: 100-240V~
• ABSOLUTE MIN/MAX: 90-264V~
• MAINS FREQUENCY: 50-60Hz
• MAX PEAK POWER CONSUMPTION: 200W
• WEIGHT: 5.10kg
• SIZE: 350 X 185 X 185mm
NOTE: THE FRONT IS
NOT REMOVABLE. THIS
ILLUSTRATION INTENDS TO
SHOW THE INTERNAL SPEAKER
LAYOUT. DO NOT ATTEMPT
TO REMOVE THE FRONT FRET
FOR RISK OF DAMAGING YOUR
ACTIVE LOUDSPEAKER.
